低负荷和高负荷压气机叶栅气动性能的实验和数值模拟

原泽; 郑群; 岳国强; 董静涛; 姜玉廷

doi:10.13224/j.cnki.jasp.2021.04.005

低负荷和高负荷压气机叶栅气动性能的实验和数值模拟

doi: 10.13224/j.cnki.jasp.2021.04.005

1.
哈尔滨工程大学动力与能源工程学院,哈尔滨 150001
2.
中国人民解放军军事科学院系统工程研究院,北京 100074

基金项目: 国家科技重大专项（2017-Ⅰ-0011-0012，2017-Ⅰ-0009-0010）

计量
- 文章访问数: 595
- HTML浏览量: 165
- PDF量: 301
- 被引次数: 0
出版历程
- 收稿日期: 2020-05-09
- 刊出日期: 2021-04-28

Experiment and numerical simulation on aerodynamic performance of low-loaded and highly-loaded compressor cascades

1.
College of Power and Energy Engineering,Harbin Engineering University,Harbin 150001,China
2.
Institute of Systems Engineering,Academy of Military Sciences,the Chinese People’s Liberation Army,Beijing 100074,China

摘要

摘要: 为了明确采用高负荷设计及一般设计（低负荷）方法的压气机气动性能和流动转捩的差异，进行了不同攻角下的叶栅吸力面流谱绘制和参数测量实验。并基于实验边界条件，采用γ-θ转捩模型开展数值研究。结果表明：与低负荷叶栅相比，随着攻角的增大，高负荷叶栅主流附面层由附着流变为分离流，尾迹的宽度和损失强度增加，并与角区分离融合为一个“带状”损失区。而低负荷叶栅的角区分离仍为紧贴壁面的开式分离，主流附面层仍然附着在壁面上。结果表明：高负荷设计增强了叶栅内逆压力梯度，这使得流动更容易分离，表现为表面形状因子呈现大范围的“峰谷”型分布，转捩模式也由局部旁路转捩变为全叶高范围的分离泡转捩。
- 低负荷和高负荷叶型 /
- 压气机叶栅实验 /
- 气动性能 /
- 转捩 /
- 攻角
Abstract: To clarify the difference in aerodynamic performance and flow transition between compressors using highly-loaded design and general design (low-loaded), the cascade experiments including suction side flow pattern and parameter measurement were performed. Based on the experimental boundary conditions, numerical researches on the suction boundary layer with γ-θ transition model were also conducted. Result showed that, compared with the low-loaded cascade, as the incidence angle increased, the flow boundary layer in highly-loaded cascade transformed from the attached flow to the separated flow, which enhanced wake width and loss and made wake integrate with corner separation loss region into a “strip-shape” loss region. Meanwhile, the flow boundary flow in low-loaded cascade was still an attached flow and the corner separation maintained open separation close to the endwall. The results indicated that highly-loaded design enhanced the inverse pressure gradient in the cascade, causing the flow more easily separated, the surface shape parameter presented a wide range of “peak” distribution, and the transition mode also changed from local bypass transition to all-span separation-induced transition.
- low-loaded and highly-loaded profile /
- compressor cascade experiment /
- aerodynamic performance /
- transition /
- incidence angle

HTML

参考文献(21)

[1]	宋寅.先进高负荷压气机气动设计技术综述［J］.分布式能源,2018,3(3):4-12. SONG Yin.Review on aerodynamics design of advanced highly-loaded compressor［J］.Distributed Energy,2018,3(3):4-12.(in Chinese)
[2]	丁骏,王松涛,刘勋,等.采用复杂三维气动布局的高负荷压气机气动设计研究［J］.工程热物理学报,2016,37(11):2325-2331. DING Jun,WANG Songtao,LIU Xun,et al.Investigation of highly loaded compressor aerodynamic design adopting complex 3D aerodynamic layout［J］.Journal of Engineering Thermophysics,2016,37(11):2325-2331.(in Chinese)
[3]	钟兢军,阚晓旭.高负荷压气机叶栅内三维旋涡结构及其形成机理的研究进展［J］.推进技术,2020,41(9):1946-1957. ZHONG Jingjun,KAN Xiaoxu.Research progress on three-dimensional vortex structures and formation mechanism of high-loaded compressor cascades［J］.Journal of Propulsion Technology,2020,41(9):1946-1957.(in Chinese)
[4]	STAATS M,NITSCHE W.Active control of the corner separation on a highly loaded compressor cascade with periodic non-steady boundary conditions by means of fluidic actuators［J］.Journal of Turbomachinery,2016,138(3):031004.1-031004.9.
[5]	NERGER D,SAATHOFF H,RADESPIEL R,et al.Experimental investigation of endwall and suction side blowing in a highly loaded compressor stator cascade［J］.Journal of Turbomachinery,2012,134(2):021010.1-021010.12.
[6]	陈浮,陈绍文,郭爽,等.高负荷压气机叶栅分离与流场结构研究［J］.工程热物理学报,2008,29(1):49-51. CHEN Fu,CHEN Shaowen,GUO Shuang,et al.Investigation of separation and flow field structure in high-loaded compressor cascade［J］.Journal of Engineering Thermophysics,2008,29(1):49-51.(in Chinese)
[7]	赵小虎,吴云,李应红,等.高负荷压气机叶栅分离结构及其等离子体流动控制［J］.航空学报,2012,33(2):208-219. ZHAO Xiaohu,WU Yun,LI Yinghong,et al.Separation structure and plasma flow control on highly loaded compressor cascade［J］.Acta Aeronautica et Astronautica Sinica,2012,33(2):208-219.(in Chinese)
[8]	张华良.采用叶片弯/掠及附面层抽吸控制扩压叶栅内涡结构的研究［D］.哈尔滨:哈尔滨工业大学,2007. ZHANG Hualiang.Investigation on application of dihedral/swept blade and boundary layer suction to control vortex configurations in compressor cascades［D］.Harbin:Harbin Institute of Technology,2007.(in Chinese)
[9]	KAN Xiaoxu,WANG Songtao,LUO Lei.Numerical analysis of the weight distribution of flow losses in a highly loaded compressor cascade with different incidences［J］.Applied Thermal Engineering,2018,139:552-561.
[10]	KAN Xiaoxu,LU Huawei,ZHONG Jingjun.Topological characterization of the vortex structures in the transonic compressor stator during the stalling process［J］.Journal of Aerospace Engineering,2016,230(3):566-580.
[11]	BESELT C,ECK M,PEITSCH D.Three-dimensional flow field in highly loaded compressor cascade［J］.Journal of Turbomachinery,2014,136(10):101007.1-101007.10.
[12]	ZHANG Yanfeng,MAHALLATI A,BENNER M.Experimental and numerical investigation of corner stall in a highly-loaded compressor cascade［R］.ASME Paper GT2014-27204,2014.
[13]	唐雨萌,柳阳威,陆利蓬,等.高速高负荷压气机叶栅损失特性实验研究［J］.工程热物理学报,2017,38(8):1624-1633. TANG Yumeng,LIU Yangwei,LU Lipeng,et al.Experimental investigation of losses in a high-speed high-loading compressor cascade［J］.Journal of Engineering Thermophysics,2017,38(8):1624-1633.(in Chinese)
[14]	HOU Anping,SHAN Shujun,WU Yu,et al.Investigation of low Reynolds number experiment and numerical simulation on compressor cascade［R］.ASME Paper IMECE2011-62639,2011.
[15]	白涛,王书贤.表面粗糙度对涡轮叶片吸力面边界层的影响［J］.西安工业大学学报,2016,36(8):647-651. BAI Tao,WANG Shuxian.Effect of surface roughness on side boundary layer of suction surface of tubine blades［J］.Journal of Xi’an Technological University,2016,36(8):647-651.(in Chinese)
[16]	SOLOMONW J,WALKER G J.Observations of wake-induced transition on an axial compressor blade［R］.ASME Paper 95-GT-381,1995.
[17]	DONG Y,CUMPSTY N A.Compressor blade boundary layers:Part 2 measurements with incident wakes［J］.Journal of Turbomachinery,1990,112(2):231-240.
[18]	王文涛,王子楠,张宏武,等.压气机静叶栅层流分离泡转捩与角区分离数值模拟与实验［J］.航空动力学报,2017,32(9):2273-2282. WANG Wentao,WANG Zinan,ZHANG Hongwu,et al.Numerical simulation and experiment of laminar separation bubble transition and corner separation of compressor stator cascade［J］.Journal of Aerospace Power,2017,32(9):2273-2282.(in Chinese)
[19]	KELTERERM E,PECNIK R,SANZ W.Computation of laminar-turbulence transition in turbomachinery using the correlation based γ-Reθ transition model［R］.ASME Paper GT2010-22207,2010.
[20]	MENTERF R,LANGTRY R B,LIKKI S R,et al.A correlation-based transition model using local variables:Part Ⅰ model formulation［J］.Journal of Turbomachinery,2006,128(3):413-422.
[21]	彭涛.压气机低能流体径向流动与失速机理研究［D］.哈尔滨:哈尔滨工程大学,2018.
