喷口速度扰动下液体射流的频率响应

周程林; 邹建锋; 张阳; 叶麟

doi:10.13224/j.cnki.jasp.20210234

喷口速度扰动下液体射流的频率响应

doi: 10.13224/j.cnki.jasp.20210234

周程林¹,
邹建锋^1, ,,
张阳¹,
叶麟²

1.
浙江大学航空航天学院，杭州 310027
2.
正泰集团股份有限公司数字化技术研究院数字化解决方案部，杭州 310052

基金项目: 国家自然科学基金（11372276，11432013，11272285）

详细信息

作者简介:
周程林（1996-），男，博士生，主要从事液体燃料射流数值模拟研究。

通讯作者:
邹建锋（1977-），男，副教授、博士生导师，博士，主要从事先湍流燃烧数值模拟技术开发及燃料雾化机理研究。E-mail：zoujianfeng@zju.edu.cn

中图分类号: V231.2
计量
- 文章访问数: 72
- HTML浏览量: 7
- PDF量: 78
- 被引次数: 0
出版历程
- 收稿日期: 2021-05-12
- 刊出日期: 2022-04-28

Frequency response of liquid jet under nozzle velocity disturbance

1.
School of Aeronautics and Astronautics，Zhejiang University，Hangzhou 310027，China
2.
Digital Technology Research Institute， CHINT Group Corporation，Hangzhou 310052，China

摘要

摘要: 基于界面捕捉VOF（volume of fluid）方法和网格自适应技术，对圆射流初始破碎过程进行了直接数值模拟，揭示了不同扰动频率对圆射流表面形态和液丝、液滴结构的响应特性。研究结果表明：Rayleigh线性化色散理论可以很好地对当前射流表面波的失稳过程进行解释。当喷口扰动频率（66.6 kHz）小于理论临界值95.5 kHz时，射流会随着时空演化逐渐失稳，而当大于临界值时，表面波振幅会逐渐减弱并逐渐变成光滑状态。表面波不稳定状态下脱落液滴会撞击波节结构，在其表面留在冲击凹痕；随着波节振幅不断增大，液膜发生穿孔式破裂，进而形成大量脱落的液丝和液滴结构。适当频率的扰动可以减少射流头部的速度波动，从而减缓射流的雾化进程；射流表面波的破碎和液核头部的破碎过程共同决定了喷雾场SMD（Sauter mean diameter）的大小，且两者存在相互耦合。
- 频率响应特性 /
- 圆射流 /
- 速度扰动 /
- VOF方法 /
- 表面形态 /
- 液丝 /
- 液滴
Abstract: Based on the VOF （volume of fluid） interface capture method and the dynamic adaptive grid technique，a direct numerical simulation of the breakup process of a circular jet was carried out.The surface morphology of the circular jet and the response characteristics of liquid ligaments and droplets under different disturbance frequencies were revealed.The results showed that Rayleigh linearized dispersion theory can well explain the instability process of jet surface wave.When the nozzle disturbance frequency （66.6 kHz） was less than the theoretical critical value of 95.5 kHz，the jet gradually lost stability with the evolution of time and space.When it was greater than the critical value，the amplitude of surface wave gradually weakened and the liquid core became smooth.When the surface wave was unstable，the falling droplets impacted the nodal structure and impact dents left on its surface；with the increase of nodal amplitude，the liquid film broke through，and then a large number of detached liquid ligaments and droplets were formed.Appropriate frequency disturbance can reduce the velocity fluctuation of the jet head and slow down the atomization process of the jet.The breakup of the jet surface wave and the breakup process of the liquid core head determined the size of the SMD （Sauter mean diameter） of spray field，and there existed mutual coupling between them.
- frequency response characteristics /
- circular jet /
- velocity disturbance /
- VOF method /
- surface morphology /
- liquid ligament /
- droplet

HTML

参考文献(20)

[1]	SHINJO J,UMEMURA A.Detailed simulation of primary atomization mechanisms in diesel jet sprays （isolated identification of liquid jet tip effects）[J].Proceedings of the Combustion Institute,2011,33（2）:2089-2097.
[2]	LIN S E,RUSCHAK K R.Breakup of liquid sheets and jets[M].New York:Cambridge University Press,2003.
[3]	王振国.液体火箭发动机燃烧过程建模与数值仿真[M].北京：国防工业出版社,2012.
[4]	曹建明.液体喷雾学[M].北京：北京大学出版社,2013.
[5]	RAYLEIGH L.On the instability of jets[J].Proceedings of the London Mathematical Society，1878,1（1）:4-13.
[6]	WEBER C.Zum zerfall eines flüssigkeitsstrahles[J].Journal of Applied Mathematics and Mechanics,1931,11（2）:136-154.（in German）
[7]	REITZ R D,BRACCO F V.Mechanism of atomization of a liquid jet[J].The Physics of Fluids,1982,25（10）:1730-1742.
[8]	LEIB S J,GOLDSTEIN M E.Convective and absolute instability of a viscous liquid jet[J].The Physics of Fluids,1986,29（4）:952-954.
[9]	LIN S P,KANG D J.Atomization of a liquid jet[J].The Physics of Fluids,1987,30（7）:2000-2006.
[10]	LI X,CHEN T.Liquid jet atomization in a compressible gas streams[J].Journal of Propulsion and Power,1999,15（3）:369-376.
[11]	CHAVES H,OBERMEIER F,SEIDEL T.Fundamental investigation of the disintegration of a sinusoidally forced liquid jet[C]∥Eighth International Conference on Liquid Atomization and Spray Systems.Pasadena,US:ICLASS,2000:1018-1025.
[12]	李珍妮.纵向扰动控制下液体射流破碎机理的研究[D].天津：天津大学,2015.
[13]	SRINIVASAN V,SALAZAR A J,SAITO K.Modeling the disintegration of modulated liquid jets using volume-of-fluid （VOF） methodology[J].Applied Mathematical Modelling,2011,35（8）:3710-3730.
[14]	YANG X,TURAN A.Simulation of liquid jet atomization coupled with forced perturbation[J].Physics of Fluids,2017,29（2）:022103.1-022103.12.
[15]	刘涛，任文文，赵家权.纵向受迫扰动下直喷雾化特性数值模拟[J].内燃机学报,2019,37（4）:359-366.
[16]	李霄月，邹建锋，张阳，等.液体射流首次破碎的直接数值模拟及动力学过程分析[J].推进技术,2018,39（7）:1529-1539.
[17]	陈潜，邹建锋，周程林，等.流向强迫作用下的液体初始雾化机制及动力学特征[J].推进技术，2020,41（2）:353-361.
[18]	POPINET S.An accurate adaptive solver for surface-tension-driven interfacial flows[J].Journal of Computational Physics,2009,228（16）:5838-5866.
[19]	SHINJO J,UMEMURA A.Simulation of liquid jet primary breakup:dynamics of ligament and droplet formation[J].International Journal of Multiphase Flow,2010,36（7）:513-532.
[20]	LEFEBVRE A H,MCDONELL V G.Atomization and sprays[M].Boca Raton，US:CRC Press,2017.
