不同工况下高速角接触球轴承-刚性转子系统动力学耦合特性分析

陈世金; 王瑞祥; 陈晓阳; 顾家铭; 刘朝霞

doi:10.13224/j.cnki.jasp.20210082

不同工况下高速角接触球轴承-刚性转子系统动力学耦合特性分析

doi: 10.13224/j.cnki.jasp.20210082

1.
上海大学机电工程与自动化学院，上海 200072
2.
上海进顺机电技术有限公司，上海 200072
3.
上海集优机械股份有限公司上海天虹微型轴承有限公司，上海 200125
4.
中国航天电子技术研究院北京航天控制仪器研究所，北京 100039

基金项目: 国家“十二五”基础科研项目上海大学子项（上海大学编号：D.50-0109-15-001）

详细信息

作者简介:
陈世金（1993-），男，博士生，主要从事滚动轴承-转子系统动力学研究。

中图分类号: V241.5+9;TH133.33
计量
- 文章访问数: 102
- HTML浏览量: 12
- PDF量: 107
- 被引次数: 0
出版历程
- 收稿日期: 2021-02-23
- 刊出日期: 2022-02-28

Analysis of dynamic coupling characteristics of high speed angular contact ball bearing-rigid rotor system under different working conditions

1.
School of Mechanical and Electrical Engineering and Automation，Shanghai University，Shanghai 200072，China
2.
Shanghai Jinshun Electromechanical Technology Company Limited，Shanghai 200072，China
3.
Shanghai Tianhong Miniature Bearing Company Limited，Shanghai Prime Machinery Company Limited，Shanghai 200125，China
4.
Beijing Institute of Aerospace Control Devices，China Academy of Aerospace Electronics Technology，Beijing 100039，China

摘要

摘要: 根据建立的高速角接触球轴承-刚性转子系统动力学数值仿真模型，以某仪表轴承支承的转子系统为算例，分析了考虑转子振动与否对系统动力学性能的影响，并详细探究了轴向载荷以及转速对转子振动、轴承内部载荷分布及旋滚比、保持架的受力和质心运动以及磨损情况的影响。结果表明：考虑转子振动时，在纯轴向载荷下，轴承各位置处的球载荷也会存在差异，且保持架质心运动包含内圈频率，运动稳定性变差；随着轴向载荷的增大，转子振动逐渐减弱，轴承打滑减小，但由于轴承球载荷的增大，内、外圈滚道磨损呈现先减小后增大的趋势，并在轴向载荷为4 N时磨损最小；保持架稳定性和磨损则均随着轴向载荷的增大而增大；随着转速的增大，转子振动加强，内、外圈沟道及保持架磨损均加剧，保持架稳定性先增强后减弱，且在转速达到40 000 r/min后，轴承磨损和保持架稳定性急剧恶化。
- 轴承-转子系统 /
- 动力学 /
- 保持架 /
- 振动 /
- 载荷 /
- 转速
Abstract: According to the established complete dynamic numerical simulation model of high-speed angular contact ball bearing-rigid rotor system，the effect of rotor vibration on the dynamic performance of the system was analyzed，and the effects of axial load and rotating speed on rotor vibration，load distribution and spin-roll ratio in bearing，cage mass center motion wear were also discussed.The results showed that：when the rotor vibration was considered，the ball load at each position of the bearing differed even under the pure axial load，and for the cage mass center motion including the inner ring frequency，its stability became poor.With the increase of axial load，the rotor vibration and bearing slip decreased.However，with the increase of bearing ball load，the wear of inner and outer raceways first decreased and then increased，and the wear was the minimum when the axial load was 4 N.Both the cage stability and wear increased with the increase of axial load.With the increase of the rotating speed，the vibration of the rotor and bearing wear increased，while the stability of the cage first increased and then decreased.Once the rotating speed reached 40 000 r/min，the bearing wear and the cage stability deteriorated sharply.
- bearing-rotor system /
- dynamics /
- cage /
- vibration /
- load /
- rotation speed

HTML

参考文献(26)

[1]	张涛,陈晓阳,顾家铭,等.高速角接触球轴承保持架稳定性研究进展[J].航空学报,2018,39（7）:27-39.
[2]	李松生.超高速电主轴球轴承-转子系统动力学性能的研究[D].上海：上海大学,2006.
[3]	WALTERS C T.The dynamics of ball bearings[J].Journal of Tribology,1971,93（1）:1-10.
[4]	MEEKS C.The dynamics of ball separators in ball bearings:Part Ⅱ results of optimization study[J].American Society of Lubricating Engineers Transactions,1985,28（3）:288-295.
[5]	NOGI T,MANIWA K,MATSUOKA N.A dynamic analysis of cage instability in ball bearings[J].Journal of Tribology,2017,140（1）:011101.1-011101.12.
[6]	GUPTA P K.Frictional instabilities in ball bearings[J].Tribology Transactions,1988,31（2）:258-268.
[7]	BOVET C,ZAMPONI L.An approach for predicting the internal behaviour of ball bearings under high moment load[J].Mechanism and Machine Theory,2016,101（1）:1-22.
[8]	LIU Xiuhai,DENG Sier,TENG Hongfei.Dynamic stability analysis of cages in high-speed oil-lubricated angular contact ball bearings[J].Transactions of Tianjin University,2011,17（1）:20-27.
[9]	WEN Baogang,REN Hongjun,ZHANG Hao,et al.Experimental investigation of cage motions in an angular contact ball bearing[J].Proceedings of the Institution of Mechanical Engineers:Part J Journal of Engineering Tribology,2017,231（8）:1041-1055.
[10]	CHEN Shijin,CHEN Xiaoyang,LI Qingqing,et al.Experimental study on cage dynamic characteristics of angular contact ball bearing in acceleration and deceleration process[J].Tribology Transaction,2020,64（1）:42-52.
[11]	GUPTA P K.Modeling of instabilities induced by cage clearances in ball bearings[J].Tribology Transactions,1991,34（1）:93-99.
[12]	MASSIMO P S,GIUSEPPE N,WYGACHIEWICZ M.Analysis and monitoring of cage dynamics in ball bearings for space applications[R].Hatfield,UK:European Space Mechanisms and Tribology Symposium（ESMATS）,2017.
[13]	邓四二,李兴林,汪久根,等.角接触球轴承摩擦力矩特性研究[J].机械工程学报,2011,47（5）:114-120.
[14]	CHEN Shijin,CHEN Xiaoyang,SHUAI Qiqi,et al.Effects of cage pocket shapes on dynamics of angular contact ball bearings[J].Tribology Online,2020,15（1）:343-355.
[15]	KARACAY T,AKTURK N.Vibrations of a grinding spindle supported by angular contact ball bearings[J].Proceedings of the Institution of Mechanical Engineers：Part K Journal of Multi-body Dynamics,2008,222（1）:61-75.
[16]	TIWARI M,GUPTA K,PRAKASH O.Dynamic response of an unbalanced rotor supported on ball bearings[J].Journal of Sound and Vibration,2000,238（5）:757-779.
[17]	HARSHA S P.Nonlinear dynamic analysis of an unbalanced rotor supported by roller bearing[J].Chaos Solitons and Fractals,2005,26（1）:47-66.
[18]	HARSHA S P.Nonlinear dynamic analysis of rolling element bearings due to cage run-out and number of balls[J].Journal of Sound and Vibration,2006,289（1/2）:360-381.
[19]	KANKAR P K,SHARMA S C,HARSHA S P,et al.Dynamic response of an unbalanced rotor supported on bearing with outer race waviness[M].New York:American Society of Mechanical Engineers,2014.
[20]	TIWARI M,GUPTA K,PRAKASH O.Effect of radial internal clearance of a ball,bearing on the dynamics of a balanced horizontal rotor[J].Journal of Sound and Vibration,2000,238（5）:723-756.
[21]	UPADHYAY S H,HARSHA S P,JAIN S C.Analysis of nonlinear phenomena in high speed ball bearings due to radial clearance and unbalanced rotor effects[J].Journal of Vibration and Control,2010,16（1）:65-88.
[22]	叶振环.航空发动机高速滚动轴承动力学行为研究[D].哈尔滨：哈尔滨工业大学,2013.
[23]	LI Yamin,CAO Hongrui,NIU Linkai,et al.A general method for the dynamic modeling of ball bearing-rotor systems[J].Journal of Manufacturing Science and Engineering,2015,137（2）:021016.1-021016.12.
[24]	WEN Baogang,WANG Meiling,ZHOU Xianwen,et al.Multi-harmonic motions of bearing cage affected by rotor unbalance[J].Journal of Mechanical Engineering Science,2018,232（15）:2610-2625.
[25]	ZHANG Tao,CHEN Xiaoyang,GU Jiaming,et al.Influences of preload on the friction and wear properties of high-speed instrument angular contact ball bearings[J].Chinese Journal of Aeronautics,2018,31（3）:597-607.
[26]	陈世金,帅琪琪,陈晓阳,等.转子不平衡对角接触球轴承-刚性转子系统动力学耦合特性的影响[J].航空动力学报,2021,36（10）:2126-2138.
