Dynamic performance of radial magnetic-gas bearing system
-
摘要: 为探究磁轴承失效时能否减轻转子跌落带来的损害，将人字槽径向动压气体轴承引入磁轴承转子系统，研究磁气组合轴承对系统动态性能的影响和动压气体轴承的支承特性。采用有限差分法和小扰动法求解气膜厚度方程和雷诺方程，研究动压气体轴承的静动态特性。对磁轴承电磁力进行了分析，采用磁轴承不完全微分PID（比例-积分-微分）控制策略，对系统进行了理论模态分析和试验模态分析，完成了系统高速旋转试验，测试了动压气体轴承在不同偏心率和转速下的承载力。结果表明，引入动压气体轴承可提高系统的动态性能，在磁轴承失效造成高速转子跌落瞬间，偏心率趋近于1，两个径向动压气体轴承能够产生较大承载力，减轻转子跌落造成的损害。
-
关键词:
- 磁轴承 /
- 人字槽径向动压气体轴承 /
- 雷诺方程 /
- 不完全微分PID控制 /
- 模态分析
Abstract: In order to explore whether the damage caused by rotor drop can be reduced in case of the failure of magnetic bearing，the herringbone groove radial dynamic pressure gas bearing was introduced into the magnetic bearing rotor system，and the influence of the magnetic-gas bearing on the dynamic performance of the system and the support characteristics of the dynamic pressure gas bearing were studied.The finite difference method and small disturbance method were used to solve the film thickness equation and Reynolds equation，and the static and dynamic characteristics of the dynamic pressure gas bearing were studied.The electromagnetic force of the magnetic bearing was analyzed.The incomplete differential PID （proportion integration differentiation） control strategy of the magnetic bearing was used.The theoretical and test modal analysis of the system was performed.The high-speed rotation test of the system was completed.The bearing capacity of dynamic pressure gas bearing under different eccentricity and rotating speed was tested.Results showed that introduction of dynamic pressure gas bearings can improve the dynamic performance of the system.At the moment when the high-speed rotor dropped due to the failure of the magnetic bearing，the eccentricity was close to 1.The two radial dynamic pressure gas bearings can produce larger bearing capacity and reduce the drop caused by the rotor damage. -
[1] SCHWEITZER G,MASLEN E H.磁悬浮轴承：理论、设计及旋转机械应用[M].徐旸，张剀，赵雷，译.北京：机械工业出版社,2012. [2] XIE Zhenyu,YU Kun,WEN Liantang,et al.Characteristics of motorized spindle supported by active magnetic bearings[J].Chinese Journal of Aeronautics,2014,27（6）:1619-1624. [3] 俞成涛,徐龙祥,金超武.自动消除主动磁悬浮轴承系统保护间隙机构的运动学分析[J].航空学报,2015,36（7）:2485-2496. [4] 李国畅.自消除间隙保护轴承支承特性研究[D].南京：南京航空航天大学,2019. [5] 黄平.润滑数值计算方法[M].北京：高等教育出版社，2012:8-11. [6] 温诗铸,黄平,田煜.摩擦学原理[M].北京:清华大学出版社,2018:332-336. [7] 陆俊杰.新型浮动式柱面微槽气膜密封的动力润滑特性研究[D].兰州：兰州理工大学,2018. [8] 姚绍明.气体复合润滑技术[M].北京:国防工业出版社,2008:1-43. [9] 祝汉婷.人字槽动压滑动轴承-转子系统的动态特性研究[D].天津：天津大学,2012. [10] BAI Shaoxian,PENG Xudong,LI Yefeng,et al.Gas lubrication analysis method of step-dimpled face mechanical seals[J].Journal of Tribology,2012，134（1）:011702.1-011702.9. [11] TOMIOKA J,MIYANAGA N.Stability threshold of herringbone grooved aerodynamic journal bearings with external stiffness and damping elements[J].Journal of Advanced Mechanical Design Systems and Manufacturing,2013,7（6）:876-887. [12] WANG Chengchi.Theoretical and nonlinear behavior analysis of a flexible rotor supported by a relative short herringbone-grooved gas journal-bearing system[J].Physica D：Nonlinear Phenomena,2008,237（18）:2282-2295. [13] 赵广,刘盼年,于贺春,等.静压气体轴承气膜力及其与转子耦合动力学特性研究[J].航空动力学报,2012,27（2）:472-480. [14] 王云飞.气体润滑理论与气体轴承设计[M].北京：机械工业出版社,1999:45-69. [15] 任佟,陈东菊,李彦生,等.气体轴承的动态特性分析及实验研究[J].西安交通大学学报,2019,53（8）:68-75. [16] 张广辉.高速动静压混合气体轴承转子系统动力学特性研究[D].哈尔滨：哈尔滨工业大学,2010. [17] 戚社苗.弹性箔片气体轴承的完全气弹耦合解[D].西安：西安交通大学,2005. [18] 费钟秀.复杂转子耦合系统有限元建模及其动力特性研究[D].杭州：浙江大学,2013. [19] 袁惠群.转子动力学分析方法[M].北京:冶金工业出版社,2017:1-90. [20] 朱祖超,翟璐璐.离心泵非定常流动激励转子动力学[M].北京:机械工业出版社,2019:28-96. [21] 朱益利,金超武,徐龙祥.保护轴承系统中弹性环不同安装位置对转子跌落后动力学响应的影响[J].航空动力学报,2012,27（7）:1671-1680. -
