Experiment and simulation on aircraft thermal protection and utilization integrated system
-
摘要: 通过设计一种基于主动冷却的点阵桁架结构，在降低飞行器质量的同时，实现有效的热防护效果，并在该结构中加入半导体温差发电装置，将产生的气动热转化为电能，可用于飞行器小型用电设备供电。对该热防护与利用一体化系统进行了实验研究。在不同工况下，温差发电功率远大于主动冷却系统的泵功消耗，可实现主动冷却系统的自驱动。通过添加管内表面凸起和螺旋扭带扰流对翼前缘主动冷却点阵桁架结构热防护性能进行了优化研究。结果表明：管内凸起和扭带耦合时能明显改善系统的热防护性能，在流速为0.1 m/s情况下，以水为冷却工质时，外面板和内面板最高温度较光管情况下分别下降了14.4%、17.8%；以煤油为冷却工质时，两者分别下降了15.0%、34.5%。Abstract: When an aircraft flies at a high Mach number for a long time，the airflow in the boundary layer of the aircraft wall will generate aerodynamic heat because of strong friction，which can cause the temperature near the wall to rise or even exceed the temperature resistance limit of the material to the disadvantage of the aircraft.A lattice truss structure based on active cooling was designed to reduce the weight of the aircraft while achieving thermal protection effectively.At the same time，a semiconductor thermoelectric conversion device was added to the structure to convert the generated aerodynamic heat into electrical energy，which could be used to supply power for small electrical equipment of aircraft.The proposed integrated system of thermal protection and utilization was studied through experiment and the results showed that the power of thermoelectric conversion was much larger than the pump power consumption of the active cooling system，which can realize the self-driving of the active cooling system.Furthermore，the thermal protection performance of the actively cooled lattice truss structure was optimized by numerical simulation method，and the heat transfer effect was enhanced by adding the inner tube protrusions and the spiral twist.The results showed that the coupling of the inner tube protrusions and the twisted band can significantly improve the thermal protection performance of the system.At the flow velocity of 0.1 m/s，the maximum temperature of the outer and inner panels decreased by 14.4% and 17.8%，respectively，when water was used as working fluid，and 15.0% and 34.5%，respectively，when kerosene was used as working fluid.
-
Key words:
- aircraft /
- aerodynamic heat /
- active cooling /
- thermal protection /
- thermoelectric conversion
-
[1] 徐世南,吴催生.超声速导弹多功能结构设计[J].计算机仿真,2020,37（5）:45-48,54. [2] 唐青春.飞行器防热承载结构一体化设计与分析[D].哈尔滨:哈尔滨工业大学,2019. [3] 杨春晓.基于热能利用的高超声速飞行器热防护技术研究[D].长沙：国防科技大学,2017. [4] 范绪箕.高速飞行器热结构分析与应用[M].北京:国防工业出版社,2009. [5] 姜培学,张富珍,胥蕊娜,等.高超声速飞行器发动机热防护与发电一体化系统[J].航空动力学报,2021,36（1）:1-7. [6] BOUSLOG S,MOORE B,LAWSON I,et al.X-33 metallic TPS tests in NASA-LARC high temperature tunnel[R].Reno,NV,US:the 37th Aerospace Sciences Meeting and Exhibit,1999. [7] LEONARD C,AMUNDSEN R,BRUCE W.Hyper-X hot structures design and comparison with flight data[R].Capua,Italy:AIAA/CIRA 13th International Space Planes and Hypersonics Systems and Technologies Conference,2005. [8] 马玉娥.可重复使用运载器热防护系统热/力耦合数值计算研究[D].西安：西北工业大学,2006. [9] 王晓君.轻质点阵主动换热壁板热力耦合分析[D].哈尔滨：哈尔滨工业大学,2014. [10] BAPANAPALLI S.Design of an integral thermal protection system for future space vehicles[M].Gainesville,Florida，US:University of Florida，2007. [11] DARYABEIGI K S S,KNUTSON J.Characterization of structurally integrated TPS for hypersonic vehicles[R].Hampton,Virginia,USA:NASA Langley Research Center Fundamental Aeronautics Annual Meeting,2008. [12] RAKOW J F,WAAS A M.Response of actively cooled metal foam sandwich panels exposed to thermal loading[J].AIAA Journal,2007,45（2）:329-336. [13] WILLIAMS A,UNDERWOOD L,BUSCH G,et al.Biologically-inspired multifunctional composite panel with integrated thermal control[R].Orlando,Florida，US:the 51st AIAA/ASME/ASCE/AHS/ASC Structures,Structural Dynamics,and Materials Conference,2010. [14] CHEN L,MEI D,WANG Y,et al.Ni barrier in Bi2Te3-based thermoelectric modules for reduced contact resistance and enhanced power generation properties[J].Journal of Alloys and Compounds,2019,796:314-320. [15] JIANG C,FAN X A,FENG B,et al.Thermal stability of p-type polycrystalline Bi2Te3-based bulks for the application on thermoelectric power generation[J].Journal of Alloys and Compounds,2017,692:885-891. [16] 周晨,王志瑾,支骄杨.主动冷却皱褶芯材夹层板的热力分析[J].固体火箭技术,2014,37（4）:545-550. [17] 吉庭武.先进飞行器半主动/主动冷却结构热力分析与优化设计[D].西安：西北工业大学,2016. [18] 孙健.高超声速飞行器前缘疏导式热防护结构的工作机理研究[D].长沙：国防科学技术大学,2013. [19] 侯宜朋,侯赤,万小朋,等.对流式主动冷却结构影响参数分析[J].固体火箭技术,2016,39（1）:90-94. -
