基于晶体塑性的涡轮盘短裂纹扩展模拟方法

张凭; 陆山; 景鑫; 杨茂; 罗忠兵; 周荣欣

doi:10.13224/j.cnki.jasp.20210230

基于晶体塑性的涡轮盘短裂纹扩展模拟方法

doi: 10.13224/j.cnki.jasp.20210230

张凭^1,,
陆山^1, ,,
景鑫¹,
杨茂¹,
罗忠兵²,
周荣欣³

1.
西北工业大学动力与能源学院，西安 710172
2.
大连理工大学无损检测研究所，辽宁大连 116024
3.
合肥工业大学土木与水利工程学院，合肥 230009

基金项目: 国家留学基金委（201806290092）

详细信息

作者简介:
张凭（1993-），男，博士，主要从事镍基高温合金裂纹模拟及晶体塑性理论研究。E-mail：pzhang@mail.nwpu.edu.cn

通讯作者:
陆山（1955-），男，教授、博士生导师，博士，主要从事航空发动机结构强度、振动及可靠性研究。E-mail：shanlu@nwpu.edu.cn

中图分类号: V232.3
计量
- 文章访问数: 594
- HTML浏览量: 139
- PDF量: 183
- 被引次数: 0
出版历程
- 收稿日期: 2021-05-11
- 刊出日期: 2022-04-28

Simulation method of short crack propagation in turbine disks based on crystal plasticity

1.
School of Power and Energy， Northwestern Polytechnical University，Xi'an 710072，China
2.
Nondestructive Testing and Evaluation Laboratory， Dalian University of Technology，Dalian Liaoning 116024，China
3.
College of Civil Engineering， Hefei University of Technology，Hefei 230009，China

摘要

摘要: 针对低周疲劳载荷下发动机涡轮盘早期短裂纹扩展行为，提出适用于工程结构的耦合晶体塑性（CP）理论和扩展有限元方法（XFEM）的多晶短裂纹模拟方法。该方法采用晶体内总累积分解切应变作为裂纹扩展判据并使裂纹沿最活跃滑移系对应的滑移平面传播。框架采用子模型技术/分区域网格细化以及宏-介观本构结合的方法解决真实工程结构和微观模型尺度不匹配的问题，在可接受的计算代价下预测了涡轮盘危险截面处的短裂纹扩展路径及速率。结果表明该结构内早期裂纹生长路径及速率受到晶体取向的影响而出现较大分散性，同时验证了基于CP-XFEM的框架在预测工程结构短裂纹扩展寿命及分散性上的可行性。
- 涡轮盘 /
- 高温镍基合金 /
- 短裂纹 /
- 数值模拟 /
- 晶体塑性（CP） /
- 扩展有限元法（XFEM）
Abstract: In view of the early-stage short crack propagation behaviour in turbine disks under low-cycle fatigue，a method coupling crystal plasticity （CP） theory and extended finite element method （XFEM） was proposed to simulate short cracks in engineering structures.The method used the total cumulative shear strain in crystals as the criterion of crack propagation and made the crack propagate along the slip plane with the most active slip system.By using sub-model technology/regional refinement of grids and a combination of macro-micro constitutive models，the framework overcame the scale mismatch between the real engineering structure and the micro model，and then predicted the short crack propagation path and rate in the dangerous section of a technique turbine disk at an acceptable calculation cost.The results showed that the short crack propagation path and rate in structures was highly affected by crystal orientations，resulting in a large dispersion of fatigue life.At the same time，it verified the feasibility of the CP-XFEM-based framework in predicting the short crack propagation life of engineering structures.
- turbine disk /
- nickel-based superalloy /
- short crack /
- numerical simulation /
- crystal plasticity （CP） /
- extended finite element method （XFEM）

HTML

参考文献(23)

[1]	CONNOLLEY T,REED P A S,STARINK M J.Short crack initiation and growth at 600 ℃ in notched specimens of Inconel718[J].Materials Science and Engineering A,2003 340（1/2）:139-154.
[2]	TOH S F,RAINFORTH W M.Fatigue of a nickel base superalloy with bimodal grain size[J].Metal Science Journal,2016,12（12）:1007-1014.
[3]	MA X,SHI H J.In situ SEM studies of the low cycle fatigue behavior of DZ4 superalloy at elevated temperature:effect of partial recrystallization[J].International Journal of Fatigue,2014,61（2）:255-263.
[4]	朱磊,吴志荣,胡绪腾,等.镍基合金GH4169疲劳小裂纹的扩展行为[J].航空动力学报,2017,32（8）:1984-1991.
[5]	张丽,黄新跃,吴学仁,等.镍基高温合金GH4169小裂纹早期扩展的原位疲劳试验[J].航空动力学报,2014,29（4）:901-906.
[6]	MO?S N,DOLBOW J,BELYTSCHKO T.A finite element method for crack growth without remeshing[J].International Journal for Numerical Methods in Engineering,1999,46:131-150.
[7]	RANNOU J,LIMODIN N,RéTHORé J,et al.Three dimensional experimental and numerical multiscale analysis of a fatigue crack[J].Computer Methods in Applied Mechanics and Engineering,2010,199:1307-1325.
[8]	CUADRA J,BAXEVANAKIS K P,LOGHIN A,et al.Validation of a cyclic plasticity computational method using fatigue full‐field deformation measurements[J].Fatigue and Fracture of Engineering Materials and Structures,2016,39（6）:722-736.
[9]	FARUKH F，ZHAO L G，JIANG R，et al.Realistic microstructure-based modelling of cyclic deformation and crack growth using crystal plasticity[J].Computational Materials Science，2016，111:395-405.
[10]	ZHANG P，ZHANG L，BAXEVANAKIS K P,et al.Modelling short crack propagation in a single crystal nickel-based superalloy using crystal plasticity and XFEM[J].International Journal of Fatigue,2020,136:105594.1-105594.11.
[11]	ZHANG P,BAXEVANAKIS K P,ZHAO L G.An investigation of short crack propagation in a single crystal Ni-based superalloy using crystal plasticity and the extended finite element method[J].Procedia Structural Integrity,2020,28:1176-1183.
[12]	WILSON D,DUNNE F P E.A mechanistic modelling methodology for microstructure-sensitive fatigue crack growth[J].Journal of the Mechanics and Physics of Solids,2019,124:827-848.
[13]	WILSON D,WAN W,DUNNE F P E.Microstructurally-sensitive fatigue crack growth in HCP BCC and FCC polycrystals[J].Journal of the Mechanics and Physics of Solidsm,2019,126:204-225.
[14]	LIU X T,LU Shan.A micro-crack initiation life simulation method by improving the Tanaka-Mura's model of slip behavior[J].International Journal of Fatigue,2021,145:106108.1-106108.11.
[15]	牟园伟,陆山.基于宏—介观模型的疲劳裂纹萌生数值模拟[J].机械强度,2012,34（3）:379-383.
[16]	牟园伟,陆山.基于材料微观特性的涡轮盘疲劳裂纹萌生寿命数值仿真[J].航空学报,2013,34（2）:282-290.
[17]	ASARO R J,RICE J R.Strain localization in ductile single crystals[J].Journal of the Mechanics and Physics of Solids,1977,25（5）:309-338.
[18]	PEIRCE D,ASARO R J,NEEDLEMAN A.An analysis of nonuniform and localized deformation in ductile single crystals[J].Acta Metallurgica,1982,30（6）:1087-1119.
[19]	冯引利,吴长波,郜伟强,等.FGH96涡轮盘低循环疲劳寿命分析技术与试验[J].航空动力学报,2012,27（3）:628-634.
[20]	LIN B,ZHAO L G,TONG J.A crystal plasticity study of cyclic constitutive behaviour crack-tip deformation and crack-growth path for a polycrystalline nickel-based superalloy[J].Engineering Fracture Mechanics,2011,78（10）:2174-2192.
[21]	北京航空材料研究院.金属材料疲劳裂纹扩展速率试验方法:
[22]	GB/T 6398-2000[S].北京:中国标准出版社，2000:450-455.
[23]	[22] 刘文珽,郑旻仲,费斌军,等.概率断裂力学与概率损伤容限/耐久性[M].北京：北京航空航天大学出版社,1999.
