第三代航空齿轮钢圆柱齿轮弯曲疲劳强度性能测试分析

唐鑫; 朱如鹏; 廖梅军; 熊兴波; 唐朋

doi:10.13224/j.cnki.jasp.20200559

第三代航空齿轮钢圆柱齿轮弯曲疲劳强度性能测试分析

doi: 10.13224/j.cnki.jasp.20200559

1. 南京航空航天大学直升机传动技术重点实验室, 南京 210016;
2. 中国航空发动机集团有限公司湖南动力机械研究所直升机传动技术重点实验室, 湖南株洲 412002

基金项目:

国家基金面上项目（51975274）；南京航空航天大学“直升机传动技术重点实验室”开放课题（HTL-O-20K02）

详细信息

作者简介:
唐鑫(1983-),男,高级工程师,博士生,主要从事直升机传动、传动强度和振动的研究。

中图分类号: V233.1;TH113.1
计量
- 文章访问数: 594
- HTML浏览量: 150
- PDF量: 224
- 被引次数: 0
出版历程
- 收稿日期: 2020-12-27
- 刊出日期: 2021-08-28

Analyse bending fatigue strength test of cylindrical gear of third-generation aviation gear steel

1. National Key Laboratory of Science and Technology on Helicopter Transmission, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China;
2. Science and Technology on Helicopter Transmission Laboratory, Hunan Aviation Powerplant Research Institute, Aero Engine corporation of China, Zhuzhou Hunan 412002, China

摘要

摘要: 以第三代航空齿轮钢圆柱齿轮的弯曲疲劳性能作为研究对象，修正了国标（GB）给出的齿轮弯曲夹具计算公式，设计了弯曲疲劳试验用圆柱齿轮参数，并对该材料的齿轮进行了弯曲疲劳试验。通过对试验结果数据采用对数正态分布、二参数威布尔分布数据处理方法对试验数据进行了处理，得到了该材料的试验齿轮弯曲疲劳极限及可靠-应力-寿命（R-S-N）曲线，同时与9310钢（第一代）齿轮的性能进行了对比分析。结果表明：在置信度为95%、可靠度为99%的情况下，9310钢圆柱齿轮的弯曲应力极限为602 MPa，第三代航空齿轮钢圆柱齿轮钢的弯曲应力极限为687.6 MPa，第三代齿轮钢的齿轮弯曲疲劳性能相对于9310钢疲劳性能提高了14.2%，该材料在航空齿轮传动齿轮的弯曲疲劳特性方面体现出较大的优势。
- 第三代航空齿轮钢 /
- 弯曲疲劳强度 /
- R-S-N曲线 /
- 疲劳极限 /
- 弯曲夹具
Abstract: Taking the third-generation aviation gear steel gear as the research object, the bending fatigue test of the cylindrical gear made of this material was carried out. The cylindrical gear for bending fatigue test was designed, and the calculation formula of the GB standard gear bending fixture was revised. The bending fatigue test was carried out for the gear of the material. The experimental data were analyzed, and the log -normal distribution and two -parameter Weibull distribution data processing methods were used to fit the data. The bending fatigue limit and R-S-N curve of the test gear were obtained. The performance of test gears and 9310 steel gear was compared and analyzed. The results showed that under the condition of 95% confidence degree and 99% reliability, the bending stress limit of 9310 steel gear was 602 MPa and the bending stress limit of the third-generation aviation gear steel gear was 687. 6 MPa. The bending fatigue performance of the third-generation aviation gear steel gear was 14. 2% higher than that of the 9310 steel,presenting great advantage in aviation gear transmission.
- third-generation aviation gear steel /
- bending fatigue strength /
- R-S-N curve /
- fatigue limit /
- bending fixture

HTML

参考文献(21)

[1]	刘子强,陈亮,万文铭. 关于齿轮单齿脉动弯曲疲劳试验中的几个问题[J].机械传动,2017,41(3):151-154. LIU Ziqiang, CHEN Liang, WAN Wenming. Several questions aboutgear single tooth pulsating bending fatigue test[J]. Journal of Mechanical Transmission, 2017, 41(3):151-154. (in Chinese)
[2]	李文正. 圆弧齿轮的几种损伤形式及其防止措施[J]. 装备制造技术,2015(6):263-264,279. LI Wenzheng.Several damage types of circular arc gear and its prevention measures[J] Equipment Manufacturing Technology,2015(6):263-264,279.(in Chinese)
[3]	朱孝录. 齿轮的试验技术与设备[M]. 北京:机械工业出数社,1988.
[4]	胡晓煜.T700发动机发展综述[R]. 北京:中国航空工业发展研究中心,2003.
[5]	于海旭. 齿轮疲劳失效分析与工艺参数优化[J]. 失效分析与预防,2018,13(3):189-195. YU Haixu. Fatigue failure analysis and process parameters optimization of gear[J]. Failure Analysis and Prevention, 2018,13(3):189-195.(in Chinese)
[6]	张洛明,张向威. 工业结构钢疲劳极限的断裂力学研究[J]. 塑性工程学报,2009,16(4):162-166. ZHANG Luoming,ZHANG Xiangwei.The study on fatigue limit of industrial structural steel with fracture mechanics[J]. Journal of Plasticity Engineering, 2009, 16(4):162-166.(in Chinese)
[7]	樊俊星,邓召义. 航空齿轮传动的可靠性优化设计[J]. 上海大学学报(自然科学版),2001,7(3):205-208. FAN Junxing,DENG Zhaoyi.Reliability optimization design of aviation gears transmission[J].Journal of Shanghai University(Natural Science Edition),2001,7(3):205-208.(in Chinese)
[8]	何晓华.20CrMoH齿轮弯曲疲劳强度研究[D].重庆:重庆大学,2011. HE Xiaohua. The study of bending fatigue strength of 20CrMoH gear[D]. Chongqing:Chongqing University, 2011. (in Chinese)
[9]	陈毅.20CrMnMo齿轮齿根残余应力理论及试验研究[D]. 重庆:重庆大学,2013. CHEN Yi.Theoretical and experimental researches of 20CrM-nMo gear root residual stresses[D]. Chongqing:Chongqing University,2013.(in Chinese)
[10]	马骋天,李纪强,陈宏,等.20CrMnMo齿轮弯曲疲劳性能试验研究[J].内燃机与配件,2018(14):5-6. MA Pintian, LI Jiqiang, CHEN Hong, et al. Experimental study on bending fatigue performance of 20CrMnMo Gear[J]. Internal Combustion Engine and Parts, 2018(14):5-6. (in Chinese)
[11]	李铭,谢里阳,张宇,等. 齿轮的概率寿命预测与弯曲疲劳试验[J].机械工程学报,2017,53(18):169-175. LI Ming, XIE Liyang, ZHANG Yu, et al. Probabilistic life prediction and bending fatigue test for gear[J].Journal of Mechanical Engineering,2017,53(18):169-175.(in Chinese)
[12]	BENEDETTI M,FONTANARI V,HÖHN B R,et al.Influence of shot peening on bending tooth fatigue limit of case hardened gears[J]. International Journal of Fatigue, 2002, 24(11):1127-1136.
[13]	PENG Chong, XIAO Yuzhe, WANG Yanzhong, et al. Effect of laser shock peening on bending fatigue performance of AISI 9310 steel spur gear[J].Optics and Laser Technology,2017,94:15-24.
[14]	赵文杰,杨绍普,任学红,等. 高铁齿轮钢18CrNiMo7-6循环变形行为实验和本构模型[J]. 湖南大学学报(自然科学版),2020,47(6):52-58. ZHAO Wenjie,YANG Shaopu,REN Xuehong,et al.Cyclic deformation experiment and constitutive model of high-speed railway gear steel 18CrNiMo7-6[J]. Journal of Hunan University(Natural Sciences), 2020, 47(6):52-58.(in Chinese)
[15]	WON C, LEE W, LEE H Y, et al. Evaluation of in-plane edge stretchability under severe contact condition for third-generation advanced high-strength steel[J]. The International Journal of Advanced Manufacturing Technology, 2020,108(9):1-14.
[16]	EMAMI M,ASKARI-PAYKANI M,FARABI E,et al.Development of new third-generation medium manganese advanced high-strength steels elaborating hot-rolling and intercortical annealing[J]. Metallurgical and Materials Transactions:A,2019,50(9):1-14.
[17]	SAVIC V, HECTOR L, SINGH H, et al. Development of a lightweight third-generation advanced high-strength steel (3GAHSS)vehicle body structure[J]. SAE International Journal of Materials and Manufacturing,2018,11(4):303-313.
[18]	CHANG Ying, HAN Shuo, LI Xiaodong, et al. Effect of shearing clearance on formability of sheared edge of the third-generation automotive medium-Mn steel with metastable austenite[J]. Journal of Mechanical Working Technology, 2018,259:216-227.
[19]	张照智,关焯,谈嘉祯,等. 齿轮弯曲疲劳强度试验方法:GB/T 14230-1993[S].北京:中国标准出版社,1993:1-12.
[20]	朱孝录,鄂中凯. 齿轮承载能力分析[M]. 北京:高等教育出版社,1992.
[21]	唐定国,鄂中凯,朱孝禄,等. 渐开线圆柱齿轮承载能力计算方法:GB/T 3480-1997[S]. 北京:中国标准出版社,1997:1-80.
