Tooth surface design and undercutting research of offset orthogonal arc tooth face gear
-
摘要: 为拓宽面齿轮的应用空间，结合面齿轮与弧线齿的特点，提出了偏置正交弧线齿面齿轮。根据坐标变换规律及啮合原理推导了全齿面的方程，并在Matlab软件中建立了全齿面模型。结合齿面模型及根切原理,利用Matlab软件编程计算了齿面根切的位置。借助CATIA软件二次开发进行仿真切齿试验，验证了计算的正确性。探究了各参数对最小内半径的影响，结果表明：坐标系距离与最小内半径呈负相关，刀具圆弧半径、偏置距离及模数都与最小内半径呈正相关，其中模数对根切位置影响最大。最后计算了顶尖位置，通过最大外半径与最小内半径之差确定了面齿轮的最大齿宽。Abstract: For the purpose of expanding the application range of face gear，a new design of offset orthogonal arc tooth face gear was proposed by combining the characteristics of both face gear and arc tooth.The equations of full tooth surfaces were derived，and the visualization of tooth surfaces was realized in Matlab.Based on the mathematical model and the undercutting theory，the undercutting location of the gear was calculated.Result was confirmed by the simulation experiment using CATIA secondary development.Several factors influencing with the minimum inner radius were studied.The research showed that：while the positional parameter had a small negative influence on the minimum inner radius，the radius of the gear cutter and the offset distance both had positive influence on it.When the module of gear increased，the inner radius increased greatly.In the end，the location of the tooth tipping point was confirmed and the tooth width of face gear was calculated.
-
[1] LITVIN F L,FUENTE S A.Gear geometryand applied theory[M].New York:Cambridge University Press,2004:142-167. [2] LITVIN F L,LIAN Q,KAPELEVICH A L.A symmetric modified gear drives:reduction of noise,localization of contact,simulation of meshing and stress analysis[J].Computer Methods in Applied Mechanics and Engineering,2000,188（1）:363-390． [3] 李政民卿,朱如鹏.正交面齿轮齿廓的几何设计和根切研究[J].华南理工大学学报（自然科学版）,2008，36（2）:78-82. [4] 朱如鹏,高德平.在面齿轮设计中避免根切和齿顶变尖的设计方法的研究[J].中国机械工程,1999,10（11）:1274-1276. [5] 朱如鹏,潘升材,高德平.正交面齿轮传动中齿宽设计的研究[J].机械科学与技术,1999,18（4）:3-5. [6] 魏冰阳,杨建军,聂少武.差曲面拓扑的齿轮啮合刚度计算与承载接触分析[J].航空动力学报,2019,34（12）:2745-2752. [7] 王峰,张健,徐兴.融合齿背接触机理的圆柱斜齿轮振动特性分析与双面修形优化研究[J].振动与冲击,2018,37（24）:53-60. [8] 方宗德.斜齿轮齿面柔度矩阵与修形的有限元计算[J].航空动力学报,1994,9（3）:242-244. [9] 彭先龙,李爱民,郭卫.人字齿面齿轮传动及其几何啮合特性[J].机械科学与技术,2017,36（7）:1131-1135. [10] 蔡香伟,方宗德,苏进展.弧线齿面齿轮的几何设计和数控加工[J].机械科学与技术,2012,31（11）:1781-1785. [11] 付学中,方宗德,李建华,等.偏置面齿轮的碟形砂轮磨齿及啮合性能[J].华南理工大学学报（自然科学版）,2016,44（7）:77-82. [12] 徐伟俊,彭学玉,李清.偏置面齿轮齿面方程和仿真[J].机械设计与制造,2013（4）:94-97. [13] 李大庆,邓效忠,魏冰阳.偏置斜齿面齿轮几何设计及齿宽特性分析[J].机械设计,2011,28（9）:59-62. [14] 宋爱平,易红,汤文成.渐开线弧齿圆柱齿轮及其啮合特性[J].中国机械工程,2006,17（18）:1888-1892. [15] 赵磊,明兴祖,王伟.基于MATLAB的正交面齿轮设计及可视化分析[J].湖南工业大学学报,2014,28（5）:38-42. [16] 盛伟,王利霞,冯占荣,等.弧线齿面齿轮齿面几何设计及径向齿宽特性[J].航空动力学报,2019,34（4）:796-803. [17] 苏进展,张昆仑,方宗德.新型斜线齿面齿轮齿宽的几何设计[J].中南大学学报（自然科学版）,2017,48（9）:2363-2369. [18] 崔艳梅,方宗德,王丽萍.弧线齿面齿轮的根切与变尖研究[J].机械强度,2014,36（4）:572-577. -
