旋流杯结构对燃油雾化粒径的影响

陈溯敏; 姜磊; 王彤; 胡宏斌; 王博涵; 姜向禹

doi:10.13224/j.cnki.jasp.20200547

旋流杯结构对燃油雾化粒径的影响

doi: 10.13224/j.cnki.jasp.20200547

陈溯敏^1,2,3,4,
姜磊^1,2,3,4,
王彤^1,2,3,4,
胡宏斌^1,2,3,4,
王博涵^1,2,3,4,
姜向禹^1,2,3,4

1.
中国科学院工程热物理研究所先进燃气轮机实验室，北京 100190
2.
中国科学院工程热物理研究所先进能源动力重点实验室，北京 100190
3.
中国科学院轻型动力创新研究院，北京 100190
4.
中国科学院大学工程科学学院，北京 100049

基金项目: 中国科学院重点部署项目（KXXZD-135-16-019）

详细信息

作者简介:
陈溯敏（1995-），女，硕士生，主要从事发动机燃烧学研究。

中图分类号: V231.2
计量
- 文章访问数: 80
- HTML浏览量: 11
- PDF量: 79
- 被引次数: 0
出版历程
- 收稿日期: 2020-12-23
- 刊出日期: 2021-12-28

Effects of swirl cup structure on fuel atomization particle size of fuel

CHEN Sumin^1,2,3,4,
JIANG Lei^1,2,3,4,
WANG Tong^1,2,3,4,
HU Hongbin^1,2,3,4,
WANG Bohan^1,2,3,4,
JIANG Xiangyu^1,2,3,4

1.
Advanced Gas Turbine Laboratory，Institute of Engineering Thermophysics，Chinese Academy of Sciences，Beijing 100190，China
2.
Key Laboratory of Advanced Energy and Power，Institute of Engineering Thermophysics，Chinese Academy of Sciences，Beijing 100190，China
3.
Innovation Academy for Light-duty Gas Turbine，Chinese Academy of Sciences，Beijing 100190，China
4.
School of Engineering Science，University of Chinese Academy of Sciences，Beijing 100049，China

摘要

摘要: 为深入研究进气参数、旋流杯结构以及中心喷嘴与旋流杯文氏管的轴向配合对航空煤油雾化粒径的影响，采用LSA（laser size analyzer）-Ⅲ激光粒度分析仪在常温常压下对同向双级轴向旋流杯出口下游35 mm处燃油索太尔平均直径（SMD）进行测量。结果显示：随着旋流杯头部压降的增大，燃油SMD不断减小，但减小趋势不断变缓；叶片角在35°附近时，燃油粒径较小；内外两级旋流强度需相互匹配，两者共同影响燃油预膜与破碎；文氏管喉道直径影响了内级旋流强度及成膜质量，喉道直径与文氏管长度比在1.04~1.13内，燃油SMD较小；套筒扩张段限制喷雾运动，其值过大或过小都会导致燃油SMD增大；燃油喷嘴与文氏管装配位置影响液膜破碎质量。
- 燃气轮机燃烧室 /
- 空气雾化喷嘴 /
- 旋流杯 /
- 索太尔平均直径（SMD） /
- 激光粒度分析仪
Abstract: In order to deeply study the effects of inlet parameters，swirl cup structures and axial coordination of fuel nozzle and Venturi of swirl cup on the atomization particle size of aviation kerosene，the LSA （laser size analyzer）-Ⅲ was used to measure the Sauter mean diameter （SMD） at 35 mm downstream the outlet of the co-rotating axial swirl cup under ambient temperature and pressure.The results showed that with the increase of the total pressure loss coefficient of the swirl cup，the SMD of fuel decreased，while the decreasing trend slowed down.The SMD was small near the case of 35° vane installation angle.The inner and outer swirling intensity should be matched with each other，which together could affect the fuel pre-filming and fuel sheet breakup.The Venturi throat diameter affected the inner swirling intensity and the quality of film formation.While the ratio between the Venturi throat diameter and Venturi length was within the range of 1.04-1.13，the SMD was small.The spray diffusion was restricted by the sleeve divergence section.Either large or small divergence angle may lead to an increase in fuel SMD.The position of fuel nozzle and the Venturi affected the quality of liquid film breaking.
- gas turbine combustor /
- air-blast-atomizer /
- swirl cup /
- Sauter mean diameter（SMD） /
- laser size analyzer

HTML

参考文献(22)

[1]	诸惠民,褚广晓.火焰筒头部涡流器空气对燃油喷雾特性的影响[J].航空发动机,1998,24（2）:20-24.
[2]	徐华胜.高性能旋流燃烧装置气动和雾化特性研究[D].成都:电子科技大学,2007.
[3]	彭云晖,林宇震,许全宏,等.双旋流空气雾化喷嘴喷雾、流动和燃烧性能[J].航空学报,2008,29（1）:1-14.
[4]	JENG S M,FLOHRE N M,MONGIA H C.Swirl cup modeling-atomization[R].AIAA-2004-137,2004.
[5]	FU Y,CAI J,ELKADY A M,et al.Fuel and equivalence ratio effects on spray combustion of a counter-rotating swirler[R].AIAA-2005-354,2005.
[6]	HADEF R,LENZE B.Effects of co-and counter-swirl on the droplet characteristics in a spray flame[J].Chemical Engineering and Processing,2008,47（12）:2209-2217.
[7]	代威,林宇震,许全宏,等.径向旋流器气量分配对点火熄火特性的影响[J].航空动力学报,2016,31（3）:608-615.
[8]	WANG Xiaofeng,LIN Yuzhen,HU Haosheng,et al.Effect of swirl cup's Venturi shape on spray structure and ignition process[R].ASME Paper GT-2014-25216,2014.
[9]	杨兴林,程林,邵明扬,等.双级轴向旋流非预混燃烧和流动特性分析[J].船舶工程,2019,41（5）:85-90,95.
[10]	MONGIA H C,GORE J P,GRINSTEIN F F,et al.Combustion research needs for helping development of next-generation advanced combustors[R].AIAA-2001-3853,2001.
[11]	WANG H Y,MCDONELL V G,SAMUELSEN G S.Influence of hardware design on the flow field structures and the patterns of droplet dispersion：Part Ⅰ mean quantities[J].Journal of Engineering for Gas Turbines and Power,1995,117（2）:282-291.
[12]	ATESHKADI A,MCDONELL V G,SAMUELSEN G S.Effect of mixer geometry on fuel spray distribution,emission and stability[R].AIAA-98-0247,1998.
[13]	WANG H Y,MCDONELL V G,SOWA W A,et al.Scaling of the two phase flow downstream of a gas turbine combustor swirl cup:Part Ⅰ mean quantities[J].Journal of Engineering for Gas Turbines and Power,1993,115（3）:453-460.
[14]	WANG H Y,MCDONELL V G,SAMUELSEN G S.The influence of spray angle on the continuous and discrete phase flow field down stream of an engine combustor swirl cup[R].AIAA-92-3231,1992.
[15]	康尧,林宇震,蒋尧,等.旋流杯套筒混合段长度对点火特性的影响[J].航空动力学报,2016,31（9）:2095-2103.
[16]	PARK J,YOON Y,JEUNG I.Effect of swirl cup on characteristics of fuel spray in gas turbine combustors[R].AIAA-2000-3352,2000.
[17]	于锦峰,郭志辉,张君锋,等.套筒长度对火焰筒流场和雾化特性的影响[J].航空动力学报,2009,24（11）:2506-2513.
[18]	HAN Y M,SEOL W S,LEE D S,et al.Effects of fuel nozzle displacement on pre-filming airblast atomization[J].Journal of Engineering for Gas Turbines and Power,2001,123（1）:33-40.
[19]	FAN Xiongjie,LIU Cunxi,XU Gang,et al.Experimental investigations of the spray structure and interactions between sectors of a double-swirl low-emission combustor[J].Chinese Journal of Aeronautics,2020,33（2）:589-597.
[20]	GAD H M,IBRAHIM I A,ABDEL-BAKY M E,et al.Experimental study of diesel fuel atomization performance of air blast atomizer[J].Experimental Thermal and Fluid Science,2018,99:211-218.
[21]	王博涵,胡宏斌,姜磊,等.一种双燃料喷嘴:
[22]	CN210153864U[P].2020-03-17.
