重载下可倾瓦推力轴承的热弹流润滑特性分析

冯欣凯; 杨利花

doi:10.13224/j.cnki.jasp.20200514

重载下可倾瓦推力轴承的热弹流润滑特性分析

doi: 10.13224/j.cnki.jasp.20200514

冯欣凯^1,2,3,
杨利花^1,2,3, ,

1.
西安交通大学机械结构强度与振动国家重点实验室，西安 710049
2.
西安交通大学陕西省先进飞行器服役环境与控制重点实验室，西安 710049
3.
西安交通大学航天航空学院，西安 710049

基金项目: 航空发动机及燃气轮机重大专项（J2019-Ⅳ-0021）；国家自然科学基金（11872288，51575425）；陕西省自然科学基金（2019JM-219）

详细信息

作者简介:
冯欣凯（1996-），男，硕士生，主要从事航空及燃气轮机滑动推力轴承研究。

通讯作者:
杨利花（1975-），女，副教授、博士生导师，博士，主要从事滑动轴承及转子动力学研究。E-mail： yanglihua_2@126.com

中图分类号: V229+.2;TH133.31+2
计量
- 文章访问数: 504
- HTML浏览量: 192
- PDF量: 206
- 被引次数: 0
出版历程
- 收稿日期: 2020-11-30
- 刊出日期: 2021-09-28

Analysis on thermoelasto-hydrodynamic lubrication characteristics of tilting pad thrust bearings under heavy load

FENG Xinkai^1,2,3,
YANG Lihua^{1,2,3
, ,}

1.
State Key Laboratory for Strength and Vibration of Mechanical Structures，Xi'an Jiaotong University，Xi'an 710049，China
2.
Shaanxi Key Laboratory of Environment and Control for Flight Vehicle，Xi'an Jiaotong University，Xi'an 710049，China
3.
School of Aerospace Engineering，Xi'an Jiaotong University，Xi'an 710049，China

摘要

摘要: 建立了可倾瓦推力轴承的热弹流润滑（TEHD）模型，应用Newton-Raphson迭代法求解，研究了弹性变形、热变形和载荷对油膜静动态特性的影响。结果表明：弹性变形会减弱油膜动压效应，而热变形会增强油膜动压效应；随外载荷增大热变形对轴承静动态特性的影响逐渐减弱而弹性变形的影响更加显著，重载条件下弹性变形的影响更为敏感。考虑轴承材料抗压性能和抗高温性能对可倾瓦推力轴承静动态特性的影响，对优化推力轴承设计、保证其稳定性和安全性具有重要意义。
- 油膜特性 /
- 可倾瓦 /
- 推力轴承 /
- 热弹流润滑 /
- 弹性变形 /
- 热变形
Abstract: A thermoelasto-hydrodynamic （TEHD） model of tilting pad thrust bearings was established and solved by Newton-Raphson iterative method.The influences of elastic deformation，thermal deformation and load on the static and dynamic characteristics of oil film were studied.Results showed that the elastic deformation reduced the dynamic pressure effect of the oil film，while the thermal deformation enhanced the dynamic pressure effect of the oil film.With the increase of external load，the influence of thermal deformation on the static and dynamic characteristics of the bearing decreased and the influence of elastic deformation became more significant.Besides，the influence of elastic deformation was more sensitive under heavy load.Considering the significant influences of bearings material compressive resistance and high temperature resistance on the static and dynamic characteristics of tilting pad thrust bearings，study on the stability and safety of thrust bearings can help to optimize thrust bearings design.
- oil film characteristics /
- tilting pad /
- thrust bearings /
- thermoelasto-hydrodynamic lubrication /
- elastic deformation /
- thermal deformation

HTML

参考文献(21)

[1]	GLAVATSKIH S B.Tilting pad thrust bearings[R].Leeds,UK：the 29th Leeds-Lyon Symposium on Tribology,2003.
[2]	ALMQVIST T.THD Analysis of tilting pad thrust bearings：comparison between theory and experiments[J].Journal of Tribology,2000,122（2）:412-417.
[3]	李贤燚,赵耀.可倾瓦推力轴承润滑油膜静动特性计算的嵌套式二分法与应用[J].船舶力学,2019,23（2）:142-151.
[4]	FILLON M,DESBORDES H,FRENE J.A global approach of thermal effects including pad deformations in tilting-pad journal bearings submitted to unbalance load[J].Journal of Tribology,1996,118（1）：169-174.
[5]	RASOOL K,LUIS S A.Effect of pad and liner material properties on the static load performance of a tilting pad thrust bearing[R].Phoenix,US:Turbomachinery Technical Conference and Exposition,2019.
[6]	SRIKANTH D V,KAUSHAL K.Determination of a large tilting pad thrust bearing angular stiffness[J].Tribology International,2012,47：69-76.
[7]	ALI E S,FENNER R T.Three-dimensional thermoelasto-hydrodynamic analysis of pivoted pad thrust bearings[J].Journal of Mechanical Engineering Science,1988,202（1）:39-50.
[8]	JIANG Xiulong,WANG Jiugen,FANG Jinghui.Thermal elastohydrodynamic lubrication analysis of tilting pad thrust bearings[J].Journal of Engineering Tribology,2011,225（2）:51-57.
[9]	FILLON M,GLAVATSKIH S B.PTFE-faced centre pivot thrust pad bearings：factors affecting TEHD performance[J].Tribology International,2008,41（12）：1219-1225.
[10]	GLAVATSKIH S B,FILLON M.TEHD analysis of thrust bearings with PTFE-faced pads[J].Journal of Tribology,2006,128（1）:49-58.
[11]	WANG Weimin,LIU Binbin,ZHANG Ya.Theoretical and experimental study on the static and dynamic characteristics of tilting-pad thrust bearing[J].Tribology International,2018,123:26-36.
[12]	SRIKANTH D V,CHATURVEDI K K,REDDY A C K.Modelling of large tilting pad thrust bearing stiffness and damping coefficients[J].Tribology in Industry,2009,31（3）:23-28.
[13]	CHANG Qiuying.Thermoelastohydrodynamic analysis of the static performance of tilting-pad journal bearings with the Newton-Raphson method[J].Tribology International,2002,35（4）:225-234.
[14]	马希直,朱均.载荷扰动下可倾瓦推力轴承绝热瞬态过程分析[J].航空动力学报,2010,25（3）：713-717.
[15]	DOWSON D.A generalized Reynolds equation for fluid-film lubrication[J].International Journal of Mechanical Sciences,1962,4（2）:159-170.
[16]	温诗铸,黄平.摩擦学原理[M].5版.北京:清华大学出版社,2018.
[17]	李忠,秦大同.可倾瓦推力轴承在变载荷下的瞬态润滑性能研究[J].中国机械工程,2004,15（15）：1326-1328.
[18]	DENNIS V,PELLEGRIN D,DOUGLAS J.An iso-viscous,isothermal model investigating the influence of hydrostatic recesses on a spring-supported tilting pad thrust bearing[J].Tribology International,2012,51:25-35.
[19]	KYUNG W K,MASATO T,YUKIO H.A three-dimensional analysis of thermohydrodynamic performance of sector-shaped,tilting-pad thrust bearings[J].Journal of Lubrication Technology,1983,105（3）:406-412.
[20]	刘世海.基于APDL的可倾瓦推力轴承润滑性能的研究[D].哈尔滨：哈尔滨理工大学,2015.
[21]	王报龙,王亚兵,刘洋洋.轴系倾斜下可倾瓦推力轴承静动特性分析[J].西安交通大学学报,2020,54（7）:129-138.
