安装误差下弧齿锥齿轮齿面6<i>σ</i>稳健优化设计

陈鹏; 董红涛; 王三民; 李飞; 何前进; 李义之

doi:10.13224/j.cnki.jasp.20200506

安装误差下弧齿锥齿轮齿面6σ稳健优化设计

doi: 10.13224/j.cnki.jasp.20200506

1.
西北工业大学机电学院，西安 710072
2.
中国航空发动机集团有限公司湖南动力机械研究所，湖南株洲 412002

详细信息

作者简介:
陈鹏（1996-），男，硕士生，主要从事弧齿锥齿轮稳健性与精度研究。

中图分类号: V222;TH132.421
计量
- 文章访问数: 455
- HTML浏览量: 222
- PDF量: 188
- 被引次数: 0
出版历程
- 收稿日期: 2020-11-24
- 刊出日期: 2021-09-28

Tooth surface 6σ robust optimization desgin under installation error of spiral bevel gear

1.
School of Mechanical Engineering，Northwestern Polytechnical University，Xi'an 710072，China
2.
Hunan Aviation Powerplant Research Institute，Aero Engine Corporation of China，Zhuzhou Hunan 412002，China

摘要

摘要: 由于航空弧齿锥齿轮传动过程中存在安装误差，其不确定性对齿轮传动中的噪声和稳健性有较大的影响，利用Monte Carlo模拟描述抽样方法与多岛遗传算法对弧齿锥齿轮的2阶接触参数进行设计，将局部综合法和 $6 σ$ 分析法结合形成了弧齿锥齿轮的稳健性优化设计方法，并展开了对安装误差不敏感的稳健性优化设计。结果表明：给定工况下，合理地预设2阶接触参数的取值与容差量可将齿轮传动中安装误差不确定性的稳健性提高至99.9%以上；同时可有效降低弧齿锥齿轮接触印痕、传动误差的灵敏度30%以上，改善弧齿锥齿轮传动的接触性能。验证了文中基于 $6 σ$ 稳健优化设计技术的弧齿锥齿轮稳健性设计方法的可行性。

Abstract: Due to the installation error in the transmission of aviation spiral bevel gears，its uncertainty had a great impact on the noise and robustness of the gear transmission.Monte Carlo simulation was used to describe the sampling method and the multi-island genetic algorithm for spiral bevel gears.The design of the second-order contact parameters was combined with the local synthesis method and the $6 σ$ analysis method to form a robust optimization design method.And a robust optimization design not sensitive to installation errors was developed.The results showed that，under a given working condition， the robustness of the uncertainty of installation error in gear transmission can be improved to more than 99.9% by reasonably presetting the value and tolerance of second-order contact parameters，the sensitivity of contact mark and transmission error can be effectively reduced by more than 30%，and the contact performance of spiral bevel gear transmission can thus be improved.The feasibility of the robust design method for spiral bevel gears based on the $6 σ$ robust optimization design technique in the article was verified.

HTML

参考文献(18)

[1]	BAXTER M L.Effect of misalignment on tooth action of bevel and hypoid gears[R].ASME Paper 61-MD-20,1962.
[2]	LITVIN F L,CHEN J.Computerized simulation of transmission errors and shift of bearing contact for face-milled hypoid gear drive[J].Journal of Mechanical Design,1995,117（6）:262-268.
[3]	LITVIN F L,ZHANG Y.Local synthesis and tooth contact analysis of face-milled spiral bevel gears [R].Chicago: NASA Lewis Research Center,1991.
[4]	SIMON V.Computer simulation of tooth contact analysis of mismatched spiral bevel gears[J].Mechanism and Machine Theory,2007,42（3）:365-381.
[5]	SIMON V.Influence of tooth errors and misalignments on tooth contact in spiral bevel gears[J].Mechanism and Machine Theory,2008,43（10）:1253-1267.
[6]	ARGYRIS J,FUENTES A,LITVIN F L L.Computerized integrated approach for design and stress analysis of spiral bevel gears[J].Computer Methods in Applied Mechanics and Engineering.2002,191（11）:1057-1095.
[7]	蔡香伟.航空弧齿锥齿轮的啮合特性分析及齿面设计研究[D].西安：西北工业大学,2015.
[8]	王小椿,吴序堂.空间点啮合齿面的接触特性对安装误差的敏感性分析[J].西安交通大学学报,1990,24（6）:45-57.
[9]	吴训成，毛世民，吴序堂.点接触齿面在控制误差敏感性条件下的二阶参数设计[J].西安交通大学学报，1999,33（11）:86-89.
[10]	唐进元,雷国伟,杜晋,等.螺旋锥齿轮安装误差敏感性与容差性研究[J].航空动力学报,2009,24（8）:1878-1885.
[11]	唐进元,杜晋.考虑安装误差敏感性的螺旋锥齿轮主动设计方法[J].中国机械工程,2009,20（10）:1197-1201.
[12]	苏进展,方宗德.弧齿锥齿轮误差敏感性优化设计[J].航空动力报,2012,27（1）:183-189.
[13]	苏进展,方宗德.弧齿锥齿轮印痕稳定性优化设计与试验[J].航空动力学报,2012,27（11）:2622-2628.
[14]	西安交通大学机制教研室.弧齿锥齿轮与准双曲线齿轮加工调整原理[M].上海：上海科学技术出版社,1979.
[15]	LITVIN F L.齿轮几何学与应用理论[M].国楷,叶凌云,范琳，译.上海：上海科学技术出版社，2008.
[16]	杨咸启.接触力学理论与滚动轴承设计分析[M].武汉：华中科技大学出版社，2018.
[17]	GUO Fang,FANG Zongde.The statistical analysis of the dynamic performance of a gear system considering random manufacturing errors under different levels of machining precision[J].Proceedings of the Institution of Mechanical Engineers:Part K Journal of Multi-Body Dynamics,2020,234（1）:3-18.
[18]	赵娜.基于 $6 σ$ 理论的稳健优化策略研究[D].沈阳：东北大学,2014.
