航空弧齿锥齿轮风阻损失机理与影响因素分析

李林林; 王三民; 张旭阳; 李飞; 李志宾

doi:10.13224/j.cnki.jasp.20200524

航空弧齿锥齿轮风阻损失机理与影响因素分析

doi: 10.13224/j.cnki.jasp.20200524

西北工业大学机电学院，西安 710072

详细信息

作者简介:
李林林（1985-），女，博士生，主要从事弧齿锥齿轮动力学及效率研究。

中图分类号: V232.8
计量
- 文章访问数: 384
- HTML浏览量: 92
- PDF量: 114
- 被引次数: 0
出版历程
- 收稿日期: 2020-12-08
- 刊出日期: 2021-11-28

Mechanism and influencing factors analysis of windage losses from aeronautic spiral bevel gear

School of Mechanical Engineering， Northwestern Polytechnical University，Xi'an 710072，China

摘要

摘要: 基于计算流体动力学（CFD）理论，采用剪切应力输运（SST） k-ω湍流模型及多参考系旋转模型（MRF）技术和Coupled解耦算法，仿真分析了单个弧齿锥齿轮周围的气流特性及齿轮风阻损失机理，研究了齿轮转速、旋转方向及挡风罩配置对风阻功率损失的影响规律。然后利用正交试验分析方法进行数值模拟仿真分析，研究挡风罩与齿轮齿面、大端及小端之间不同间隙值时的风阻力矩，对数值仿真数据进行方差分析与拟合得到齿轮风阻功率损失与间隙值的函数关系，结果表明：挡风罩间隙值均为1 mm时，风阻力矩最小，降低风阻功率损失的效果最好。利用最优化分析方法给出了挡风罩与齿轮间隙值的单目标最优参考值，为进一步研究挡风罩间隙值多约束下的多目标优化提供了理论基础及研究方法，也为挡风罩的工程应用提供了参考。
- 计算流体动力学（CFD） /
- 弧齿锥齿轮 /
- 风阻功率损失 /
- 多参考系模型（MRF） /
- 挡风罩
Abstract: Based on the computational fluid dynamics （CFD） theory，the airflow characteristic and the mechanism of gear windage losses around the single spiral bevel gear were simulated and analyzed using shear stress transfer （SST） k-ω turbulence model and multi-reference rotation model （MRF） technology and the Coupled decoupling algorithm.The influence of gear speed，rotation direction and shroud configuration on windage power loss was researched.Then the windage moment was studied by orthogonal experiment and numerical simulation analysis with the difference clearance value between the shroud and the tooth surface，the heel and toe of the gear.By means of variance analysis and data fitting，the functional relationship between the windage losses and the clearance value of the gear was obtained.The results showed that when the shroud clearance value was 1mm，the windage moment was the smallest，and the effect of reducing the windage power loss was the best.The optimal reference value of the clearance between the shroud and the gear was given by using the single-objective optimization analysis method，which provided the theoretical basis and research method for further studying the multi-objective optimization of the shroud clearance and also a reference for the engineering application of the windshield.
- computational fluid dynamics （CFD） /
- spiral bevel gear /
- windage power loss /
- multiple reference frame （MRF） /
- shroud

HTML

参考文献(18)

[1]	GORlA C,CONCLI F,STAHL K,et al.Hydraulic losses of a gearbox CFD analysis and experiments[J].Tribology International,2013,66（5）:337-344.
[2]	陈士煊.航空齿轮传动系统的“风阻”问题[J].航空动力学报,1993,8（3）:303-304.
[3]	ANDERSON N E,LOEWENTHAL S H.Effect of geometry and operating conditions on spur gear system power loss[J].Journal of Mechanical Design,1981,103（4）:151-159.
[4]	DAWSON P H.Windage loss in larger high-speed gears[J].Proceedings of the Institution of Mechanical Engineers：Part A Journal of Power and Energy,1984,198（1）:51-59.
[5]	WINFREE D D.Reducing gear windage losses from high speed gears and applying these principles to actual running hardware[R].ASME Paper DETC2013-13039,2013.
[6]	JOHNSON G,SIMMONS K,FOORD C.Experimental investigation into windage power loss from a shrouded spiral bevel gear[R].ASME Paper GT2007-27885,2007.
[7]	FARRALL M,SIMMONS K,HIBBERD S,et al.Computational investigation of the airflow through a shrouded bevel gear[R] Reno,US:ASME Turbo Expo,2005.
[8]	RAPLEY S,EASTWICK C,SIMMONS K.The application of CFD to model windage power loss from a spiral bevel gear[R].ASME Paper GT2007-27879,2007.
[9]	RAPLEY S,EASTWICK C,SIMMONS K.Effect of variations in shroud geometry on single phase flow over a shrouded single spiral gear[R].ASME Paper GT2008-50633,2008.
[10]	WEBB T,EASTWICK C,MORVAN H.Parametric modelling of a spiral bevel gear using CFD[R].ASME Paper GT2010-22632,2010.
[11]	WEBB T,EASTWICK C,MORVAN H.CFD modelling of gear windage losses:two phase modelling using particle injections[R].ASME Paper ESDA2010-24654 ,2010.
[12]	贾清健,赵宁.高速圆柱直齿轮风阻功率损失参数研究[J].机械传动,2012,36（10）:20-24.
[13]	赵宁,贾清健．基于CFD的面齿轮风阻功率损失研究[J].机械传动,2012,36（9）:4-7．
[14]	梁作斌,杜佳佳,郭梅.齿轮风阻损失仿真及其实际应用[J].航空动力学报,2017,32（6）:1419-1424.
[15]	鲍和云,王春雷,陆凤霞,等.基于CFD的GTF发动机风扇驱动齿轮箱行星齿轮风阻损失分析[J].中南大学学报（自然科学版）,2020,51（4）:971-978.
[16]	ZHU X,DAI Y,MA F Y.CFD modelling and numerical simulation on windage power loss of aeronautic high-speed spiral bevel gears[J].Simulation Modelling Practice and Theory,2020,103（10）:102080.1-102080.21.
[17]	王福军.水泵与泵站流动分析方法[M].北京:中国水利水电出版社,2020:45-60.
[18]	吴达人.泵与风机[M].西安:西安交通大学出版社,1989.
