叶顶喷气对凹槽叶尖气动性能的影响

轩笠铭; 邹正平; 赵强; 黄霖; 杜金霖; 陈云

doi:10.13224/j.cnki.jasp.20210104

叶顶喷气对凹槽叶尖气动性能的影响

doi: 10.13224/j.cnki.jasp.20210104

轩笠铭¹,
邹正平^1,2, ,,
赵强¹,
黄霖¹,
杜金霖¹,
陈云³

1.
北京航空航天大学能源与动力工程学院航空发动机气动热力国家级重点实验室，北京 100191
2.
北京航空航天大学航空发动机研究院，北京 102206
3.
中国航空发动机集团有限公司沈阳发动机研究所，沈阳 110015

基金项目: 国家自然科学基金（51676005）

详细信息

作者简介:
轩笠铭（1993-），男，博士生，主要从事叶轮机械气动热力学研究。

通讯作者:
邹正平（1970-），男，教授，博士，主要从事高超声速航空发动机、叶轮机气体动力学研究。E-mail：zouzhengping@buaa.edu.cn

中图分类号: V231.3
计量
- 文章访问数: 454
- HTML浏览量: 232
- PDF量: 75
- 被引次数: 0
出版历程
- 收稿日期: 2021-03-09
- 刊出日期: 2022-05-28

Effect of tip injection on aerodynamic performance of squealer tip

1.
National Key Laboratory of Science and Technology on Aero-Engine Aero-thermodynamics，School of Energy and Power Engineering，Beihang University，Beijing 100191，China
2.
Research Institute of Aero-Engine，Beihang University，Beijing 102206，China
3.
Shenyang Engine Research Institute，Aero Engine Corporation of China,Shenyang 110015，China

摘要

摘要: 对某型航空发动机高压涡轮转子叶片通过相似变换得到的低速叶型进行研究，探讨叶尖机匣相对运动条件下，叶顶喷气对凹槽叶尖气动性能的影响。结果表明：叶顶喷气对平叶尖的气动性能影响有限，但会降低凹槽叶尖效率；在相同喷气条件下，使用凹槽叶尖相比于使用平叶尖可降低20%的叶尖泄漏损失；泄漏流在凹槽内部的能量耗散主要来自于泄漏流动与凹槽涡和刮削涡的相互作用，在喷气条件下，刮削涡仍然是泄漏流动的主要控制结构。喷气位置对凹槽叶尖性能有显著的的影响；在靠近吸力侧和前缘布置喷气孔，有利于凹槽气动性能的提升；基于以上研究，建立可用于凹槽叶尖的泄漏流动损失模型，新模型相比Denton模型误差降低了31.6%。
- 凹槽叶尖 /
- 叶尖泄漏流动 /
- 叶顶喷气 /
- 气动性能 /
- 流动机理 /
- 损失模型
Abstract: A low-speed blade profile of a certain aero-engine high-pressure turbine rotor blade obtained by similarity transformation was studied,and the effect of tip injection on the aerodynamic performance of the squealer tip under the condition of relative casing motion was discussed.The results showed that tip injection had limited effect on the aerodynamic performance of the flat tip,but it could reduce the efficiency of the squealer tip.Under the same injection condition,the squealer tip can reduce the tip leakage loss by 20% compared with the flat tip.The energy dissipation of the leakage flow in the cavity mainly came from the interaction of the leakage flow with cavity vortex and scraping vortex.Under the injection condition,scraping vortex was still the dominant flow structure of the leakage flow.The injection position had a significant effect on the performance of the squealer tip; the jet holes near the suction side and leading edge were conducive to the improvement of the aerodynamic performance.Based on the above research,a leakage flow loss model for the squealer tip was established,and the error of new model was reduced by 31.6% compared with the Denton model.
- squealer tip /
- tip leakage flow /
- tip injection /
- aerodynamic performance /
- flow mechanism /
- loss model

HTML

参考文献(30)

[1]	DENTON J D.The 1993 IGTI scholar lecture:loss mechanisms in turbomachines[J].Journal of Turbomachinery,1993,115（4）:621-656.
[2]	HAN J C.Fundamental gas turbine heat transfer[J].Journal of Thermal Science & Engineering Applications,2013,5（2）:021007.1-021007.15.
[3]	ZOU Z,WANG S,LIU H,et al.Axial turbine aerodynamics for aero-engines[M].Singapore City,Singapore:Springer,2018.
[4]	邹正平,綦蕾,李维,等.上游尾迹与涡轮转子泄漏流相互作用数值模拟[J].航空动力学报,2010,25（1）:58-66.
[5]	BINDON J P.The measurement and formation of tip clearance loss[J].Journal of Turbomachinery,1989,111（3）:257-263.
[6]	YARAS M I,SJOLANDER S A.Prediction of tip leakage losses in axial turbine[J].ASME Paper 90-GT-154,1990.
[7]	GAO J,ZHENG Q,XU T,et al.Inlet conditions effect on tip leakage vortex breakdown in unshrouded axial turbines[J].Energy,2015,91:255-263.
[8]	HUANG A.Loss mechanisms in turbine tip clearance[D].Cambridge,USA:Massachusetts Institute of Technology,2011.
[9]	魏佐君,段文华,乔渭阳,等.涡轮转子叶尖泄漏涡涡核稳定性及控制[J].航空动力学报,2018,33（9）:2139-2149.
[10]	BUNKER R S.Axial turbine blade tips:function,design,and durability[J].Journal of Propulsion and Power,2006,22（2）:271-285.
[11]	HEYS F J G,HODSON H P.The effect of blade tip geometry on the tip leakage flow in axial turbine cascades[J].Journal of Turbomachinery,1992,114（3）:643-651.
[12]	邹正平,姚李超,轩笠铭,等.涡轮转子凹槽叶尖泄漏流动气动热力特征[J].推进技术,2020,41（9）:1975-1987.
[13]	ZOU Z,SHAO F,LI Y,et al.Dominant flow structure in the squealer tip gap and its impact on turbine aerodynamic performance[J].Energy,2017,138:167-184.
[14]	杜金霖,邹正平,黄霖,等．计及机匣相对运动的涡轮叶片叶顶凹槽流动研究[J].实验流体力学,2021,35（2）:22-35.
[15]	KRISHNABABU S K,NEWTON P J,DAWES W N,et al.Aero-thermal investigations of tip leakage flow in axial flow turbines:Part Ⅰ effect of tip geometry and tip clearance gap[J].Journal of Turbomachinery，2009，131（1）:1-14.
[16]	KEGALJ M,SCHMID G,SCHIFFER H P,et al.Experimental and numerical investigation of tip leakage flow in a 1/2 stage turbine rig comparing flat and cavity-squealer tip geometries[R].ASME Paper GT2012-69568,2012.
[17]	杜昆,李军.涡轮叶片凹槽状叶顶非定常流动传热特性的数值研究[J].推进技术,2017,38（3）:551-558.
[18]	皮骏,杜旭博,孔庆国,等.冲击式凹槽叶尖流动换热特性[J].航空动力学报,2019,34（2）:331-340.
[19]	王维杰,卢少鹏,马海腾,等.高压涡轮尾切凹槽叶尖冷却换热特性[J].航空动力学报,2019,34（10）:2131-2139.
[20]	VOLINO R J.Control of tip leakage in a high pressure turbine cascade using tip blowing[R].ASME Paper GT2016-56511,2016.
[21]	WANG Y,SONG Y,YU J,et al.Effect of cooling injection on the leakage flow of a turbine cascade with honeycomb tip[J].Applied Thermal Engineering,2018,133:690-703.
[22]	ZHOU Z,CHEN S,LI W,et al.Thermal performance of blade tip and casing coolant injection on a turbine blade with cavity and winglet-cavity tip[J].International Journal of Heat and Mass Transfer,2019,130:585-602.
[23]	GAO J,ZHENG Q,ZHANG Z,et al.Aero-thermal performance improvements of unshrouded turbines through management of tip leakage and injection flows[J].Energy,2014,69:648-660.
[24]	NIU M,ZANG S.Experimental and numerical investigations of tip injection on tip clearance flow in an axial turbine cascade[J].Experimental Thermal and Fluid Science,2011,35（6）:1214-1222.
[25]	ZHOU C,HODSON H.The tip leakage flow of an unshrouded high pressure turbine blade with tip cooling[J].Journal of Turbomachinery,2011,133（4）:041028.1-041028.12.
[26]	ZENG F,DU J,HUANG L,et al.An experimental method for squealer tip flow field considering relative casing motion[J].Chinese Journal of Aeronautics,2020,33（7）:1942-1952.
[27]	Erhard J.Design,construction and commissioning of a transonic test-turbine facility[D].Graz,Austria:Graz University of Technology,2000.
[28]	YOUNG J B,HORLOCK J H.Defining the efficiency of a cooled Turbine[J].Journal of Turbomachinery,2006,128（4）:658-667.
[29]	SCHLICHTING H,GERSTEN K.Boundary-layer theory[M].New York,USA:McGraw-Hill,1979.
[30]	BAKER S.Regions of recirculating flow associated with two-dimensional steps[D].Guildford,UK:University of Surrey,1977.
