基于GWO-TVF-EMD方法的行星齿轮箱齿面剥落故障诊断

曹蔚; 苟臻元; 韩昭; 郭雅泓; 杨壮壮; 王栋; 瞿金秀

doi:10.13224/j.cnki.jasp.20210226

基于GWO-TVF-EMD方法的行星齿轮箱齿面剥落故障诊断

doi: 10.13224/j.cnki.jasp.20210226

1.
西安工业大学机电工程学院，西安 710021
2.
陕西水利电力勘测设计研究院水电工程分院，西安 710001

基金项目: 国家自然科学基金（52175113，51505360，51905406）；陕西省国际科技合作计划项目（2020KW-014）；陕西省教育厅重点实验室项目（18JS044）

详细信息

作者简介:
曹蔚（1977-），女，副教授、硕士生导师，博士，主要研究方向为机械振动与故障诊断、精密机械设计技术与产品开发、摩擦学系统工程等。

通讯作者:
韩昭（1996-），男，硕士生，主要研究方向为机械振动与故障诊断、动力学建模等。E-mail： hanzhao1996@163.com

中图分类号: V263.6;TH132.46
计量
- 文章访问数: 99
- HTML浏览量: 1
- PDF量: 90
- 被引次数: 0
出版历程
- 收稿日期: 2021-05-10
- 刊出日期: 2021-11-28

Fault diagnosis of tooth surface spalling of planetary gearbox based on GWO-TVF-EMD method

1.
School of Mechatronic Engineering，Xi'an Technological University，Xi'an 710021，China
2.
Hydroelectric Engineering Branch，Shaanxi Province Institute of Water Resources and Electric Power Investigation and Design，Xi'an 710001，China

摘要

摘要: 针对时变滤波经验模态分解（TVF-EMD）方法的不足之处，将样本熵作为适应度函数，采用灰狼优化（GWO）算法对带宽阈值和B样条阶数核心参数进行寻优，得到最优组合解，对不同的故障冲击试验振动信号进行分解。对本征模态函数（IMF）分量选取过程进行优化，采用多个加权指标对所有IMF分量进行计算，最终选取最优IMF分量，再通过包络谱分析提取出行星轮齿面剥落故障特征。在行星齿轮箱故障试验中，利用方均根法对剥落故障进行初步识别，根据GWO-TVF-EMD法分解得到各剥落故障信号最优IMF分量，使用包络谱分析明显判断出行星齿轮的故障频率。该方法能够提取3种不同程度齿面剥落故障的细节特征，理论值与实际值的相对误差为1.68%。
- 行星齿轮箱 /
- 剥落 /
- 灰狼优化算法 /
- 时变滤波经验模态分解 /
- 特征提取
Abstract: In order to overcome the shortcomings of the time varying filter for empirical mode decomposition （TVF-EMD） method，the sample entropy was used as the fitness function.The gray wolf optimization （GWO） algorithm was used to optimize the bandwidth threshold and B-spline order core parameters，and the optimal combination solution was obtained to decompose the vibration signals of different fault impact tests.The selection process of intrinsic mode function （IMF） components was optimized，and multiple weighted indexes were used to calculate all the IMF components，and finally the optimal IMF component was selected.Then，the spalling fault features of planetary gear were extracted by envelope spectrum analysis.In the planetary gear box fault test，the root mean square method was used to identify the spalling fault initially，and the optimal IMF component of each spalling fault signal was obtained by GWO-TVF-EMD，and the envelope spectrum analysis was used to judge the fault frequency of the planetary gear clearly.The method can extract the detailed features of three different degrees of tooth surface spalling faults，and the relative error between the theoretical value and the actual value was 1.68%.
- planetary gearbox /
- spalling /
- grey wolf optimizer /
- time varying filter for empirical mode decomposition /
- feature extraction

HTML

参考文献(23)

[1]	LIANG Xihui,ZUO Mingjian,FENG Zhipeng.Dynamic modeling of gearbox faults:a review[J].Mechanical Systems and Signal Processing,2018,98（1）:852-876.
[2]	刘波,安宗文.考虑零件寿命相关的风电齿轮箱可靠性分析[J].机械工程学报,2015,51（10）:164-171.
[3]	CAO Wei,ZHANG Han,WANG Ning,et,al.The gearbox wears state monitoring and evaluation based on on-line wear debris features[J].Wear,2019,426/427:1719-1728.
[4]	陈果,杨默晗,于平超.基于深度学习的航空发动机不平衡故障部位识别[J].航空动力学报,2020,35（12）:2602 -2615.
[5]	CAO Wei,GOU Zhenyuan,WANG Dong,et al.Application of haar wavelet de-noising with cross correlation and neighboring coefficients to the bearing faults prognosis[J].International Journal of Comadem,2020,23（4）:15-22.
[6]	陈雪骑,马艳红,王永锋,等.复杂激励下涡轴发动机中央从动锥齿轮故障机理[J].航空动力学报,2020,35（6）:1222-1227.
[7]	HUANG N E,SHEN Z,LONG S R,et al.The empirical mode decomposition and the Hilbert spectrum for nonlinear and non-stationary time series analysis[J].Proceedings of the Royal Society:A Mathematical,Physical and Engineering Sciences,1998,454（1971）:903-995.
[8]	WU Zhaohua,HUANG N E.Ensemble empirical mode decomposition: a noise-assisted data analysis method[J].Advances in Adaptive Data Analysis,2009,1（1）:1-41.
[9]	LI Heng,LI Zhi,MO Wei.A time varying filter approach for empirical mode decomposition[J].Signal Processing,2017,138:146-158.
[10]	ZHANG Xin,LIU Zhiwen,MIAO Qiang,et al.An optimized time varying filtering based empirical mode decomposition method with grey wolf optimizer for machinery fault diagnosis[J].Journal of Sound and Vibration,2018,418:55-78.
[11]	唐贵基,周翀,庞彬,等.基于参数优化时变滤波经验模态分解的转子故障诊断[J].振动与冲击,2019,38（10）:162-168.
[12]	林近山,窦春红,寇兴磊.基于时变滤波经验模式分解的齿轮箱故障诊断[J].机械传动,2018,42（1）:98-101.
[13]	RICHMAN J S,MOORMAN J R.Physiological time-series analysis using approximate entropy and sample entropy[J].American Journal of Physiology:Heart and Circulatory Physiology,2000,278（6）:2039-2049.
[14]	张学清,梁军,张熙,等.基于样本熵和极端学习机的超短期风电功率组合预测模型[J].中国电机工程学报,2013,33（25）:33-40.
[15]	MIRJALILI S,MIRJALILI S M,LEWIS A.grey wolf optimizer[J].Advances in Engineering Software,2014,69（3）:46-61.
[16]	杨超,赵荣珍,孙泽金.基于SVD-MEEMD与Teager能量谱的滚动轴承微弱故障特征提取[J].噪声与振动控制,2020,40（4）:92-97.
[17]	杜冬梅,张昭,李红,等.基于LMD和增强包络谱的滚动轴承故障分析[J].振动、测试与诊断,2017,37（1）:92-96.
[18]	屈梁生.机械故障诊断学[M].西安：西安交通大学出版社,1986.
[19]	华哲.风电机组不对中故障预测技术的研究[D].北京：北京交通大学,2020.
[20]	姜丰,朱家玲,胡开永,等.Pearson相关系数评价ORC系统蒸发器特性的应用研究[J].太阳能学报,2019,40（10）:2732-2738.
[21]	王况,王科盛,左明健.一种基于行星齿轮箱复合运动的故障诊断指标[J].振动与冲击,2016,35（23）:216-221.
[22]	张龙，吴荣真.滚动轴承性能退化评估的自适应频带熵能比指标[J].振动与冲击，2021,40（2）:63-71,100.
[23]	WEN Weigang,GAO R X,CHENG Weidong,et al.Planetary gearbox fault diagnosis using envelope manifold demodulation[J].Shock and Vibration,2016,7（2）:1-13
