运输类飞机动力装置溅水试验技术

赵海刚; 屈霁云; 马争胜; 符小刚; 戚学锋

doi:10.13224/j.cnki.jasp.20200542

运输类飞机动力装置溅水试验技术

doi: 10.13224/j.cnki.jasp.20200542

1.
中国航空工业集团有限公司中国飞行试验研究院，西安 710089
2.
中国商用飞机有限责任公司上海飞机设计研究院，上海 201210

详细信息

作者简介:
赵海刚（1979-），男，高级工程师，硕士，主要从事航空动力装置飞行试验技术研究。

中图分类号: V217.39
计量
- 文章访问数: 604
- HTML浏览量: 279
- PDF量: 118
- 被引次数: 0
出版历程
- 收稿日期: 2020-12-19
- 刊出日期: 2021-12-28

Water ingestion test technical of transport aircraft power system

1.
Chinese Flight Test Establishment，Aviation Industry Corporation of China Limited，Xi'an 710089，China
2.
Shanghai Aircraft Design and Research Institute，Commercial Aircraft Corporation of China Limited，Shanghai 201210，China

摘要

摘要: 基于对中国民用航空局（CAAC）运输类飞机适航标准和美国联邦航空管理局（FAA）咨询通告的分析、解读，分别从工程试验与适航验证两个方面，研究了溅水试验程序、试验水池方案设计与滑行速度测量与控制技术，制定了符合适航标准体系的运输类飞机动力装置溅水试验审定程序，以ARJ21-700型支线飞机合格审定试飞为平台，完整进行了相关试验验证。结果表明：所设计的溅水试验程序合理可行，能够完整地验证运输类飞机在机场跑道积水环境下动力装置对适航标准体系的符合性；试飞结果表明CF34-10A发动机配装ARJ21-700型飞机在机场积水环境下起飞构型临界滑行速度为166.6 km/h，发动机风扇、压气机及动力涡轮前温度最大波动值分别为5.1%、1.7%和39 ℃；在飞机着陆构型下，发动机慢车状态相对于最大反推力状态工作稳定性较好，能够满足适航标准规定；项目形成溅水试验程序和技术为后续C919、C929等运输类飞机动力装置相关试验提供了直接的支持。
- 适航标准 /
- 运输类飞机 /
- 动力装置 /
- 溅水试验 /
- 滑行速度
Abstract: On the basis of analyzing and interpreting the Chinese civil regulations transport airworthiness standards of Civil Aviation Administration of China （CAAC） and advisory circular of Federal Aviation Administration （FAA），the water ingestion test program，test pool scheme and landing speed measurement and control technology was studied and designed from two aspects of engineering test and airworthiness verification.Based on the airworthiness standard system，the procedure of transport aircraft power system water ingestion test was developed and applied in the ARJ21-700 aircraft flight test.The results showed that the designed water ingestion test procedure was reasonable and feasible，and it was able to verify power systemcompliance with standards completely when the transport aircraft passed through the water contaminated runway；the critical speed of ARJ21-700 aircraft equipped with CF34-10A engine was 166.6 km/h in aircraft taking off and slipping through the water contaminate runway；the maximum fluctuations of the rotation rate of fan and compressor，and inter turbo temperature were 5.1%，1.7% and 39 ℃.The performance of engine was better in idle state compared with maximum reverse thrust state in the aircraft landing and slipping through the water contaminated runway.So it could meet the airworthiness standard.The procedure and technology provide a direct support for the power system water ingestion test of C919，C929 and other transport aircrafts.
- airworthiness standard /
- transport aircraft /
- power system /
- water ingestion test /
- aircraft slipping speed

HTML

参考文献(20)

[1]	王传煌，崔健勇.民用飞机的起落架溅水试验[J].飞行试验，1992，4（2）:36-39.
[2]	戚学峰，曾涛.民用飞机动力装置溅水试验适航验证方法[J].航空发动机，2013，39（3）:55-58.
[3]	徐绯，李亚南，高向阳，等.机场污染跑道飞机轮胎的溅水问题[J].航空学报，2015，36（4）：1177-1184.
[4]	MARTIN C S.Hydrodynamics of tire hydroplaning[R].NASA CR-601,1996.
[5]	GOODEN J H M.CR spray-impingement drag calculation of aircraft on water-contaminated runways[R].Toronto，Canada:the 48th CASI（Canadian Association of Snowboard Instructors） Annual Conference，2001.
[6]	ROBERT H D,SANDY M S.Measurements of flow rate and trajectory of aircraft tire-generated water spray[R].NASA-TP-2718,1987.
[7]	Federal Aviation Administration.Flight test guide for certification of transport categoryairplanes:AC25-7D[S].Washington，US:Federal Aviation Administration，2018:156-198.
[8]	Federal Aviation Administration.Water ingestion for turbine powered airplanes:AC20-124[S].Washington，US:Federal Aviation Administration，1985:1-5.
[9]	Federal Aviation Administration.Evaluating turbine engine operating characteristics:AC 25-939[S].Washington，US:Federal Aviation Administration,1986:1-11.
[10]	Society of Automotive Engineers.Tire spray suppression-airplane design and considerationfor:AIR 1904B[S].Chicago，US:America:Society of Automotive Engineers International，2017:1-39.
[11]	Federal Aviation Administration.Water,slush and snow on the runway:AC 91-6A[S].Washington，US:Federal Aviation Administration,1978:1-6.
[12]	GOODEN J H M.CRspray- impingement drag calculation of aircrafton water-contaminated runways[R].National Aerospace Laboratory，NLR-TP-2001-204,2001.
[13]	MCBRIDEE E.An experimental investigation of the scalerelations for the impinging water spray generated by a planningsurface[R].NACA-TN-3615,1956.
[14]	BARRETT R B.Drag and spray measurements from a Smallpneumatic tyre travelling through a water layer[R].London,UK:Ministry of Aviation,1965.
[15]	张岳青，徐绯，段敏鸽，等.飞机轮胎溅水计算方法及翻边轮胎挡水原理分析[J].科学技术工程2014，14（6）:54-59.
[16]	张显鹏，徐绯，任选其，等.轮胎滚动溅水与垂直入水相似性分析[J].中国科学：技术科学，2018，48（9）:931-938.
[17]	张树鹏.翻边轮胎挡水效应的数值模拟研究[D].西安：西北工业大学，2017.
[18]	杨成凤，郭兆电，邓文剑.机轮溅水特性及对进气道吸水的影响[J].航空学报，2018，39（2）：56-65.
[19]	朱林培.基于Ls-dyna的轮胎滑水特性研究[J].中国制造业信息化，2009,38（11）：72-75.
[20]	李强，张卓，张立.临界滑水速度的计算研究[J].重庆交通大学学报（自然科学版）,2011,30（5）:899-993.
