基于多缝放气自适应流动控制的超声速进气道数值研究

温玉芬; 张晨凯; 张正; 高晶晶

doi:10.13224/j.cnki.jasp.20200487

基于多缝放气自适应流动控制的超声速进气道数值研究

doi: 10.13224/j.cnki.jasp.20200487

1.
中国航天科技集团公司中国运载火箭技术研究院，北京 100076
2.
中国航天科技集团公司中国航天空气动力技术研究院，北京 100074

详细信息

作者简介:
温玉芬（1986-），女，高级工程师，硕士，主要从事内外流空气动力学研究。

中图分类号: V211.3
计量
- 文章访问数: 675
- HTML浏览量: 154
- PDF量: 260
- 被引次数: 0
出版历程
- 收稿日期: 2020-11-15
- 刊出日期: 2021-10-28

Numerical investigation on adaptive flow-control of supersonic inlet based on air-bleeding multi-slots

1.
China Academy of Launch Vehicle Technology，China Aerospace Science and Technology Corporation，Beijing 100076，China
2.
China Academy of Aerospace Aerodynamics，China Aerospace Science and Technology Corporation，Beijing 100074，China

摘要

摘要: 针对一种超声速混压式二元进气道，设计了多缝放气自适应流动控制方案，采用数值方法分别对有放气措施和无放气措施的进气道特性进行仿真对比分析，获得了放气对进气道自起动能力、临界性能及阻力特性的影响规律。结果表明：在进气道内收缩段开设系列放气缝，可以在保证进气道自起动能力的情况下大幅提升其临界性能，同时该种流动控制措施可通过唇口斜激波及其反射激波的移动实现放气量的自适应调节。对比分析发现，所设计的多缝放气流动控制方案，在设计状态下进气道的抗反压能力和总压恢复系数较无放气措施方案分别提高12.15%和7.11%，流量损失和阻力增加仅为0.71%和2.7%；巡航状态下，阻力增幅进一步减小，仅为1%。
- 超声速进气道 /
- 流动控制 /
- 放气 /
- 总压恢复系数 /
- 阻力
Abstract: An adaptive flow-control method based on air-bleeding multi-slots for a supersonic mixed-compression two-dimensional inlet was brought forward.Two inlet models with/without air-bleeding method were designed separately and a comparison of the inlet performance was conducted with numerical method.Effects of air-bleeding on the self-starting ability，critical performance and resistance characteristic were attained.Results indicated that setting a series of air-bleeding slots in the internal contraction region of the inlet can obviously improve the critical performance of the inlet without deterioration to its self-starting characteristics.Meanwhile，bleeding mass flow can be self-regulated with the movement of the incident shock of the lip and its reflected shock.Compared with the inlet without flow-control method，the maximum backpressure and the total pressure recovery coefficient of the inlet was raised by 12.15% and 7.11% separately at design operation by means of air-bleeding，with a cost of only 0.71% reduction of mass flow and 2.7% resistance increment.Moreover，the increment of resistance can be further reduced to only 1% at cruise operation.
- supersonic inlet /
- flow-control /
- air-bleeding /
- total pressure recovery coefficient /
- resistance

HTML

参考文献(28)

[1]	WARREN E A,NORMAN D W.A two-dimensional,mixed-compression inlet system design to self-restart at a Mach number of 3.5[J].Journal of Aircraft,1970,7（5）:431-436.
[2]	HAWS R G,NOALL J S,DAINES R L.Computational investigation of a method to compress air fluidcally in supersonic inlets[J].Journal of Spacecraft and Rockets,2001,38（1）:51-59.
[3]	POWELL A G,WELGE H R,TREFNY C J.Low-speed aerodynamic test of an axisymmetric supersonic inlet with variable cowl slot[R].AIAA-1985-1210,1985.
[4]	张华军,梁德旺,郭荣伟.一种组合发动机变几何进气道流场特性研究[J].航空动力学报,2009,24（10）:2201-2207.
[5]	YUSUKE M.Multi-row disk arrangement concept for spike of axisymmetric air inlet[R].AIAA-2004-3407,2004.
[6]	金志光,张堃元.宽马赫数范围高超声速进气道伸缩唇口式变几何方案[J].宇航学报,2010,31（5）:1503-1510.
[7]	张林,张堃元,金志光,等.高超声速二元进气道顶板移动变几何方案数值模拟[J].航空学报,2012,33（10）:1800-1808.
[8]	BANGERT L H,SANTMAN D M,HORIE G,et al.Some effects of cruise speed and engine matching on supersonic inlet design[J].Journal of Aircraft,1982,19（1）:58-64.
[9]	GARY J H,GREGORY E S.Supersonic-inlet boundary-layer bleed flow[J].AIAA Journal,1996,34（4）:778-785.
[10]	JAN S,JOSEPH L S.Experimental evaluation of an analytically derived bleed system for a supersonic inlet[J].Journal of Aircraft,1976,13（10）:792-797.
[11]	AKIRA F,NOBUO N,KEISUKE S.Numerical investigation of supersonic inlet with realistic bleed and bypass systems[J].Journal of Propulsion and Power,1992,8（4）:857-861.
[12]	HERRMANN D,BLEM S,GüLHAN A.Experimental study of boundary-layer bleed impact on ramjet inlet performance[J].Journal of Propulsion and Power,2011,27（6）:1186-1195.
[13]	SHNEIDER M N,MACHERET S O,MILES R B.Nonequilibrium magnetohydrodynamic control of scramjet inlets[R].AIAA-2002-2251,2002.
[14]	SHEIKIN E G,KURANOV A L.MHD controlled inlet for scramjet with various configurations of magnetic field[R].AIAA-2004-1195,2004.
[15]	JAMES C T,MICHAEL K S.Application of inlet injection to a three-dimensional scramjet at Mach 8[J].AIAA Journal,2010,48（4）:829-838.
[16]	冯喜平,林志远,郑亚,等.固冲发动机射流控制可调进气道研究[J].固体火箭技术,2010,33（4）:396-400.
[17]	冯喜平,林志远,郑亚,等.基于燃气射流控制的可调进气道数学模型研究[J].固体火箭技术,2010,33（6）:641-645.
[18]	游进,夏智勋,刘冰,等.二元混压式进气道窄缝射流调节结构参数设计[J].航空动力学报,2012,27（7）:1562-1570.
[19]	谭慧俊，陈智，李光胜.基于激波形状控制的定几何高超声速可调进气道概念及初步验证[J].中国科学 E辑:技术科学,2007,37（11）:1469-1479.
[20]	李程鸿,谭慧俊,孙姝,等.流体式高超声速可调进气道流动机理及工作特性分析[J].宇航学报,2011,32（12）:2613-2621.
[21]	张悦,谭慧俊,张启帆,等.一种进气道内激波/边界层干扰控制的新方法及其流动机理[J].宇航学报,2012,33（2）:265-274.
[22]	程代姝,张悦,高婉宁,等.结合局部次流循环的变几何轴对称进气道研究[J].推进技术,2019,40（9）:2003-2011.
[23]	刘志伟,马高建,崔金平.附面层吸除对二元混压式进气道起动影响分析[J].弹箭与制导学报,2009,29（3）:149-152.
[24]	贺永杰,马高建,刘志伟.通过附面层泄除提高定几何混压式进气道性能的方法研究[J].航空兵器,2010（2）:28-31.
[25]	翁小侪,郭荣伟.一种二元定几何混压式超声速进气道流场控制概念研究[J].航空动力学报,2012,27（11）:2492-2498.
[26]	WAN D W,GUO R W.Experimental investigation of a fixed-geometry two-dimensional mixed-compression supersonic inlet with sweep-forward highlight and bleed slot in an inverted “X”-typer layout[J].Chinese Journal of Aeronautics,2007,4（20）:304-312.
[27]	麻肖妃,谢旅荣,郭荣伟.双下侧布局带泄流腔二元进气道试验[J].航空动力学报,2010,25（8）:1818-1824.
[28]	SCHüLEIN E.Skin-friction and heat flux measurements in shock/boundary-layer interaction flows[J].AIAA Journal,2006,44（8）:1732-1741.
