Aero-engine centrifugal separator performance test
-
摘要: 为获取某型发动机离心通风器性能,通过试验模拟通风器的油雾工作环境,综合运用测质量法与光学测量方法,获取分离效率、粒径分布与压降数据。试验结果显示,分离效率随转速增加呈现先线性上升后平缓的规律。转速从静态增加到1 000 r/min,分离效率增加10%,油雾平均直径从1.8 μm降低至1.3 μm,粒径2.0~3.0 μm基本被分离;转速增加至2 500 r/min,平均粒径基本不变,未分离油雾粒径集中在2.1 μm以下。空气质量流量基本不影响粒度分布,对分离效率影响小;压降随质量流量、转速增加而增加。Abstract: Tests were performed on aero-engine centrifugal separator to gain the performance data by simulating bearing cavity oil-air mist environment.Mass and optics measurement methods were used to collect the separating efficiency,particle size distribution and pressure drop data.Test results revealed that separating efficiency increased linearly and then gently while rotation increased.Separating efficiency increased 10% while rotation increased from static state to 1 000 r/min,particles between 2.0 μm and 3.0 μm were nearly separated,and middle diameter decreased from 1.8 μm to 1.3 μm.While rotation increased up to 2 500 r/min,middle diameter kept the same and particles below 2.1 μm were kept.Air mass flow nearly had no effect on particle size distribution and separating efficiency.Pressure drop increased when air mass flow and rotation increased.
-
Key words:
- separator /
- oil mist field /
- particle size distribution /
- separating efficiency /
- pressure drop
-
[1] WILLENBORG K,BUSAM S,RO?KAMP H,et al.Experimental studies of the boundary conditions leading to oil fire in the bearing chamber and in the secondary air system of aeroengines[R].ASME Paper GT-2002-30241,2002. [2] 林基恕.航空燃气涡轮发动机机械系统设计[M].北京:航空工业出版社,2005. [3] ZIMMERMANN H,KAMMERER A,FISCHER R,et al.Two-phase flow correlations in air/oil systems of aero engines[R].ASME Paper 91-GT-51,1991. [4] 徐让书,胡慧,邵长浩,等.离心通风器通风阻力的影响因素[J].航空动力学报,2014,29(10):2410-2416. [5] 徐让书,邵长浩,牛玲,等.结构因素对离心通风器性能影响的数值研究[J].航空发动机,2014,40(6):18-23. [6] 石帅奇,刘振侠,胡剑平.航空发动机离心通风器计算[J].航空计算技术,2012,42(1):68-71. [7] 李勇,李国权.航空发动机离心通风器性能的试验研究[R].南京:中国航空学会机械动力传输学术会议,2007. [8] WILLENBORG K,KLINGSPORN M,TEBBY S,et al.Experimental analysis of air/oil separator performance[R].ASME Paper GT2006-90708,2006. [9] WITTING S L K,ZAHORANSKT R A,SAKBANI K H.The dispersion quotient technique in submicron particle size analysis[J].Journal of Aerosol Science,1981,12(3):183-184. [10] SCHNEIDER W,KAUSCH E,WITTING S,et al.The mean particle size in fresh undiluted cigarette smoke determined by means of the dispersion quotient method[J].Journal of Aerosol Science,1988,19(7):895-898. [11] WITTIG S,FEL H J,MULLER A,et al.Application of the dispersion-quetient method under technical system conditions[R].Arizona,US:the 2nd International Congress on Optical Particle Sizing,1990. [12] DITTMANN R,FELD H J,SAMENFINK W,et al.Multipe wavelength extinction technique for particle characterization in dense particle clouds[J].Particle and Particle Systems Characterization,1994,11(5):379-384. [13] 国家国防科技工业局. 航空燃气涡轮发动机离心通风器性能试验方法:HB20273-2016 [S].北京:中国航空综合技术研究所,2016:1-6.[14] 张福根.激光粒度仪的光学结构[R].北京:中国颗粒学会年会暨海峡两岸颗粒技术研讨会,2006. [15] 刘树,张兆芝,潘志东,等.国内外激光粒度仪结构与性能介绍[J].中国仪器仪表,2012(1):63-66. [16] 梁国标,李新衡,王燕民.激光粒度测量的应用与前景[J].材料导报,2006,20(4):90-93. [17] 马尔文仪器有限公司.马尔文MS 2000激光粒度分析仪使用手册[M].郑州:黄河水利出版社,2001. [18] BUSAM S,EBNER J,WITTIG S.An experimental study of liquid film thickness in annular air/oil flow in a vertical pipe using a laser focus displacement meter[R].ASME Paper 2001-GT-0116,2001. [19] KLINGSPORN M.Advanced transmission and oil system concepts for modern jet engines[R].ASME Paper GT-2004-53578,2004.
