声电换能超材料设计与性能

吕海峰; 余瀚海; 叶俊杰; 马智宇; 张景惠; 李静

doi:10.13224/j.cnki.jasp.20210064

声电换能超材料设计与性能

doi: 10.13224/j.cnki.jasp.20210064

1.
中北大学机械工程学院，太原 030051
2.
北京市地铁运营有限公司运营一分公司，北京 102209

基金项目: 国家自然科学基金（51305409）；山西省重点研发计划项目（201903D221025）

详细信息

作者简介:
吕海峰（1981-），男，副教授、硕士生导师，博士，主要研究方向为振动与噪声控制研究。

中图分类号: V216.5+4;TB535+.2
计量
- 文章访问数: 77
- HTML浏览量: 9
- PDF量: 49
- 被引次数: 0
出版历程
- 收稿日期: 2021-02-09
- 刊出日期: 2022-01-28

Design and performance of metamaterials for acoustic-electric energy conversion

1.
School of Mechanical Engineering，North University of China，Taiyuan 030051，China
2.
The First Operation Branch， Beijing Mass Transit Railway Operation Corporation Limited，Beijing 102209，China

摘要

摘要: 设计了一种将Helmholtz共振效应与压电效应结合的声电换能超材料结构及电路系统，通过传递矩阵法对超材料的能带结构进行了分析。以压电片作为Helmholtz共振器基底通过阵列形成超材料结构。当入射噪声频率与共振频率一致时，声电转换效率最高。利用COMSOL分别对超材料单元及系统进行仿真，验证了超材料单元对于噪声的抑制作用；研究了超材料单元串并联方式对声电换能效率的影响规律；采用整流桥设计了交直流转换电路，采用超级电容设计了储能电路。测试结果表明：所设计的声电换能超材料系统的最优直流负载为250 kΩ。当声波以共振频率入射驱动时，系统的声电功率最大为1 523 μW，实现了声电的能量转换、调理与储能。
- 噪声 /
- 超材料 /
- 共振 /
- 电能 /
- 能带
Abstract: A metamaterial structure for acoustic-electric energy conversation and circuit system combining Helmholtz resonance effect and piezoelectric effect was designed，and the energy band structure of the metamaterial was analyzed by the transfer matrix method.The piezoelectric sheet was used as the Helmholtz resonator substrate to form a metamaterial structure through an array.When the incident noise frequency was consistent with the resonance frequency，the acoustic-electric conversion efficiency was the highest.Using COMSOL to simulate the metamaterial unit and the system respectively，the effect of the metamaterial unit on noise suppression was verified.The influence of the series-parallel mode of the metamaterial unit on the efficiency of acoustic-electric conversion was studied.A rectifier bridge was used to design an alternating current/direct current converter，and super capacitor was adopted to design the energy storage circuit.The test results showed that the optimal direct current load of the designed metamaterials system for acoustic-electric energy conversion was 250 kΩ.With the incident driving of the sound wave at the resonance frequency，the maximum acoustic-electric power of the system was 1 523 μW，which realized the energy conversion，conditioning and energy storage of acoustic-electric.
- noise /
- metamaterials /
- resonance /
- electric energy /
- energy band

HTML

参考文献(20)

[1]	MA K J，TAN T，LIU F R，et al.Acoustic energy harvesting enhanced by locally resonant metamaterials[J].Smart Materials and Structures，2020，29（7）:075025.1-075025.12.
[2]	WU L Y，CHEN L W，LIU C M.Acoustic energy harvesting using resonant cavity of a sonic crystal[J].Applied Physics Letters，2009，95（1）:013506.1-013506.3.
[3]	CHOI J，JUNG I，KANG C Y.A brief review of sound energy harvesting[J].Nano Energy，2019，56（3）:169-183.
[4]	IZHAR,KHAN F U.Electromagnetic-based acoustic energy harvester[R].Lahore,Pakistan:International Multitopic Conference，2013.
[5]	EGHBALI P，YOUNESIAN D，FARHANGDOUST S.Enhancement of the low-frequency acoustic energy harvesting with auxetic resonators[J].Applied Energy，2020，270:1-10.
[6]	LI B，YOU J H，KIM Y J.Low frequency acoustic energy harvesting using PZT piezoelectric plates in a straight tube resonator[J].Smart Materials and Structures，2013，22（5）:055013.1-055013.9.
[7]	PILLAI M A，EZHILARASI D.Improved acoustic energy harvester using tapered neck helmholtz resonator and piezoelectric cantilever undergoing concurrent bending and twisting[J].Procedia Engineering，2016，144:674-681.
[8]	YUAN M，CAO Z，LUO J，et al.Low frequency acoustic energy harvester based on a planar Helmholtz resonator[J].AIP Advances，2018，8（8）:08501-085012.
[9]	YANG A，LI P，WEN Y，et al.Note:high-efficiency broadband acoustic energy harvesting using Helmholtz resonator and dual piezoelectric cantilever beams[J].Review of Scientific Instruments，2014，85（6）:015035.1-015035.4.
[10]	刘子牛.局域共振型压电超材料薄板振动能量俘获特性理论与实验研究[D].长沙：国防科技大学,2017.
[11]	刘晓峻.声学超材料的机遇和挑战[J].科学通报,2020,65（15）:1395.
[12]	张晓光,吕海峰,吕传茂,等.双局域共振效应声学超材料消声性能[J].航空动力学报,2020,35（1）:52-59.
[13]	吕海峰,王普浩,叶俊杰，等.局域共振型声学超材料及其噪声控制[J].航空动力学报,2020,35（7）:1369-1375.
[14]	刘子牛,陈仲生,张帆.局域共振型压电薄板建模及振动特性仿真分析[R].北京：中国力学大会：2017暨庆祝中国力学学会成立60周年大会,2017.
[15]	WANG Yuan，ZHU Xin，ZHANG Tingsheng，et al.A renewable low-frequency acoustic energy harvesting noise barrier for high-speed railways using a Helmholtz resonator and a PVDF film[J].Applied Energy，2018，230:52-61.
[16]	陈鹏,吕海峰,安君,等.异形腔体压电声衬声学性能[J].航空动力学报,2018,33（12）:2999-3006.
[17]	李雁飞，沈惠杰，章林柯，等.超材料型周期管路声传播特性及低频宽带控制[J].声学学报，2017，42（3）:334-340.
[18]	曹晓丰,郁殿龙,刘江伟,等.周期性附加单腔赫姆霍兹共鸣器一维管路声带隙耦合分析[J].振动与冲击,2016,35（19）:20-25.
[19]	顾聪,陈远晟,王浩,等.直管谐振式低频压电声能量回收系统[J].电子学报,2020,48（10）:2071-2076.
[20]	YUAN M，CAO Z，LUO J,et al.An efficient low-frequency acoustic energy harvester[J].Sensors and Actuators A，2017，264（1）:84-89.
