脉冲爆震燃气膨胀过程及能量转换难易度评价方法

李晓丰; 肖俊峰; 胡孟起; 王玮; 王峰

doi:10.13224/j.cnki.jasp.20200474

脉冲爆震燃气膨胀过程及能量转换难易度评价方法

doi: 10.13224/j.cnki.jasp.20200474

西安热工研究院有限公司燃气轮机技术部, 西安 710032

基金项目:

陕西省自然科学基金（2020JQ-996）

详细信息

作者简介:
李晓丰(1985-),男,高级工程师,博士,主要从事燃气轮机燃烧技术研究。

中图分类号: V231.2
计量
- 文章访问数: 118
- HTML浏览量: 2
- PDF量: 184
- 被引次数: 0
出版历程
- 收稿日期: 2020-11-06
- 刊出日期: 2021-08-28

Pulse detonation gas expansion process and evaluation method of energy conversion difficulty degree

Gas Turbine Technology Department, Xi'an Thermal Power Research Institute Company Limited, Xi'an 710032, China

摘要

摘要: 为了提高脉冲爆震燃气的能量转换效率，分析了脉冲爆震燃气在涡轮内的膨胀过程，建立了评价爆震燃气能量转换难易度计算方法，并基于脉冲爆震燃烧室与轴流涡轮匹配工作数值模型，采用涡轮效率对燃气能量转换难易度计算方法进行了验证，结果表明： ①爆震波膨胀过程，爆震燃气在涡轮静叶内会产生热壅塞现象，并往上游形成前传压缩波； ②涡轮内爆震燃气的膨胀主要分一次膨胀、过度膨胀和二次膨胀三个阶段，爆震燃气在涡轮内的焓降主要发生在一次膨胀和二次膨胀阶段，在过度膨胀阶段，燃气在涡轮内做负功； ③当量比为0.72、0.89和1.00三种计算工况的燃气能量转换难易度分别为0.396、1.000和0.803，对应的涡轮效率分别为0.473 6、0.597 2和0.570 3，验证了燃气能量转换难易度计算方法的准确性。
- 脉冲爆震燃烧室 /
- 爆震波 /
- 爆震燃烧 /
- 能量转换 /
- 膨胀
Abstract: In order to improve the energy conversion efficiency of pulse detonation gas, the expansion process of pulse detonation gas in the turbine was analyzed, and a calculation method for evaluation method of energy conversion difficulty degree was established. Based on the numerical model of the pulse detonation combustor with the axial turbine, the turbine efficiency was adopted to verify the calculation method for gas energy conversion difficulty degree. The results showed that:(1) in the process of detonation wave expansion,the thermal choking phenomenon appeared in the turbine static vane and formed a back-propagating compression wave.(2) The expansion of the detonation gas in the turbine was mainly comprised of primary expansion, over-expansion and secondary expansion; the enthalpy drop of the detonation gas in the turbine mainly occurred in the primary and secondary expansion stages. In the over-expansion stage,the gas did negative work in the turbine.(3) The gas energy conversion difficulty degrees for the three calculation conditions with equivalent ratios of 0. 72, 0. 89 and 1. 00 were 0. 396, 1. 000 and 0. 803, respectively, and the turbine efficiency for the three calculation conditions was 0. 473 6, 0. 597 2 and 0. 570 3, respectively, verifying the accuracy of the calculation method for gas energy conversion difficulty degree.
- pulse detonation combustor /
- detonation wave /
- detonation combustion /
- energy conversion /
- expansion

HTML

参考文献(19)

[1]	严传俊,范玮. 脉冲爆震发动机原理及关键技术[M]. 西安:西北工业大学出版社,2005.
[2]	PETTERS D P,FELDER J L.Engine system performance of pulse detonation concepts using the npss program[R]. AIAA 2002-3910,2002.
[3]	ENDO T,YATSUFUSA T,TAKI S,et al.Thermodynam-ic analysis of the performance of a pulse detonation turbine engine[J]. Science and Technology of Energetic Materials, 2004,65(4):103-110.
[4]	ENDO T, YATSUFUSA T, TAKI S, et al. A study on pulse detonation turbine and steam turbine combined cycle[J].Ryutai Rikigaku Koenkai Koenshu,2005,37:143-146.
[5]	ANDRUS I Q,KING P I.Evaluation of a high bypass turbofan hybrid utilizing a pulsed detonation combustor[R].AIAA 2007-5074,2007.
[6]	CARLOS X, FAKHRE A, OLIVIER P, et al. Analytical model for the performance estimation of pre-cooled pulse detonation turbofan engines[R]. ASME Paper GT2017-63776, 2017.
[7]	GIULIANI F, LANG A, IRANNEZHAD M, et al. Pulse detonation as an option for future innovative gas turbine com-bustion technologies a concept assessment[R].Nice,France:Congress of the International Council of the Aeronautical Sciences (ICAS2010),2010.
[8]	李晓丰,肖俊峰,王玮,等. 基于爆震燃烧的燃气轮机理想热力循环分析[J].西北工业大学学报, 2016,34(1):112-117. LI Xiaofeng, XIAO Junfeng, WANG Wei, et al. Ideal thermodynamic cycle analysis of gas turbine based on detonation combustion[J]. Journal of Northwestern Polytechnical University,2016,34(1):112-117.(in Chinese)
[9]	李晓丰,肖俊峰,王玮,等. 爆震燃气轮机的变比热容热力循环性能[J].航空动力学报, 2016,31(2):369-376. LI Xiaofeng, XIAO Junfeng, WANG Wei, et al.Thermodynamic cycle performance of detonation gas turbine with variable specific heat capacity[J]. Journal of Aerospace Power, 2016,31(2):369-376.(in Chinese)
[10]	邓君香,郑龙席,严传俊,等. 脉冲爆震燃烧室与涡轮组合的性能试验研究[J]. 西北工业大学学报, 2009, 27(3):300-304. DENG Junxiang, ZHENG Longxi, YAN Chuanjun, et al. Studying experimentally performances of a pulse detonation combustor (PDC) integrated with a turbine[J]. Journal of Northwestern Polytechnical University,2009, 27(3):300-304.(in Chinese)
[11]	邓君香,严传俊,郑龙席, 等. 装有脉冲爆震主燃烧室的燃气涡轮发动机热力性能计算[J]. 西北工业大学学报,2008, 26(3):362-367. DENG Junxiang, YAN Chuanjun, ZHENG Longxi, et al. Calculating performance of gas turbine engine with embedded PDC(pulse detonation combustor)[J].Journal of North-western Polytechnical University, 2008, 26(3):362-367.(in Chinese)
[12]	AYAKA N, KAZUAKI I, TAKAYUKI K, et al. Aerodynamic effect of turbine blade geometry in pulse detonation combustor[R].AIAA 2007-1176,2007.
[13]	LEE J K, TAN C S, SIRAKOV B T, et al. Performance metric for turbine stage under unsteady pulsating flow environment[J].Journal of Engineering for Gas Turbines Power, 2017,139(7):072606.1-072606.7.
[14]	LI Xiaofeng,ZHENG Longxi,QIU Hua,et al.Experimental investigations on the power extraction of a turbine driven by a pulse detonation combustor[J].Chinese Journal of Aeronautics,2013,26(6):1353-1359.
[15]	李晓丰,郑龙席,邱华, 等. 脉冲爆震涡轮发动机原理性试验研究[J].实验流体力学, 2013,27(6):1-5. LI Xiaofeng,ZHENG Longxi,QIU Hua,et al.Experimental study on the principle of pulse detonation turbine engine[J]. Journal of Experiments in Fluid Mechanics,2013,27(6):1-5. (in Chinese)
[16]	李晓丰,郑龙席,邱华. 脉冲爆震涡轮发动机气动阀特性数值模拟研究[J].西北工业大学学报,2013, 31(6):935-939. LI Xiaofeng, ZHENG Longxi, QIU Hua. Numerical simulation study on pneumatic valve pulse detonation turbine engine[J]. Journal of Northwestern Polytechnical University, 2013, 31(6):935-939.(in Chinese)
[17]	李晓丰,郑龙席,邱华,等. 两相脉冲爆震涡轮发动机原理性试验研究[J].航空动力学报,2013,28(12):2731-2736. LI Xiaofeng, ZHENG Longxi, QIU Hua, et al.Principle experiments on two phase pulse detonation turbine engine[J]. Journal of Aerospace Power,2013,28(12):2731-2736.(in Chinese)
[18]	李晓丰,肖俊峰,王玮, 等. 脉冲爆震燃烧室出口燃气能量分布特性[J].航空动力学报,2020,35(11):2356-2363. LI Xiaofeng,XIAO Junfeng,WANG Wei,et al.Energy distribution characteristics of gas at the outlet of a pulse detonation combustor[J]. Journal of Aerospace Power, 2020, 35(11):2356-2363.(in Chinese)
[19]	刘新宪,朱道立. 选择与判断-AHP层次分析法决策[M]. 上海:上海科学普及出版社,1990.
