多级轴流压气机出口级转子扩张通道优化设计

金芸; 耿少娟; 王文涛; 张小玉; 张宏武

doi:10.13224/j.cnki.jasp.20210175

多级轴流压气机出口级转子扩张通道优化设计

doi: 10.13224/j.cnki.jasp.20210175

金芸^1,2,3,4,
耿少娟^1,2,3,4, ,,
王文涛^1,2,3,
张小玉^1,2,3,
张宏武^1,2,3,4

1.
中国科学院工程热物理研究所先进燃气轮机实验室，北京 100190
2.
中国科学院轻型动力创新研究院，北京 100190
3.
中国科学院先进能源动力重点实验室，北京 100190
4.
中国科学院大学工程科学学院，北京 100049

基金项目: 国家科技重大专项（2017-Ⅱ-0006-0020）

详细信息

作者简介:
金芸（1997-），女，博士生，主要从事叶轮机械气动热力学研究。

通讯作者:
耿少娟（1980-），女，副研究员，博士，主要从事叶轮机械气动热力学研究。E-mail：gengsj@iet.cn

中图分类号: V231.1
计量
- 文章访问数: 98
- HTML浏览量: 6
- PDF量: 112
- 被引次数: 0
出版历程
- 收稿日期: 2021-04-15
- 刊出日期: 2022-04-28

Design optimization of exit stage rotor with diffuser passage in multi-stage axial compressor

JIN Yun^1,2,3,4,
GENG Shaojuan^{1,2,3,4
, ,},
WANG Wentao^1,2,3,
ZHANG Xiaoyu^1,2,3,
ZHANG Hongwu^1,2,3,4

1.
Advanced Gas Turbine Laboratory，Institute of Engineering Thermophysics，Chinese Academy of Sciences，Beijing 100190，China
2.
Innovation Academy for Light-duty Gas Turbine，Chinese Academy of Sciences，Beijing 100190，China
3.
Key Laboratory of Advanced Energy and Power，Chinese Academy of Sciences，Beijing 100190，China
4.
School of Engineering Science，University of Chinese Academy of Sciences，Beijing 100049，China

摘要

摘要: 为提高多级轴流压气机后面级气动性能，针对某多级轴流压气机出口级转子搭建了基于遗传算法和神经网络代理模型的扩张通道压气机优化设计平台，并对其进行扩张通道优化设计研究。根据优化得到的数据库分析了各设计参数对效率和裕度的影响规律。在优化所得解集中选择了两个扩张通道设计方案，探究了其对效率和裕度的影响规律和机制。结果表明：扩张通道设计可使出口级转子在设计流量点的负荷提高12.1%、效率提高1.28%，同时获得12.50%的裕度改善量。基于当地熵产率损失模型可得，扩张通道转子相较于原型转子，其上下端壁损失增加，叶型损失减小。扩张通道转子近失速点堵塞系数变小是其裕度提升的主要原因。
- 出口级 /
- 扩张通道 /
- 神经网络代理模型 /
- 当地熵产率 /
- 堵塞
Abstract: In order to improve the aerodynamic performance of the rear stages of multi-stage axial compressor，an in-house optimization design platform for diffuser passage compressors based on genetic algorithm and neural network surrogate model was built and applied into the optimization design of an exit rotor with diffuser passage.Impacts of the design parameters on efficiency and stability improvement were analyzed based on optimization database.Two optimized diffuser passage designs were selected from the optimization solution set and their influencing rules and mechanisms on efficiency and stability were further studied.Results showed that application of diffuser passage design can improve the load coefficient by 12.1% and efficiency by 1.28% at design mass flow rate，the improvement of stall margin by 12.50% can also be obtained.According to the local entropy generation rate model，the loss of the upper and lower endwalls of the diffuser passage rotor was increased compared with the origin rotor，whereas the loss of profile was reduced. The main reason for stall margin increase of the diffuser passage rotor was the decrease of blockage coefficient near the stall point.
- exit stage /
- diffuser passage /
- neural network surrogate model /
- entropy generation rate /
- blockage

HTML

参考文献(23)

[1]	WISLER D C.E Advanced compressor and fan systems[M].New York,USA:GE （General Electric） Aircraft Engine Business Group,1985.
[2]	BAGHDADI S,Modeling tip clearance effects in multistage axial compressors[J].Journal of Turbomachinery,1996,118（4）:613-843.
[3]	WISLER D C.Core compressor exit stage study：VolumeⅠ data and performance report for the best configuration[R].NASA CR-165357,R81AEG314,1981.
[4]	WISLER D C.Core compressor exit stage study:Volume Ⅵ final report[R].NASA CR-16555,R81AEG288,1981.
[5]	桂幸民.航空压气机气动热力学理论与应用[M].上海:上海交通大学出版社,2014.
[6]	FUNATOGAWA O.Research and technology development in Japanese environmentally compatible engine for small aircraft project[R].Munich,Germany:the 17th International Society for Air Breathing Engines Conference,2005.
[7]	阳诚武.高负荷轴流压气机叶顶端区流动及调控方法研究[D].北京:中国科学院,2015.
[8]	KATO D,GOTO S,MUROOKA T,et al.Development of diffuser passage compressor for improved performance robustness against tip clearance flows[R].Tokyo,Japan:the 9th International Gas Turbine Congress,2007.
[9]	KATO D,PALLOT G,SATO D,et al.Development of a highly loaded axial flow compressor for small core size aircraft engines[R].Osaka,Japan:the 10th International Gas Turbine Congress,2011.
[10]	YANG Chengwu,HAN Ge,ZHAO Shengfeng,et al.Design and test of a novel highly-loaded compressor[R].ASME Paper GT2019-91181,2019.
[11]	赵清伟,潘若痴.一种高负荷叶型优化设计方法[J].航空动力学报,2016,31（12）:3017-3025.
[12]	罗明,左志涛,李弘扬,等.基于BP人工神经网络的离心压气机叶轮多目标优化设计方法[J].航空动力学报,2016,31（10）:2424-2431.
[13]	周创鑫,成金鑫,黄松,等.基于贝塞尔曲面参数化方法的1.5级高负荷轴流压气机气动优化[J].航空动力学报,2021,36（4）:673-686.
[14]	DENTON J D.Loss mechanisms in turbomachines[J].Journal of Turbomachinery,1993,115（4）:621-656.
[15]	KOCH C C,SMITH L H.Loss sources and magnitudes in axial-flow compressors[J].Journal of Engineering for Power,1976,98（3）:411-424.
[16]	KOCK F,HERWIG H.Local entropy production in turbulent shear flows:a high-Reynolds number model with wall functions[J].International Journal of Heat and Mass Transfer,2004,47（10/11）:2205-2215.
[17]	KOCK F,HERWIG H.Entropy production calculation for turbulent shear flows and their implementation in CFD codes[J].International Journal of Heat and Mass Transfer,2005,26（4）:672-680.
[18]	李志远.RANS-LES混合方法轴流压气机数值模拟及熵产损失模型构建[D].北京:中国科学院,2017.
[19]	LI Zhiyuan,DU Juan,JEMCOY A,et al.A study of loss mechanism in a linear compressor cascade at the corner stall condition[R].ASME Paper GT2017-65192,2017.
[20]	MOORE J,MOORE J G.Entropy generation rates from viscous flow calculation:Part 1 a turbulent boundary layer[R].ASME Paper 1983-GT-70,1983.
[21]	张千丰.高负荷斜流压气机叶顶间隙流动与轴向缝处理机匣的非定常作用机理研究[D].北京:中国科学院,2020.
[22]	KHALID S A,KHALSA A S,WAITZ I A,et al.Endwall blockage in axial compressors[J].Journal of Turbomachinery,1999,121（3）:499-509.
[23]	SUDER K L.Blockage development in a transonic axial compressor rotor[J].Journal of Turbomachinery,1998,120（3）:465-476.
