油滴与铝合金壁面的碰撞试验

马兴裕; 陈薄; 周超

doi:10.13224/j.cnki.jasp.20200495

油滴与铝合金壁面的碰撞试验

doi: 10.13224/j.cnki.jasp.20200495

西南科技大学制造科学与工程学院制造过程测试技术教育部重点实验室，四川绵阳 621010

基金项目: 国家自然科学基金（51475395）；制造过程测试技术教育部重点实验室开放基金（14tdzk04）

详细信息

作者简介:
马兴裕（1995-），男，硕士生，主要研究方向为航空发动机润滑系统的分析与设计。

通讯作者:
陈薄（1978-），男，副教授，博士，主要研究方向为润滑与密封技术、现代机械设计理论与方法等。E-mail：chenbo@mail.nwpu.edu.cn

中图分类号: V233.4
计量
- 文章访问数: 366
- HTML浏览量: 112
- PDF量: 179
- 被引次数: 0
出版历程
- 收稿日期: 2020-11-19
- 刊出日期: 2021-09-28

Experiment of oil droplet impacting on aluminium alloy surface

Key Laboratory of Testing Technology for Manufacturing Process，Ministry of Education，School of Manufacturing Science and Engineering， Southwest University of Science and Technology，Mianyang Sichuan 621010，China

摘要

摘要: 机械零部件喷油或滴油润滑方式下油滴与零件表面碰撞后形成的沉积油膜流动特性决定着零件表面润滑油膜的分布特征和零件的润滑状态，对于这一润滑现象的深入理解需要对油滴与金属固体壁面碰撞及其后沉积油膜的流动铺展行为进行研究。建立了油滴与铝合金壁面碰撞的试验装置，采用高速相机拍摄了油滴与铝合金壁面碰撞及其后沉积油膜的流动铺展与形貌演化过程，分析了碰撞油滴的变形及沉积油膜的铺展与回缩历程，探讨了碰撞条件和润滑油黏度对沉积油膜流动铺展特性的影响。结果表明：与铝合金壁面碰撞后形成的沉积油膜铺展较快而回缩较为缓慢，没有明显的整体回缩现象和振荡过程。较小碰撞角度下，铺展初期油滴与壁面之间存在轻微滑移现象，受重力和铺展能量的作用，铺展后期油膜发生断裂并溅射离开壁面，但没有二次油滴生成。前铺展因子随着碰撞角度的减小和碰撞速度的增加而增大，后铺展因子则随着两者的增大而增大。油滴直径对前、后铺展因子的影响不太明显。
- 油滴 /
- 铝合金壁面 /
- 碰撞 /
- 流动铺展 /
- 沉积油膜
Abstract: The lubrication oil film on the surface of mechanical parts under spray or drip lubrication condition was influenced by the deposited film resulted from the impact of oil droplet with part surface.To understand the complex lubrication phenomena,it is necessary to study the impact behavior of oil droplet with metal solid substrate and the spreading process of deposited film.Therefore,an experimental apparatus was built to investigate the impact outcome of single oil droplet with aluminum alloy surface.High-speed photography was used to capture the oil droplet dynamical morphology and the spreading process of the subsequent film.The oil droplet deformation and the histories of spreading and recoiling of the film were analyzed qualitatively,and the effects of experimental condition and oil viscosity were discussed quantitatively.The experimental results showed that the deposited film spread outwards quickly, recoiled inwards very slowly, and reached eventually steady state.The whole film retraction and oscillation were not observed in the recoiling process.At lower impact angle,the slight slip between oil droplet and surface was found in the initial spreading stage, and due to the effects of gravity and spreading energy,finally,the film disintegrated without ejection of secondary oil droplets.The front spread factor increased with increasing impact velocity and decreasing impact angle,and the back spread factor increased with the increase of impact velocity and impact angle.The effect of oil droplet diameter on the front and back spread factors was insignificant.
- oil droplet /
- aluminum alloy surface /
- impact /
- spread /
- deposited film

HTML

参考文献(24)

[1]	GUNJAL P R,RANADE V V,CHAUDHARI R V.Dynamics of drop impact on solid surface:experiments and VOF simulations[J].American Institute of Chemical Engineers Journal,2005,51（1）:59-78.
[2]	CAVIEZEL D,NARAYANAN C,LAKEHAL D.Adherence and bouncing of liquid droplets impacting on dry surfaces[J].Microfluidics and Nanofluidics,2008,5（4）:469-478.
[3]	DIAZ A J,ORTEGA A.Gas-assisted droplet impact on a solid surface[J].Journal of Fluids Engineering,2016,138（8）:1-9.
[4]	PATIL N D,GADA V H,SHARMA A,et al.On dual-grid level-set method for contact line modeling during impact of a droplet on hydrophobic and superhydrophobic surfaces[J].International Journal of Multiphase Flow,2016,81:54-66.
[5]	JIANG Mengcheng,ZHOU Biao,WANG Xichen.Comparisons and validations of contact angle models[J].International Journal of Hydrogen Energy,2018,43（12）:6364-6378.
[6]	周超,古忠涛,陈薄,等.油滴/金属壁面正碰撞的油膜动力学特性[J].航空动力学报,2019,34（7）:1607-1614.
[7]	GANESAN S.Simulations of impinging droplets with surfactant-dependent dynamic contact angle[J].Journal of Computational Physics,2015,301:178-200.
[8]	RANGE K,FEUILLEBOIS F.Influence of surface roughness on liquid drop impact[J].Journal of Colloid and Interface Science,1998,203（1）:16-30.
[9]	RIOBOO R,TROPEA C,MARENGO M.Outcomes from a drop impact on solid surfaces[J].Atomization and Sprays,2001,11（2）:155-165.
[10]	RIOBOO R,MARENGO M,TROPEA C.Time evolution of liquid drop impact onto solid,dry surfaces[J].Experiments in Fluids,2002,33（1）:112-124.
[11]	BAYER I S,MEGARIDIS C M.Contact angle dynamics in droplets impacting on flat surfaces with different wetting characteristics[J].Journal of Fluid Mechanics,2006,558（7）:415-449.
[12]	CROOKS R,COOPER-WHITEZ J,BOGER D V.The role of dynamic surface tension and elasticity on the dynamics of drop impact[J].Chemical Engineering Science,2001,56（19）:5575-5592.
[13]	?IKALO ?,MARENGO M,TROPEA C,et al.Analysis of impact of droplets on horizontal surfaces[J].Experimental Thermal and Fluid Science,2002,25（7）:503-510.
[14]	?IKALO ?,TROPEA C,GANI? E N.Impact of droplets onto inclined surfaces[J].Journal of Colloid and Interface Science,2005,286（2）:661-669.
[15]	?IKALO ?,TROPEA C,GANI? E N.Dynamic wetting angle of a spreading droplet[J].Experimental Thermal and Fluid Science,2005,29（7）:795-802.
[16]	?IKALO ?,GANI? E N.Phenomena of droplet–surface interactions[J].Experimental Thermal and Fluid Science,2006,31（2）:97-110.
[17]	PAN K L,TSENG K C,WANG C H.Breakup of a droplet at high velocity impacting a solid surface[J].Experiments in Fluids,2010,48（1）:143-156.
[18]	TANG Chenglong,QIN Mengxiao,WENG Xinyan,et al.Dynamics of droplet impact on solid surface with different roughness[J].International Journal of Multiphase Flow,2017,96:56-69.
[19]	ZHANG Rui,HAO Pengfei,ZHANG Xiwen,et al.Supercooled water droplet impact on superhydrophobic surfaces with various roughness and temperature[J].International Journal of Heat and Mass Transfer,2018,122:395-402.
[20]	方龙,陈国定,刘登.喷射油滴沉积油膜的流动铺展特性研究[J].机械工程学报,2016,52（23）:160-167.
[21]	RIOS-LOPEZ I,EVGENIDIS S,KOSTOGLOU M,et al.Effect of initial droplet shape on the tangential force required for spreading and sliding along a solid surface[J].Colloids and Surfaces A：Physicochemical and Engineering Aspects,2018,549:164-173.
[22]	梁刚涛,沈胜强,郭亚丽,等.实验观测液滴撞击倾斜表面液膜的特殊现象[J].物理学报,2013,62（8）:084707.1-084707.7.
[23]	FUJIMOTO H,DIO R,TAKUDA H.An experimental study on the oblique collisions of water droplets with a smooth hot solid[J].Journal of Fluids Engineering,2012,134（7）:071301.1-071301.12.
[24]	PALACIOS J,HERNáNDEZ J,GóMEZ P,et al.Experimental study of splashing patterns and the splashing/deposition threshold in drop impacts onto dry smooth solid surfaces[J].Experimental Thermal and Fluid Science,2013,44:571-582.
