基于Hankel阵的荧光油膜灰度与厚度预测模型改进

钱泓江; 董秀成; 张征宇

doi:10.13224/j.cnki.jasp.20210147

基于Hankel阵的荧光油膜灰度与厚度预测模型改进

doi: 10.13224/j.cnki.jasp.20210147

1.
西华大学电气与电子信息学院，成都 610039
2.
中国空气动力研究与发展中心高速空气动力研究所，四川绵阳 621000

基金项目: 国家自然科学基金（11872069）；教育部“春晖计划”科研项目（Z2017076）；四川省高校科研创新团队-机器视觉与智能控制资助项目（18TD0024）；四威高科-西华大学产学研联合实验室资助项目（2016-YF04-00044-JH）

详细信息

作者简介:
钱泓江（1997-），男，硕士生，主要从事机器视觉、空气动力学研究。

通讯作者:
董秀成（1963-），男，教授，硕士，主要从事机器视觉研究。E-mail：dxc136@163.com

中图分类号: V19
计量
- 文章访问数: 476
- HTML浏览量: 95
- PDF量: 175
- 被引次数: 0
出版历程
- 收稿日期: 2021-04-06
- 刊出日期: 2021-10-28

Improved prediction model of gray and thickness of fluorescent oil film based on Hankel matrix

1.
School of Electrical Engineering and Electronic Information，Xihua University，Chengdu 610039，China
2.
High Speed Aerodynamics Institute，China Aerodynamics Research and Development Center，Mianyang Sichuan 621000，China

摘要

摘要: 针对荧光油膜灰度与厚度关系数据采集方法较为繁琐、耗时耗力这一问题，研究了基于Hankel阵的系统辨识算法,并在此基础提出了Hankel阵误差修正模型和Hankel阵高阶迭代误差修正模型等两种改进方法，利用了极少数据量建立模型，实现了对其余未知荧光油膜厚度值的预测，且保持了较高的精度。试验结果表明：基于极少数据量建模以预测该数据量外的数据点这一特殊背景下，插值法的外插能力显得并不适用。而传统Hankel阵预测模型的预测精度为76.69%，Hankel阵误差修正模型和Hankel阵高阶迭代误差修正模型的预测精度分别为85.69%和89.25%，较之传统方法预测精度分别提高了9%和12.56%，为荧光油流技术领域针对荧光油膜灰度与厚度建模问题提供了一种可行技术路线，具有一定的实际工程应用意义。
- 荧光油膜 /
- 灰度 /
- 油膜厚度 /
- Hankel阵 /
- 预测模型
Abstract: In order to solve the problem of tedious and time-consuming data collection methods for the relationship between gray and thickness of fluorescent oil film，the system identification algorithm of Hankel matrix was studied，and two improved methods such as Hankel array error correction model and Hankel array high order iterative error correction model were proposed accordingly，which can achieve the prediction of the remaining unknown fluorescent oil film thickness values by using a very small amount of data to build the models.The prediction of the remaining unknown fluorescent oil film thickness values was achieved with high accuracy.The test results showed that the interpolation capability of the interpolation method seemed not applicable in the particular context of modelling a very small amount of data to predict data points outside that amount of data，while the prediction accuracy of the traditional Hankel array prediction model was 76.69%；the Hankel array error correction model and the Hankel array high order iterative error correction model had a prediction accuracy of 85.69% and 89.25%，respectively，9% and 12.56% higher than those of the traditional method.This has provided a feasible technical route for modelling the gray and thickness of fluorescent oil film in the field of fluorescent oil flow technology with certain practical engineering application significance.
- fluorescent oil film /
- gray /
- oil film thickness /
- Hankel matrix /
- prediction model

HTML

参考文献(29)

[1]	LIU T,SHEN L.Fluid flow and optical flow[J].Journal of Fluid Mechanics,2008,614:253-291.
[2]	雷鹏飞,周恩民,胡运华.连续式跨声速风洞与压缩机的气动性能匹配[J].航空动力学报,2021,36（2）:233-239.
[3]	LIU T,WOODIGA S，MONTEFORT J，et al.Global skin friction diagnostics in separated flows using luminescent oil[J].Journal of Flow Visualization and Image Processing,2009,16（1）:19-39.
[4]	朱自强,吴宗成,丁举春.层流流动控制技术及应用[J].航空学报,2011,32（5）:765-784.
[5]	周江宁,殷一民,郭秋亭,等.基于激光诱导荧光的高速飞行粒子低温段测温方法[J].航空动力学报,2019,34（12）:2642-2647.
[6]	LIU T，WOODIGA S，TIAN M.Skin friction topology in a region enclosed by penetrable boundary[J].Experiments in Fluids,2011,51（6）:1549-1562.
[7]	邢宇,罗东明,余雄庆.超临界层流翼型优化设计策略[J].北京航空航天大学学报,2017,43（8）:1616-1624.
[8]	刘志勇,李建强,高荣钊,等.应用OFI和Preston管测量亚跨声速摩擦应力[J].实验流体力学,2018,32（5）:76-81.
[9]	张华辉.低温漂混合集成砷化镓霍尔器件的研究与设计[D].太原：太原理工大学,2019.
[10]	王帅,何国强,秦飞,等.超声速内流道摩擦阻力分析及减阻技术研究[J].航空动力学报,2019,34（4）:908-919.
[11]	徐大川,龙彦志,李玉栋,等.基于激光多普勒原理的极低风速测量实验[J].航空动力学报,2020,35（6）:1228-1237.
[12]	TANNER L H.A skin friction meter,using the viscosity balance principle,suitable for use with flat or curved metal surfaces （based on thickness measurement）[J].Journal of Physics E:Scientific Instruments,1977,10（3）:278-284.
[13]	BROWN J L,NAUGHTON J W.The thin oil film equation[M].Washington DC:NASA AMES Research Center,1997.
[14]	LIU T,MONTEFORT J,WOODIGA S,et al.Global luminescent oil-film skin-friction meter[J].AIAA Journal,2008,46（2）:476-485.
[15]	李鹏,明晓.风力机叶片的全局表面摩擦力测量的荧光油膜法[J].南京航空航天大学学报,2011,43（5）:581-585.
[16]	李鹏.全局表面摩擦应力直接测量技术研究[D].南京：南京航空航天大学,2012.
[17]	黄湛,王宏伟,魏连风,等.基于荧光油膜的全局表面摩阻测量技术研究[J].空气动力学学报,2016,34（3）:373-378，403.
[18]	向珉江,高厚磊,安艳秋,等.一种提高数据同步精度的自适应插值算法[J].电力系统自动化,2012,36（8）:77-81.
[19]	MU B Q,CHEN H F.Hankel matcices for system identification[J].Journal of Mathematical Analysis and Applications,2014,409（1）:494-508.
[20]	李海涛,邵泽东.空间插值分析算法综述[J].计算机系统应用,2019,28（7）:1-8.
[21]	孙思梦.关于连分式插值方法的若干研究[D].安徽淮南：安徽理工大学,2020.
[22]	ALI S，WENG C，KONG J.Vector Hankel transform analysis of annular-ring microstrip antenna[J].IEEE Transactions on Antennas and Propagation,1982,30（4）:637-644.
[23]	CHEN G N,ZHAO B,ZHANG H P.The general rational interpolation problem in scalar case and its hankel vector[J].Linear Algebra and its Applications,1996,244（1）:165-201.
[24]	FORTAKI T，KHEDROUCHE D，BOUTTOUT F，et al.Vector Hankel transform analysis of a tunable circular microstrip patch[J].International Journal for Numerical Methods in Biomedical Engineering,2010,21（5）:219-231.
[25]	张波,李健君.基于Hankel矩阵与奇异值分解（SVD）的滤波方法以及在飞机颤振试验数据预处理中的应用[J].振动与冲击,2009,28（2）:162-166.
[26]	AHN H S，PARK S H，YE J C.Quantitative susceptibility map reconstruction using annihilating filter-based low-rank Hankel matrix approach[J].Magnetic Resonance in Medicine,2020,83（3）:858-871.
[27]	WANG C，ZHU Z，GU H.Low-rank seismic denoising with optimal rank selection for hankel matrices[J].Geophysical Prospecting,2020,68（3）:892-909.
[28]	LI T，CHEN J.The core invertibility of a companion matrix and a Hankel matrix[J].Linear and Multilinear Algebra,2020,68（3）:550-562.
[29]	LAL M，MITTRA R.A comparison of transfer function simplification methods[J].IEEE Transactions on Automatic Control,2003,19（5）:617-618.
