Simulation and sensitivity analysis of air system for the compressor test piece
-
摘要: 将空气系统简化为由节点和元件组成的一维拓扑网络,建立各部分的流动控制方程组,编制了仿真程序,利用循环中点求积牛顿法对方程组进行求解。将其应用于某压气机试验件空气系统计算,并对试验件空气系统的参数进行敏感性分析,探讨影响空气系统功能的主要因素。结果表明:利用参数微分法求解同伦方程,可增大牛顿法求解的收敛速度与收敛域;在该压气机试验件中,利用卸荷腔结构和封严能力较强的篦齿封严环可以将流路有效分隔开,有利于分别实现控制目标。Abstract: Based on fluid network method and mathematical models of components,the air system of engine compressor was simplified as a one-dimensional topological network composed of nodes and components.A program was developed to simulate this system for solving the flow control equations by the rotative mid-point mensuration combined with the Newton-Raphson method.The program was applied to simulation of the air system of a compressor test piece.The sensitivity analysis on the parameters of the air system of the test piece was carried out,and the main factors affecting the function of the air system were discussed.Results showed that the convergence speed and convergence region of Newton method can be increased by using the parametric differential method to solve the homotopy equation;in the compressor test piece,the flow path can be effectively separated by using the unloading chamber structure and the labyrinth with strong sealing ability,contributing to achieving the control objectives respectively.
-
[1] 焦华宾,莫松.航空涡轮发动机现状及未来发展综述[J].航空制造技术,2015,481(12):62-65. [2] 林宏镇,汪火光,蒋章焰.高性能航空发动机传热技术[M].北京:国防工业出版社,2005. [3] 曹玉璋,陶智.航空发动机传热学[M].北京:北京航空航天大学出版社,2004. [4] 王华阁,陆海鹰.《航空发动机设计手册》总编委会编航空发动机设计手册第16册[M].北京:航空工业出版社,2001. [5] CROSS H.Analysis of flow in networks of conduits or conductors[R].Urbana,US:University of Illinois Bulletin,1936. [6] DAMEROW W P,MURTAUGH J P.Experimental and analytical investigation of the coolant flow characteristics in cooled turbine airfoils[R].NASA GE-R72-AEG-165,1972. [7] KUMAR G,ROELKE R.A generalized one dimensional computer code for turbomachinery cooling passage flow calculations[R].AIAA-89-2574,1989. [8] KUTZ K J,SPEER T M.Simulation of the secondary air system of aero engines[J].Journal of Turbomachinery,1994,116(2):306-315. [9] MAJUMDAR A,STEADMAN T.Numerical modeling of pressurization of a propellant tank[R].AIAA 1999-0879,1999. [10] SCHALLHORN P A.Forward looking pressure regulator algorithm for improved modeling performance within the generalized fluid system simulation program[R].AIAA 2004-3667,2004. [11] 陆海鹰,杨燕生.航空发动机空气系统特性的数值模拟[J].航空发动机,1997,23(1):6-13. [12] 郭文,吉洪湖.高压涡轮导叶内冷通道流动特性计算分析[J].航空动力学报,2005,20(5):831-835. [13] 刘剑,张卫正.基于节点网络法的润滑系统图形化建模技术研究[J].润滑与密封,2006,31(2):59-62. [14] 王树刚,孙金鹏.用增量网络法计算稳态流体网络的微分灵敏度[J].建筑热能通风空调,2007,26(2):55-58. [15] 吕亚国,刘振侠,黄生勤.航空发动机内流空气系统通用分析软件设计[J].计算机仿真,2009,26(7):99-103. [16] 陶智,侯升平,韩树军,等.流体网络法在发动机空气冷却系统设计中的应用[J].航空动力学报,2009,24(1):1-6. [17] 胡肖肖,李育隆,吴宏.基于蒙特卡罗法的航空发动机稳态空气系统网络计算[J].航空发动机,2014,40(6):28-32. [18] 吴宏,胡肖肖.应用特征线法求解航空发动机瞬态空气系统[J].航空动力学报,2013,28(9):2003-2008. [19] 刘传凯,刘海明,李艳茹,等.强瞬变空气系统的模块化仿真建模[J].航空动力学报,2015,30(8):1826-1833. [20] 郭晓杰.航空发动机空气系统与热分析耦合方法研究[D].上海:上海交通大学,2014. [21] 梁津华,赵维维,徐连强,等.航空发动机空气系统和热分析的耦合计算与试验验证[J].燃气涡轮试验与研究,2019,32(3):24-28,52. [22] 孙宁彤,施小娟,吉洪湖.航空发动机整机空气系统流动与传热数值模拟[J].推进技术,2021,42(5):1130-1137. [23] 王新月.热力学与气体动力学基础[M].西安:西北工业大学出版社,2004. [24] 金勇,丁冰洁.水力摩阻手册(上册)[M].北京:水利水电规划设计院,1989. [25] HUNING M.Comparison of discharge coefficient measurements and correlations for orifices with cross-flow and rotation[J].Journal of Turbomachinery,2010,132(3):10-17. [26] MILLWARD J A,EDWARDS M F.Windage heating of air passing through labyrinth seals[J].Turbomachinery,1996,118(2):414-419. [27] 李庆扬,关治,白峰杉.数值计算原理[M].北京:清华大学出版社,2009.
