推力协同的大柔性飞行器纵向姿态控制

雷灏; 陈柏屹; 刘燕斌; 陆宇平

doi:10.13224/j.cnki.jasp.20200457

推力协同的大柔性飞行器纵向姿态控制

doi: 10.13224/j.cnki.jasp.20200457

1.
南京航空航天大学自动化学院，南京 211106
2.
南京航空航天大学航天学院，南京 211106

基金项目: 国家自然科学基金（11572149，51675264）；江苏省博士后科研资助计划（2019K286）；江苏省基础研究计划青年基金（BK20200437）；中国博士后面上基金（2020M681586）

详细信息

作者简介:
雷灏（1990-），女，博士生，主要从事大柔性飞行器建模与控制研究。

中图分类号: V249.1;TP273
计量
- 文章访问数: 315
- HTML浏览量: 90
- PDF量: 91
- 被引次数: 0
出版历程
- 收稿日期: 2020-10-29
- 刊出日期: 2021-10-28

Longitudinal attitude control for very flexible aircraft with thrust cooperation

1.
College of Automation Engineering，Nanjing University of Aeronautics and Astronautics，Nanjing 211106，China
2.
College of Astronautics，Nanjing University of Aeronautics and Astronautics，Nanjing 211106，China

摘要

摘要: 为了研究大柔性飞行器飞行/结构耦合动力学特性，提出了改进的面向控制的大柔性飞行器多体模型，开展了大柔性飞行器纵向动力学耦合特性分析与推力协同下纵向姿态控制律设计。采用二面角动态近似描述大柔性飞行器结构动力学特征，并推导了纵向耦合动力学模型。根据改进模型在配平点处的线性化模型，分析了飞行/结构耦合系统的纵向稳定性与结构变形量之间的关系。针对大柔性飞行器姿态稳定与跟踪，设计了纵向姿态控制器。与常规飞行器相比，大柔性飞行器飞行过程中会发生大变形，当载荷较大时，配平构型近似“U”形，此时纵向动力学具有长周期不稳定的特征。分析结果表明：大柔性飞行器各模态之间的耦合程度随着变形的增大而增大。此外，纵向姿态控制需要升降舵与推力协同控制速度和俯仰角并且考虑结构动力学的影响，否则飞行/结构的耦合作用会导致姿态跟踪误差衰减缓慢甚至发散。
- 大柔性飞行器 /
- 多体模型 /
- 耦合飞行动力学 /
- 纵向姿态控制 /
- 速度控制 /
- 协同控制
Abstract: The improved multi-body model of very flexible aircraft was proposed to analyse the flight/structure coupled dynamics characteristics of very flexible aircraft,the longitudinal dynamics characteristics of very flexible aircraft were studied and the longitudinal attitude controller was designed.The dynamics of dihedral angle was used to approximate the structural dynamics characteristics of very flexible aircraft,and the coupled longitudinal dynamics model was derived.The improved model was trimmed under different load conditions,and the relationship between the stability and deformation of the system was analyzed according to the linearized model at the equilibrium point.The longitudinal attitude controller was designed for attitude stabilization and tracking of very flexible aircraft.Compared with conventional aircrafts,large deformation occurs during the flight of very flexible aircraft.When the load was large,the trimmed configuration was approximately “U” shaped,and the longitudinal phugoid period was unstable.The results showed that as the deformation increased,the coupling between the modes increased.The longitudinal attitude control of very flexible aircraft needed to control the velocity at the same time and takes the coupled structure dynamics into account,otherwise,due to the coupling effect between structure and flight dynamics,the system will even be divergent.
- very flexible aircraft /
- multi-body model /
- coupled flight dynamics /
- longitudinal attitude control /
- velocity control /
- cooperative control

HTML

参考文献(22)

[1]	张健，张德虎.高空长航时太阳能无人机总体设计要点分析[J].航空学报，2016，37（增刊1）:S1-S7.
[2]	GIBSON T，ANNASWAMY A，LAVRETSKY E.Modeling for control of very flexible aircraft[R].AIAA 2011-6202,2011.
[3]	NOLL T E，BROWN J M，PEREZ-DAVIS M E，et al.Investigation of the helios prototype aircraft mishap：Volume Ⅰ mishap report[R].NASA Report 64317，2004.
[4]	王伟.太阳能无人机非线性气动弹性及飞行力学研究[D].西安：西北工业大学，2015.
[5]	PATIL M J，HODGES D H.Flight dynamics of highly flexible flying wings[J].Journal of Aircraft，2006，43（6）:1790-1798.
[6]	CHANG C S，HODGES D H，PATIL M J.Flight dynamics of highly flexible aircraft[J].Journal of Aircraft，2008，45（2）:538-545.
[7]	RAGHAVAN B，PATIL M J.Flight dynamics of high aspect-ratio flying wings:effect of large trim deformation[J].Journal of Aircraft，2009，46（5）:1808-1812.
[8]	SU W，CESNIK C E S.Dynamic response of highly flexible flying wings[J].AIAA Journal，2011，49（2）:324-339.
[9]	CESNIK C E S，SU W.Nonlinear aeroelastic modeling and analysis of fully flexible aircraft[R].AIAA-2005-2169，2005.
[10]	SU W，CESNIK C E S.Strain-based geometrically nonlinear beam formulation for modeling very flexible aircraft[J].International Journal of Solids and Structures，2011，48（16/17）:2349-2360.
[11]	O'ROURKE I，KOLMANOVSKY I，GARONE E，et al.Explicit reference governor for constrained maneuver and shape control of a seven-state multibody aircraft[R].AIAA 2020-1830，2020.
[12]	张勇，陆宇平，刘燕斌，等.高超声速飞行器控制一体化设计[J].航空动力学报，2012，27（12）:2724-2732.
[13]	肖地波，陆宇平，姚克明，等.高超声速飞行器推进系统建模[J].航空动力学报，2015，30（4）:944-951.
[14]	张勇.面向控制的高超声速飞行器一体化设计[D].南京：南京航空航天大学，2011.
[15]	AFONSO F，VALE J，OLIVEIRA E，et al.A review on non-linear aeroelasticity of high aspect-ratio wings[J].Progress in Aerospace Sciences，2017，89:40-57.
[16]	曾惠华，刘钟坤.大展弦比机翼几何非线性颤振风洞试验研究[J].装备环境工程，2019，16（1）:68-72.
[17]	向锦武，张雪娇，赵仕伟，等.大展弦比复合材料机翼研究进展[J].哈尔滨工业大学学报，2017，49（10）:1-14.
[18]	PATIL M J，HODGES D H，CESNIK C E S.Characterizing the effects of geometrical nonlinearities on aeroelastic behavior of high-aspect-ratio wings[C]∥Proceedings of International Forum on Aeroelasticity and Structural Dynamics.Williamsburg，Virginia，US：NASA,1999:1-10.
[19]	RAGHAVAN B.Flight dynamics and control of highly flexible flying-wings[D].Blacksburg，US:Virginia Polytechnic Institute and State University，2009.
[20]	王子安，龚正，陈永亮，等.复合翼无人机加速段纵向飞行特性分析与控制设计[J].航空动力学报，2019，34（10）:2177-2190.
[21]	SKOGESTAD S，POSTLETHWAITE I.Multivariable feedback control:analysis and design[M].Chichester，UK:John Wiley & Sons Inc，1996.
[22]	吴森堂.飞行控制系统[M].北京：北京航空航天大学出版社，2013.
