公-自转耦合的滚针轴承保持架振动特性

王玉波; 周彩虹; 邓凯文; 邓四二

doi:10.13224/j.cnki.jasp.20200518

公-自转耦合的滚针轴承保持架振动特性

doi: 10.13224/j.cnki.jasp.20200518

王玉波^1,,
周彩虹²,
邓凯文¹,
邓四二^1,3,4, ,

1.
河南科技大学机电工程学院，河南洛阳 471003
2.
苏州轴承厂有限公司总师办，江苏苏州 215129
3.
辽宁重大装备制造协同创新中心，辽宁大连 116024
4.
河南科技大学高端轴承摩擦学技术与应用国家地方联合工程实验室，河南洛阳 471003

基金项目: 国家自然科学基金（52005158）

详细信息

作者简介:
王玉波（1995-），男，硕士生，主要研究方向为滚动轴承设计及理论。E-mail：1428134483@qq.com

通讯作者:
邓四二（1963-），男，教授、博士生导师，博士，主要从事滚动轴承设计及理论研究。E-mail：dse@hasut.edu.cn

中图分类号: V275;TH133.33+3
计量
- 文章访问数: 313
- HTML浏览量: 54
- PDF量: 116
- 被引次数: 0
出版历程
- 收稿日期: 2020-12-02
- 刊出日期: 2021-10-28

Vibration characteristics of needle roller bearing under planetary rotation

WANG Yubo^1
,,
ZHOU Caihong²,
DENG Kaiwen¹,
DENG Sier^{1,3,4
, ,}

1.
School of Mechatronics Engineering，Henan University of Science and Technology，Luoyang Henan 471003，China
2.
Chief Engineer's Office，Suzhou Bearing Factory Company Limited，Suzhou Jiangsu 215129，China
3.
Collaborative Innovation Center of Major Machine Manufacturing in Liaoning，Dalian Liaoning 116024，China
4.
National United Engineering Laboratory for Advanced Bearing Tribology，Henan University of Science and Technology，Luoyang Henan 471003，China

摘要

摘要: 建立了含公-自转耦合的行星轮滚针轴承动力学微分方程组，采用gear stiff（GSTIFF）变步长积分算法对微分方程组进行求解，对比研究了有无公转工况下保持架的打滑率和振动特性，分析了公-自转耦合工况下结构参数和工况参数对两者的影响。结果表明：纯自转工况下保持架振动加速度幅频图各倍频处对应1个幅值，公-自转耦合工况下各倍频处对应2个幅值；在公-自转耦合工况下，保持架振动幅值随径向力和公转速度的增大而增大，随自转速度的增大而减小，存在一个最优间隙比，即间隙比为1左右时使保持架振动幅值最小；保持架打滑率变化趋势与纯自转时一致，但数值减小且减幅越来越大；综上，公-自转耦合工况下会增大保持架径向振动特性，减小周向振动特性。
- 保持架振动特性 /
- 公-自转耦合 /
- 动力学 /
- 幅频变换 /
- 打滑率
Abstract: Dynamic differential equations of needle roller bearing was established，and solved by using gear stiff （GSTIFF） variable-step integration algorithm.The slip rate and vibration characteristics of cage between rotation and planetary rotation were compared，and the effects of vibration characteristics and slip rate of cage on the structural parameters and operating conditions under planetary rotation were further analyzed.The results showed that： one amplitude corresponded to each multiple band of the frame vibration acceleration spectrum under rotation conditions，two amplitudes corresponded to the multiple band of the frame vibration acceleration under planetary rotation conditions；the value increased with the increase of radial force and the velocity of orbital，decreased with the increase of the velocity of the rotation，there was an optimal gap ratio，which was about 1 to make the cage vibration amplitude minimum；the trend of slip rate of cage was similar to that without planetary rotation，but the level of reduction was higher.In summary，the radial vibration characteristic of cage was increased and the peripheral vibration characteristic was reduced under planetary rotation.
- vibration characteristics of cage /
- planetary rotation /
- dynamics /
- amplitude frequency transformation /
- slip rate

HTML

参考文献(18)

[1]	林何,王三民,董金城.斜齿行星齿轮传动系统振动模式与动载特性[J].航空动力学报,2015,30（9）:2298-2304.
[2]	廖映华,秦大同,刘长钊.行星齿轮系统载荷分配行为机理及影响因素分析[J].航空动力学报,2015,30（1）:201-208.
[3]	刘鲁,霍帅,郑凯,等.高DN值滚子轴承保持架断裂分析[J].航空动力学报,2020,35（10）:2115-2122.
[4]	张丽民,刘邦武,马风莉.轴承保持架断裂失效分析[J].金属热处理,2019,44（增刊1）:44-47.
[5]	GUPTA P K.Dynamics of rolling-element bearings:Part Ⅰ cylindrical roller bearing analysis[J].Journal of Tribology，1979，101（3）:303-304.
[6]	邓四二,顾金芳,崔永存,等.高速圆柱滚子轴承保持架动力学特性分析[J].航空动力学报,2014,29（1）:207-215.
[7]	景新,曹宏瑞,陈雪峰.保持架打滑对航空发动机主轴承故障特征频率的影响[J].航空动力学报,2019,34（5）:1145-1152.
[8]	黄运生,邓四二,张文虎,等.冲击载荷对铁路轴箱轴承塑料保持架动态性能影响研究[J].振动与冲击,2018,37（1）:172-180.
[9]	CUI Yongcun，DENG Sier，NIU Rongjun，et al.Vibration effect analysis of roller dynamic unbalance on the cage of high-speed cylindrical roller bearing[J].Journal of Sound and Vibration,2018,434:314-335.
[10]	STEVENTS K T.Experimental observations on torque variation caused by ball bearing cage instabilities （spin tests） [R].Risley，UK：the 2nd Space Tribology Workshop,1980.
[11]	白晓波,吉晓民,王毅.滚针轴承载荷分布影响因素的分析及其优化[J].机械科学与技术,2014,33（8）:1186-1191.
[12]	王春洁,曾福明,王东.航空发动机主轴承中保持架的振动特性分析[J].轴承,2004,4（4）:9-11.
[13]	张涛,陈晓阳,顾家铭,等.高速角接触球轴承保持架不稳定运动机理分析[J].振动与冲击,2019,38（10）:233-241,268.
[14]	姚廷强,黄亚宇,王立华.圆柱滚子轴承多体接触动力学研究[J].振动与冲击,2015,34（7）:15-23.
[15]	张文虎,胡余生,邓四二,等.高速圆柱滚子轴承保持架振动特性研究[J].振动与冲击,2019,38（22）:85-94.
[16]	涂文兵.滚动轴承打滑动力学模型及振动噪声特征研究[D].重庆：重庆大学，2012.
[17]	崔立,王黎钦,郑德志,等.航空发动机高速滚子轴承动态特性分析[J].航空学报,2008,29（2）:492-498.
[18]	陈渭,李军宁,张立波,等.考虑涡动工况的高速滚动轴承打滑失效分析[J].机械工程学报,2013,49（6）:38-43
