端壁倒圆半径误差对高负荷静叶栅性能影响的不确定性分析

郭正涛; 楚武利; 姬田园; 杨吉博; 张耀峰

doi:10.13224/j.cnki.jasp.20200519

端壁倒圆半径误差对高负荷静叶栅性能影响的不确定性分析

doi: 10.13224/j.cnki.jasp.20200519

西北工业大学动力与能源学院，西安 710129

基金项目: 国家科技重大专项（J2019-Ⅰ-0011）；国家自然科学基金面上项目（52076179）

详细信息

作者简介:
郭正涛（1996-），男，博士生，研究领域为叶轮机械气动热力学。E-mail：gzt141507108@outlook.com

通讯作者:
楚武利（1962-），男，教授、博士生导师，博士，研究领域为高性能轴流及离心压气机先进流动控制。E-mail：wlchu@nwpu.edu.cn

中图分类号: V231.3
计量
- 文章访问数: 366
- HTML浏览量: 116
- PDF量: 116
- 被引次数: 0
出版历程
- 收稿日期: 2020-12-03
- 刊出日期: 2021-10-28

Uncertainty analysis of effects of end wall fillet radius error on high-load stator cascade performance

School of Power and Energy，Northwestern Polytechnical University，Xi'an 710129，China

摘要

摘要: 为对压气机静子叶片高精度设计与制造提供有力参考，以某高负荷压气机静子叶栅为研究对象，采用基于高斯分布型随机输入的非嵌入式多项式混沌方法，量化评估了端壁倒圆半径误差对最小损失和近失速两个工况下气动性能的不确定性影响。结果表明：倒圆半径误差的不确定性对气动性能的平均水平影响不大，主要反映在气动性能参数的标准差上。提高倒圆半径的加工精度可提升气动性能的鲁棒性近一倍。加工精度一定时，为对叶片进行鲁棒性优化设计，应重点关注近失速工况下气动损失的鲁棒性。根据公差带内端壁倒圆半径与近失速工况下气动性能的关联性分析，倒圆半径与气动性能呈线性关系，应避免倒圆半径与设计值相比偏小的叶片投入使用，以期获得良好的气动性能。通过近失速流场的不确定性分析，分离流动对于倒圆半径误差更为敏感，是引起气动性能不确定性变化的主要因素。
- 不确定性量化 /
- 端壁倒圆 /
- 加工误差 /
- 高负荷叶栅 /
- 非嵌入式混沌多项式
Abstract: To provide a strong reference for the high-precision design and manufacture of the compressor stators，a high-load compressor stator cascade was used as the research object，and the non-intrusive polynomial chaos method based on Gaussian random input was used to quantitatively evaluate the uncertainty effect of the end wall fillet radius manufacturing error on the aerodynamic performance under the minimum loss and near stall conditions.Results showed that the uncertainty of the fillet radius error had little effect on the average level of aerodynamic performance，which was mainly reflected by the standard deviation of aerodynamic performance parameters.The robustness of aerodynamic performance can be nearly doubled by increasing the manufacturing accuracy of the fillet radius.When the manufacturing accuracy was constant，the robustness of total pressure losses under near stall conditions should be focused on to conduct the robustness design of the blade.According to the correlation analysis between the end wall fillet radius in the tolerance zone and the aerodynamic performance under near stall conditions，the fillet radius had a linear relationship with the aerodynamic performance，and it was required to avoid the use of blades with a rounding radius smaller than the nominal so as to obtain better aerodynamic performance.Through the uncertainty analysis of the near stall flow field，the separated flow was more sensitive to the rounding radius manufacturing error，which was the main factor causing the uncertainty of the aerodynamic performance.
- uncertainty quantification /
- end wall fillet /
- manufacturing error /
- high-load cascade /
- non- intrusive polynomial chaos

HTML

参考文献(26)

[1]	DEBRUGE L L.The aerodynamic significance of fillet geometry in turbo compressor blade rows[J].Journal of Engineering for Power,1980,102（4）:984-993.
[2]	MüLLER R,SAUER H,VOGELER K,et al.Influencing the secondary flow losses in compressor cascades by a leading edge bulb modification at the endwall[R].ASME Paper GT2002-30442,2002.
[3]	KüGELER E,WEBER A,NüRNBERGER,et al.Influence of blade fillets on the performance of a 15 stage gas turbine compressor[R].ASME Paper GT2008-50748,2008.
[4]	季路成，程荣辉，邵卫卫，等.最大负荷设计之:角区分离预测与控制[J].工程热物理学报，2007，28（2）:219-222.
[5]	田勇，季路成，李伟伟，等.叶身/端壁融合技术工况的适用性[J].航空动力学报，2013，28（8）:1905-1913.
[6]	高丽敏，蔡宇桐，李萍，等.叶根倒角对跨音速轴流压气机气动性能的影响[J].机械工程学报，2016，52（20）:137-143.
[7]	李兰攀，楚武利，张皓光.端壁倒圆对高负荷压气机叶栅性能及流场影响的机理研究[J].推进技术，2017，38（12）:2743-2752.
[8]	李兰攀.端壁倒圆与叶根Bulb对高负荷压气机叶栅性能影响的研究[D].西安:西北工业大学，2018.
[9]	GARZON V E.Probability aerothermal design of compressor airfoils[D].Cambridge,Massachusetts,US:Massachusetts Institute of Technology,2003.
[10]	LANGE A,VOIGT M,VOGELER K,et al.Impact of manufacturing variability on multistage high-pressure compressor performance[J].Journal of Engineering for Gas Turbines and Power,2012,134（11）:112601.1-112601.8.
[11]	WUNSCH D,HIRSCH C,NIGRO R,et al.Quantification of combined operational and geometrical uncertainties in turbo-machinery design[R].ASME Paper GT2015-43399,2015.
[12]	LUO J,LIU F.Statistical evaluation of performance impact of manufacturing variability by an adjoint method[J].Aerospace Science and Technology,2018,77（7）:471-484.
[13]	刘佳鑫，于贤君，孟德君，等.高压压气机出口级叶型加工偏差特征及其影响[J]．航空学报,2021,42（2）:423796.1-423796.17.
[14]	SCHNELL R,KAMPMANN T L,NICKE E.On the impact of geometric variability on fan aerodynamic performance,unsteady blade row interaction,and its mechanical characteristics[J].Journal of Turbomachinery,2014,136（9）:091005.1-091005.14.
[15]	李相君.高负荷轴流压气机叶栅角区失速及非轴对称端壁造型技术研究[D].西安:西北工业大学，2014.
[16]	中国工业和信息化部.一般公差、未注公差的线性和角度尺寸的公差: GB/T 1804-2000[S].北京:中国标准出版社，2000:4.
[17]	CHEN H,WANG Q,HU R,et al.Conditional sampling and experiment design for quantifying manufacturing error of transonic airfoil[R].AIAA-2011-658,2011.
[18]	张燕峰.高载荷压气机端壁流动及其控制策略研究[D].西安:西北工业大学，2010.
[19]	LI X,CHU W,WU Y,et al.Effective end wall profiling rules for a highly-loaded compressor cascade[J].Journal of Power and Energy,2016,230（6）:535-553.
[20]	MA S,CHU W,ZHANG H.Effects of modified micro-vortex generators on aerodynamic performance in a high-load compressor cascade[J].Journal of Power and Energy,2018,233（3）:309-323.
[21]	XIU D,KARNIADAKIS G E.Modeling uncertainty in flow simulations via generalized polynomial chaos[J].Journal of Computational Physics,2003,187（1）:137-167.
[22]	MAZZONI C,AHLFELD R,ROSIC B,et al.Uncertainty quantification of leakages in a multistage simulation and comparison with experiments[J].Journal of Fluids Engineering,2018,140（2）:021110.1-021110.9.
[23]	马驰，高丽敏，李瑞宇，等.来流马赫数波动对扩压叶栅气动性能的影响[J].工程热物理学报，2020，41（4）:851-859.
[24]	蔡雨桐.压气机叶片加工误差影响研究及叶型稳健性设计[D].西安:西北工业大学，2017.
[25]	ZHENG T,QIANG X,TENG J,et al.Application of humpback whale flippers in an annular compressor cascade[R].ASME Paper GT2016-56589,2016.
[26]	高丽敏，马驰，李瑞宇，等.真实运行状态下叶顶间隙尺寸波动对跨声速转子气动性能的影响研究[J].推进技术，2020，41（9）:1958-1966.
