旋转FGMs层合圆柱壳行波模态频率分析

刘超; 刘文光; 吕志鹏; 张宇航

doi:10.13224/j.cnki.jasp.20210029

旋转FGMs层合圆柱壳行波模态频率分析

doi: 10.13224/j.cnki.jasp.20210029

南昌航空大学航空制造工程学院，南昌 330063

基金项目: 国家自然科学基金（51965042）

详细信息

作者简介:
刘超（1995-），男，硕士生，主要从事功能梯度板壳振动研究。

通讯作者:
刘文光（1978-），男，副教授、硕士生导师，博士，主要从事结构动力学和疲劳寿命预测研究。E-mail：liuwg14@nchu.edu.cn

中图分类号: V214.3+3
计量
- 文章访问数: 325
- HTML浏览量: 157
- PDF量: 61
- 被引次数: 0
出版历程
- 收稿日期: 2021-01-19
- 刊出日期: 2022-04-28

Analysis on traveling wave modal frequency of a rotating FGMs laminated cylindrical shell

School of Aeronautical Manufacturing Engineering，Nanchang Hangkong University，Nanchang 330063，China

摘要

摘要: 为推进功能梯度（FGMs）材料在发动机、导弹和火箭等领域的应用，旨在研究旋转FGMs层合圆柱壳的行波模态频率。采用Voigt模型和Sigmoid体积分数描述FGMs层合圆柱壳的材料属性，考虑科里奥利力、离心惯性力、环向初应力以及热内力推导了FGMs层合圆柱壳的能量表达式。采用切比雪夫正交多项式构造位移容许函数，建立了任意边界旋转FGMs层合圆柱壳的模态频率方程，并探讨了组分含量、夹层厚度、温度梯度和弹簧刚度系数等对FGMs层合圆柱壳模态频率的影响。结果表明：夹层厚度相比Sigmoid体积分数对模态频率的变化更为敏感；高旋转短薄壁圆柱壳相比长薄壁圆柱壳对边界条件和失稳现象的影响更为敏感；轴向弹簧相比其他弹簧对模态频率的影响更大。
- FGMs层合圆柱壳 /
- 旋转速度 /
- 模态频率 /
- 任意边界 /
- 切比雪夫多项式
Abstract: For prompting the application of functionally graded materials （FGMs） in the fields of engines，missiles and rockets，the traveling wave modal frequencies of rotating FGMs laminated cylindrical shell were studied.The Voigt model and Sigmoid volume fraction were employed to describe the material properties of the FGMs laminated cylindrical shell.The energy expression of the rotating FGMs laminated cylindrical shell was derived with the Coriolis force，centrifugal inertial force，hoop initial tension and thermal internal force involved.The modal frequency equation of the FGMs laminated cylindrical shell with arbitrary boundary conditions was derived by using the Chebyshev orthogonal polynomial as the admissible displacement function.And the effects of material components，sandwich thickness，temperature gradient and spring stiffness coefficients on the modal frequency of the FGMs laminated cylindrical shell were discussed.Results indicate that the sandwich thickness is more sensitive to the traveling wave mode than the Sigmoid volume fraction index；the short thin-walled cylindrical shell is more sensitive to boundary conditions and instability than the long thin-walled structures at high rotation speeds；the axial spring stiffness has a greater effect on the traveling wave mode than other spring stiffness.
- FGMs laminated cylindrical shell /
- rotating speed /
- modal frequency /
- arbitrary boundary /
- Chebyshev polynomials

HTML

参考文献(21)

[1]	李凯伦，张家忠，王赵波.超声速流动中功能梯度曲壁板的热气动弹性颤振机理[J].航空动力学报，2018，33（8）:1905-1915.
[2]	刘超，刘文光.金属陶瓷功能梯度板的模态频率分析[J].航空材料学报，2020，40（5）:88-95.
[3]	BRYAN G H.On the beats in the vibrations of a revolving cylinder or bell[J].Proceedings of the Cambridge Philosophical Society，1890，7:101-111.
[4]	DITARANTO R A，LESSEN M.Coriolis acceleration effect on the vibration of a rotating thin-walled circular cylinder[J].Journal of Applied Mechanics，1964，31（4）:700-701.
[5]	SRINIVASAN A V，LAUTERBACH G F.Traveling waves in rotating cylindrical shells[J].Journal of Engineering for Industry，1971，93（4）:1229-1232.
[6]	SAITO T，ENDO M.Vibration of finite length，rotating cylindrical shells[J].Journal of Sound and Vibration，1986，107（1）:17-28.
[7]	项松，李广超，张魏，等.旋转功能梯度圆柱壳的固有频率计算[J].应用数学和力学，2012，33（3）:332-341.
[8]	LIANG B，XIANG S，LI R，et al.Study of effective factors for the vibration of rotating functionally graded cylindrical shells[J].Journal of Ship Mechanics，2013，17（12）:1460-1472.
[9]	HOSSEINI-HASHEMI S，ILKHANI M R，FADAEE M.Accurate natural frequencies and critical speeds of a rotating functionally graded moderately thick cylindrical shell[J].International Journal of Mechanical sciences，2013，76（1/2）:9-20.
[10]	孙述鹏，曹登庆，初世明.转动薄壁圆柱壳行波振动响应分析[J].振动工程学报，2013，26（3）:161-168.
[11]	SHENG G G，WANG X.The nonlinear vibrations of rotating functionally graded cylindrical shells[J].Nonlinear Dynamics，2017，87（2）:1095-1109.
[12]	SAADATFAR M，AGHAIE K M.Thermoelastic analysis of a rotating functionally graded cylindrical shell with functionally graded sensor and actuator layers on an elastic foundation placed in a constant magnetic field[J].Journal of Intelligent Material Systems and Structures，2016，27（4）:512-527.
[13]	TALEBITOOTI M.Three-dimensional free vibration analysis and critical speed of pressurized rotating functionally graded cylindrical shells[J].Iranian Journal of Science and Technology，Transactions of Mechanical Engineering，2019，43（2）:113-126.
[14]	李文达，杜敬涛，杨铁军，等.基于改进傅里叶级数方法的旋转功能梯度圆柱壳振动特性分析[J].哈尔滨工程大学学报，2016，37（3）:388-393.
[15]	WANG Q S，SHI D Y，LIANG Q，et al.Free vibration of four-parameter functionally graded moderately thick doubly-curved panels and shells of revolution with general boundary conditions[J].Applied Mathematical Modelling，2017，42:705-734.
[16]	JIN G Y，SHI S X，SU Z，et al.A modified Fourier–Ritz approach for free vibration analysis of laminated functionally graded shallow shells with general boundary conditions[J].International Journal of Mechanical sciences，2015，93:256-269.
[17]	QIN Z Y，CHU F L，ZU J.Free vibrations of cylindrical shells with arbitrary boundary conditions:a comparison study[J].International Journal of Mechanical Sciences，2017，133:91-99.
[18]	HEYDARPOUR Y，MALEKZADEH P，GOLBAHAR HAGHIGHI M R，et al.Thermoelastic analysis ofrotating laminated functionally graded cylindrical shells using layerwise differential quadrature method[J].Acta Mechanica，2012，223（1）:81-93.
[19]	SHEN H S.Nonlinear vibration of shear deformable FGM cylindrical shells surrounded by an elastic medium[J].Composite Structures，2012，94（3）:1144-1154.
[20]	LOY C T，LAM K Y，REDDY J N.Vibration of functionally graded cylindrical shells[J].International Journal of Mechanical sciences，1999，41（3）:309-324.
[21]	李文达，杜敬涛，杨铁军,等.边界条件对旋转薄壁圆柱壳结构自由振动行波特性的影响分析[J].振动工程学报，2016,29（3）:452-464.
