不同压比状态下超声速射流冲击斜板的声场/流场特性

齐龙舟; 冯和英; 赵鲲; 张俊龙; 覃晨

doi:10.13224/j.cnki.jasp.20210042

不同压比状态下超声速射流冲击斜板的声场/流场特性

doi: 10.13224/j.cnki.jasp.20210042

齐龙舟¹,
冯和英^1, ,,
赵鲲^2,3,
张俊龙²,
覃晨²

1.
湖南科技大学机械设备健康维护湖南省重点实验室，湖南湘潭 411201
2.
中国空气动力研究与发展中心空气动力学国家重点实验室，四川绵阳 621000
3.
中国空气动力研究与发展中心气动噪声控制重点实验室，四川绵阳 621000

基金项目: 国家自然科学基金（51875194）；空气动力学国家重点实验室研究基金（SKLA2019020101）

详细信息

作者简介:
齐龙舟（1999-），男，硕士生，主要从事超声速射流噪声研究。

通讯作者:
冯和英（1983-），女，副教授，博士，主要研究方向为气动声学。E-mail：fengheying@hnust.edu.cn

中图分类号: V211.7;O358;O422.2
计量
- 文章访问数: 430
- HTML浏览量: 148
- PDF量: 96
- 被引次数: 0
出版历程
- 收稿日期: 2021-04-26
- 刊出日期: 2021-12-28

Sound field/flow field characteristics of supersonic jet impinging on inclined plate under different pressure ratios

1.
Hunan Provincial Key Laboratory of Health Maintenance for Mechanical Equipment， Hunan University of Science and Technology，Xiangtan Hunan 411201，China
2.
State Key Laboratory of the Aerodynamics，China Aerodynamics Research and Development Center，Mianyang Sichuan 621000，China
3.
Key Laboratory of Aerodynamic Noise Control，China Aerodynamics Research and Development Center，Mianyang Sichuan 621000，China

摘要

摘要: 为研究超声速射流冲击斜板的噪声特性及声源特性，针对不同压比下，超声速射流流场及声场分别进行了高频PIV（particle image velocimetry)测量与远场噪声测量。PIV测量结果可观测到激波格栅形成过程以及冲击斜板对它的影响。声场测量结果可捕捉到自由射流与冲击射流中不同的纯音频率随压比增加的转变过程。通过一一对比各纯音模态与流场模态，可区分各纯音模态的声源特性。结果表明：当压比在2.0~3.2之间时，共出现五种纯音模态：A模态纯音频率为剪切层大尺度涡脱落频率，此时流场呈现同轴模态；d模态和e模态中纯音频率主要为冲击纯音频率，且e模态出现时流场转化为螺旋模态，这是一种不稳定模态；当压比大于等于2.53时，纯音模态稳定成单一模态B，B模态纯音频率为啸叫频率，其流场结构转化回同轴模态，啸叫频率对斜板的存在与否不敏感；啸叫频率随着压比的增加逐渐减小，其二次谐频在基频幅值较小的方向上会出现一个强声波辐射。
- 射流冲击斜板 /
- 模态分析 /
- 啸声 /
- PIV流场分析 /
- 传声器弧阵列
Abstract: In order to study the noise characteristics and sound source characteristics of the supersonic jet impinging on the inclined plate，the flow field and sound field of the supersonic jet under different pressure ratios were measured by high-frequency PIV （particle image velocimetry） and far-field noise.PIV measurement results can be used to observe the formation process of the shock grid and the impact of the inclined plate.The sound field measurement results can be used to capture the transition process of different tone frequencies in the free jet and the impinging jet as the pressure ratio increased.By comparing each tone mode and flow field mode one by one，the sound source characteristics of each tone mode can be distinguished.When pressure ratio was between 2.0-3.2，there were five tone modes：the tone of A mode was taken as the shear layer large-scale vortex shedding frequency，and the flow field presented a coaxial mode；the tone frequencies of the d and e modes were mainly taken as an impinging tone frequency；when the e mode appeared，the flow field transformed into a spiral mode，which was an unstable mode；when pressure ratio was more than 2.53，the tone mode was stable to a single mode B，and the tone of the B mode was taken as the screech frequency.The structure was converted back to the coaxial mode，and the screech frequency was not sensitive to the presence or absence of the inclined plate；the tone frequency of the B mode gradually decreased with the increase of the pressure ratio，and for the second harmonic frequency there was a strong sound wave radiation in the direction of the smaller amplitude of the fundamental frequency.
- jet impinging on the inclined plate /
- modal analysis /
- screech tone /
- PIV flow field analysis /
- microphone arc array

HTML

参考文献(23)

[1]	FILIPPONE A.Aircraft noise prediction[J].Progress in Aerospace Sciences，2014，68（l）:27-63.
[2]	MOREAU D J，GEYER T F，DOOLAN C J，et al.Surface curvature effects on the tonal noise of a wall-mounted finite airfoil[J].The Journal of the Acoustical Society of America，2018，143（6）:3460-3473.
[3]	朱志斌，程晓丽，潘宏禄.超声速喷流混合流场大涡模拟[J].航空动力学报，2019,34（1）:210-216.
[4]	BREHM C，HOUSMAN J A，KIRIS C C.Noise generation mechanisms for a supersonic jet impinging on an inclined plate[J].Journal of Fluid Mechanics，2016，797:802-850.
[5]	NONOMURA T，FUJII K.Over-expansion effects on Mach 3.0 supersonic jet acoustics[R].AIAA 2008-2836,2008.
[6]	UZUN A，KUMAR R，HUSSAINI M Y，et al.Simulation of tonal noise generation by supersonic impinging jets[J].AIAA Journal，2013，51（7）:1593-1611.
[7]	FRENDI A，BROWN M R.Flow structures and noise from a supersonic impinging jet[J].International Journal of Numerical Methods for Heat and Fluid Flow，2016，26（8）:1-20.
[8]	GOJON R，BOGEY C，MARSDEN O.Large-eddy simulation of under-expanded round jets impinging on a flat plate 4 to 9 radii downstream from the nozzle[R].AIAA 2015-2210,2015.
[9]	THOMAS D.Supersonic rectangular jet impingement noise experiments[J].AIAA Journal，1991，29（7）:1051-1057.
[10]	SHEPLAK M，SPINA E F.Control of high-speed impinging-jet resonance[J].AIAA Journal，1994，32（8）:1583-1588.
[11]	SINIBALDI G，LACAGNINA G，MARINO L，et al.Aeroacoustics and aerodynamics of impinging supersonic jets:analysis of the screech tones[J].Physics of Fluids，2013，25（8）:393-405.
[12]	汪洋海，李晓东.超声速喷流啸声的控制方法[J].推进技术，2007，28（2）:211-215.
[13]	张俊龙，雷红胜，田昊，等.亚声速矩形射流的噪声辐射特性和声源分布[J].航空学报，2020,41（2）:132-141.
[14]	VALENTICH G，UPADHYAY P，KUMAR R.Mixing characteristics of a moderate aspect ratio screeching supersonic rectangular jet[J].Experiments in Fluids，2016，57（5）:1-14.
[15]	沈鑫垚，毛军逵，刘方圆，等.基于PIV技术的单圆孔脉冲射流流场特征[J].航空动力学报，2020,35（9）:1845-1855.
[16]	王庆宇，刘琪麟，赖焕新.高亚声速喷流近场的流-声关联[J].航空动力学报，2020,35（12）:2532-2542.
[17]	UMEDA Y，ISHII R.On the sound sources of screech tones radiated from choked circular jets[J].The Journal of the Acoustical Society of America，2001，110（4）:1845-1858.
[18]	DAUPTAIN A，CUENOT B，GICQUEL L Y M.Large eddy simulation of stable supersonic jet impinging on flat plate[J].AIAA Journal，2010,48（10）:2325-2338.
[19]	葛其明，姚朝晖，何枫.超声速欠膨胀冲击射流流场振荡的数值模拟[J].推进技术，2004，25（1）:7-10.
[20]	何枫,谢峻石,姚朝晖.超声速欠膨胀冲击射流的数值模拟[J].推进技术,2002，23（2）:96-99.
[21]	POWELL A.On the edge tone[J].The Journal of the Acoustical Society of America，1961，33（4）:395-409.
[22]	POWELL A.On edge tones and associated phenomena[J].Acta Acustica United with Acustica,1953,3:233-243.
[23]	POWELL A.Observations of the oscillation modes of choked circular jets[J].The Journal of the Acoustical Society of America，1992，92（5）:2823-2836.
