温度和压力对低热值燃料层流燃烧特性的影响

郑玮琳,  张世杰,  庞历瑶,  谢凡,  曾文

downloadPDF
文章导航 > 航空动力学报  > 2021 >  36(8): 1578-1585
郑玮琳, 张世杰, 庞历瑶, 谢凡, 曾文. 温度和压力对低热值燃料层流燃烧特性的影响[J]. 航空动力学报, 2021, 36(8): 1578-1585. doi: 10.13224/j.cnki.jasp.20200453
引用本文: 郑玮琳, 张世杰, 庞历瑶, 谢凡, 曾文. 温度和压力对低热值燃料层流燃烧特性的影响[J]. 航空动力学报, 2021, 36(8): 1578-1585. doi: 10.13224/j.cnki.jasp.20200453
shu
ZHENG Weilin, ZHANG Shijie, PANG Liyao, XIE Fan, ZENG Wen. Effects of temperature and pressure on laminar flame characteristics of low heat value fuel[J]. Journal of Aerospace Power, 2021, 36(8): 1578-1585. doi: 10.13224/j.cnki.jasp.20200453
Citation: ZHENG Weilin, ZHANG Shijie, PANG Liyao, XIE Fan, ZENG Wen. Effects of temperature and pressure on laminar flame characteristics of low heat value fuel[J]. Journal of Aerospace Power, 2021, 36(8): 1578-1585. doi: 10.13224/j.cnki.jasp.20200453
shu

温度和压力对低热值燃料层流燃烧特性的影响

doi: 10.13224/j.cnki.jasp.20200453

  • 1. 沈阳航空航天大学 航空发动机学院, 沈阳 110136;

  • 2. 中国航空工业集团有限公司 沈阳飞机设计研究所, 沈阳 110035

基金项目:

辽宁省自然科学基金博士科研启动基金（2019-BS-185）

详细信息
    作者简介:

    郑玮琳(1989-),女,副教授、硕士生导师,博士,主要从事燃烧室流动与反应动力学研究。

    通讯作者:

    曾文(1977-),男,教授、博士生导师,博士,主要从事航空发动机燃烧过程与排放物生成的数值研究。E-mail:zengwen928@sohu.com

  • 中图分类号: V231.2;TK16

Effects of temperature and pressure on laminar flame characteristics of low heat value fuel

  • 1. School of Aero-engine, Shenyang Aerospace University, Shenyang 110136, China;

  • 2. Shenyang Aircraft Design and Research Institute, Aviation Industry Corporation of China Limited, Shenyang 110035, China

    摘要
  • 摘要: 为阐明低热值燃料在燃气轮机工况下的燃烧特性，在定容燃烧弹中测试了初始压力分别为0.10、0.15、0.20 MPa，初始温度分别为303、353、403、453 K，当量比范围为0.8~1.6，体积分数为7% H2、21.72% CO、21.45% CO2、49.83% N2的高炉煤气层流燃烧速度，并采用Gri-Mech 3.0化学反应机理对其进行了数值模拟。实验和模拟均发现，低热值燃料的层流燃烧速度随着初始压力的降低而增高，随着初始温度的增加而升高，且层流燃烧速度随温度和压力并非呈现单调性的变化规律，并在实验工况范围内对层流燃烧速度进行了温度和压力拟合。通过敏感性分析发现：主要的正向促进反应为R99、R46，主要的逆向抑制反应为R45、R36，层流燃烧速度受高活性自由基的影响，与链终止反应与链分支反应关于高活性自由基的竞争有关；随着初始压力的降低和初始温度的升高，高活性自由基摩尔分数增大，从而导致层流燃烧速度升高。



    Abstract: In order to illustrate the combustion characteristics of low heat value fuel under operation conditions of gas turbines, the laminar flame velocity of blast furnace gas, with volume fraction of 7%H2, 21. 72%CO, 21. 45%CO2, 49. 83%N2, was measured in a constant volume vessel, under initial pressures of 0. 10, 0. 15, 0. 20 MPa, initial temperatures of 303, 353, 403, 453 K, and equivalent ratios within the range of 0. 8~1. 6,in comparison with calculation results using the Gri-Mech 3. 0 kinetic mechanism. It was concluded that the laminar flame velocity of low heat value fuel increased with the decrease of the initial pressure and the increase of the initial temperature. The change of the laminar flame velocity was not monotonous and thus was fitted by high-order polynomials based on the experimental data. Further sensitivity analysis showed that the main reactions with positive sensitivities were R99 and R46,and the main reactions with negative sensitivities were R45 and R36,respectively. The laminar flame velocity was highly dependent on reactive free radicals,and affected by the competition between chain termination reactions and chain branching reactions. The mole fraction of active free radicals increased with the decrease of initial pressure and the increase of initial temperature, resulting in an increase in the laminar flame speed.



    • HTML
    • 参考文献(18)
  • [1] 刘文和,杨若仪. 低热值煤气燃气轮机联合循环发电在钢铁厂的应用[J].燃气轮机技术,2004,17(1):21-25. LIU Wenhe, YANG Ruoyi. Gas turbine combined cycle power generation burning LHV gas used in iron and steel works[J]. Gas Turbine Technology, 2004, 17(1):21-25.(in Chinese)
    [2] 朱世澜. 国外中、低热值气体燃料开发及应用于燃气轮机的概况[J].燃气轮机技术,1991,4(2):16-22. ZHU Shilan.Development of medium and low calorific value fuel and application in gas turbine abroad[J]. Gas Turbine Technology,1991,4(2):16-22.(in Chinese)
    [3] LIU Yongqi,WANG Yanxia,WANG Haifeng,et al.Experimental investigations on combustion characteristics of the blast furnace gas[C]//Proceedings of the 3rd International Conference on Bioinformatics and Biomedical Engineering. Beijing:IEEE Engineering in Medicine and Biology Society, 2009:1-4.
    [4] PUGH D G, O'DOHERTY T, GRIFFITHS A J, et al. Laminar burning velocity and Markstein length characterisation of compositionally dynamic blast furnace gas[R].ASME Paper GT2012-69667,2012.
    [5] PUGH D G,O'DOHERTY T,GRIFFITHS A J,et al.Sensitivity to change in laminar burning velocity and Markstein length resulting from variable hydrogen fraction in blast furnace gas for changing ambient conditions[J]. International Journal of Hydrogen Energy,2013,38(8):3459-3470.
    [6] DAVIS S G,JOSHI A V,WANG H,et al.An optimized kinetic model of H2/CO Combustion[J]. Proceedings of the Combustion Institute,2005,30(1):1283-1292.
    [7] LI J,ZHAO Z,KAZAKOV A,et al.A comprehensive kinetic mechanism for CO, CH2O, and CH3OH combustion[J].International Journal of Chemical Kinetics,2007,39(3):109-136.
    [8] SCHWER D A,LU P S,GREEN W H.Anadaptive chemistry-approachto modelingcomplexkineticsin reactingflows[J].Combustion and Flame,2003,133(4):451-465.
    [9] 刘宇, 孙震, 汤卓, 等. 初始温度对CH4/RP-3航空煤油混合燃料层流燃烧特性的影响[J]. 航空动力学报, 2019,34(2):348-356. LIU Yu, SUN Zhen, TANG Zhuo, et al. Effects of initial temperature on the laminar combustion characteristics of CH4/RP-3 mixed fuel[J].Journal of Aerospace Power,2019, 34(2):348-356.(in Chinese)
    [10] 刘宇, 汤卓, 孙震, 等.小球藻油/RP-3航空煤油混合燃料的层流燃烧特性[J].航空动力学报, 2019,34(8):1663-1670. LIU Yu, TANG Zhuo, SUN Zhen, et al. Laminar combustion characteristics of chlorella oil/RP-3 kerosene mixed fuel[J].Journal of Aerospace Power,2019,34(8):1663-1670.(in Chinese)
    [11] HUANG Zuohua,ZHANG Yong,ZENG Ke,et al.Measurements of laminar burning velocities for natural gas-hydrogen-air mixtures[J].Combust and Flame,2006,146(1/2):302-311.
    [12] PUGH D G.Combustion characterisation of compositionally dynamic steelworks gases[D]. Wales Cardiff,UK:Cardiff University,2013.
    [13] 吕鑫,胡二江,彭成, 等. 氢气/氧气/稀释气混合气高温高压下层流燃烧速度的测量[J]. 航空动力学报,2017,32(7):1599-1604. LÜ Xin,HU Erjiang,PENG Cheng,et al.Measurements on laminar burning velocities of hydrogen/oxygen/diluents at elevated pressure and temperature[J]. Journal of Aerospace Power,2017,32(7):1599-1604.(in Chinese)
    [14] FRANKEL M L, SIVASHINSKY G I. On quenching of curved flames[J]. Combustion Science and Technology, 1984,40(5/6):257-268.
    [15] CHEN Zheng.On the extraction of laminar flame speed and Markstein length from outwardly propagating spherical flames[J].Combustion and Flame,2011,158(2):291-300.
    [16] 汤成龙,张旭辉,司占博, 等. 甲烷/乙烷-空气预混层流燃烧特性试验和数值模拟研究[J]. 内燃机工程,2016,37(1):83-88. TANG Chenglong,ZHANG Xuhui,SI Zhanbo,et al.Experimental and numerical investigation on the laminar flame characteristics of CH4/C2H6-air mixture[J]. Chinese Internal Combustion Engine Engineering,2016,37(1):83-88.(in Chinese)
    [17] 胡二江. 天然气-氢气混合燃料结合EGR的发动机和预混层流燃烧研究[D].西安:西安交通大学,2010. HU Erjiang.Study on engine and premixed laminar combustion fueled with natural gas-hydrogen blends combined with EGR[D].Xi'an:Xi'an Jiaotong University,2010.(in Chinese)
    [18] 汤成龙,司占博,张旭辉, 等. 稀释气对高甲烷含量天然气燃烧特性的影响[J].西安交通大学学报,2015,49(9):41-46. TANG Chenglong,SI Zhanbo,ZHANG Xuhui,et al.Effects of diluents on the combustion characteristics of natural gas with high methane content[J].Journal of Xi'an Jiaotong University,2015,49(9):41-46.(in Chinese)
