基于纳米多孔薄膜的蒸发特性

王佳豪; 夏国栋; 李冉; 马丹丹

doi:10.13224/j.cnki.jasp.20210247

基于纳米多孔薄膜的蒸发特性

doi: 10.13224/j.cnki.jasp.20210247

北京工业大学环境与生命学部强化传热与过程节能教育部重点实验室暨传热与能源利用北京市重点实验室，北京 100124

基金项目: 国家自然科学基金（51976002）

详细信息

作者简介:
王佳豪（1993-），男，博士生，主要从事微纳尺度传热方面研究。

通讯作者:
夏国栋（1965-），男，教授，博士，主要从事两相流、微纳尺度传热方面研究。E-mail：xgd@bjut.edu.cn

中图分类号: V231.1;TK124
计量
- 文章访问数: 420
- HTML浏览量: 200
- PDF量: 75
- 被引次数: 0
出版历程
- 收稿日期: 2021-05-17
- 刊出日期: 2022-05-28

Evaporation processes from nanoporous membranes

Key Laboratory of Enhanced Heat Transfer and Energy Conservation， Ministry of Education，Beijing Key Laboratory of Heat Transfer and Energy Conversion， Faculty of Environment and Life， Beijing University of Technology，Beijing 100124，China

摘要

摘要: 实验研究了基于纳米多孔薄膜的蒸发特性，以氟化液FC-72为液态工质，对比分析了开口向上和向下时的相变特性。结果发现：两种工况下，其热流密度-过热度曲线具有相似的变化趋势，且均出现热流密度增加而温度保持不变的“薄液膜蒸发”区间。在低热流密度下，温度均较为稳定，但开口向下时的传热性能始终优于开口向上时，分析原因为重力对供液的影响和液膜厚度对热阻的改变。随着热流密度的增加，表面温度波动也越来越剧烈，甚至出现了温度的峰值，最终开口向下和向上达到的临界热流密度值分别为59 W/cm²和47 W/cm²；同时，对蒸发过程进行理论建模，得出其蒸发系数分别为0.043 1和0.021 9。
- 蒸发 /
- 纳米多孔薄膜 /
- 开口方向 /
- 传热特性 /
- 温度不稳定性
Abstract: Tests were conducted to study the evaporation processes from nanoporous membranes using FC-72.The heat transfer characteristics of two facing directions：membrane facing upward and downward，were compared.Results showed that the heat flux-superheat curves for two directions presented a similar variation trend，and there existed a‘thin film evaporation’ stage where heat flux increased while temperature remained constant.The temperature was stable in low heat flux.The heat transfer performance of downward-facing membrane was better than that of upward-facing membrane at different heat flux levels.This was caused by the effect of gravity on the liquid supply and the effect of liquid film thickness on thermal resistance.As the heat flux increased，the temperature fluctuated more sharply，eventually a temperature peak appeared.The critical heat flux reached 59 W/cm² and 47 W/cm² for downward and upward facing membranes，respectively.Additionally，theoretical modeling of the evaporation processes was carried out，and it was found that the evaporation coefficients were 0.043 1 and 0.021 9，respectively.
- evaporation /
- nanoporous membranes /
- facing directions /
- heat transfer characteristics /
- temperature instability characteristics

HTML

参考文献(22)

[1]	CHO H J,PRESTON D J,ZHU Y,et al.Nanoengineered materials for liquid-vapour phase-change heat transfer[J].Nature Reviews Materials,2016,2（2）:16092.1-16092.17.
[2]	WHEELER T D,STROOCK A D.The transpiration of water at negative pressures in a synthetic tree[J].Nature,2008,455（7210）:208-212.
[3]	ERP R V,SOLEIMANZADEH R,NELA L,et al.Co-designing electronics with microfluidics for more sustainable cooling[J].Nature,2020,585（7824）:211-216.
[4]	朱剑琴，赵超凡，邱璐，等.热障涂层在涡轮叶片应用中的热防护有效性[J].航空动力学报，2019，34（11）:2503-2508.
[5]	XIAO R,MAROO S C,WANG E N.Thin film evaporation using nanoporous membranes for enhanced heat transfer[C]∥Heat Transfer Summer Conference.Rio Grande,Puerto Rico:American Society of Mechanical Engineers,2012:103-107.
[6]	XIAO R,MAROO S C,WANG E N.Negative pressures in nanoporous membranes for thin film evaporation[J].Applied Physics Letters,2013,102（12）:147-169.
[7]	NARAYANAN S,FEDOROV A G,JOSHI Y K.On-chip thermal management of hotspots using a perspiration nanopatch[J].Journal of Micromechanics and Microengineering,2010,20（7）:075010.1-075010.10.
[8]	WANG Q,CHEN R.Ultrahigh flux thin film boiling heat transfer through nanoporous membranes[J].Nano Letters,2018,18（5）:3096-3103.
[9]	LU Z,WILKE K L,PRESTON D J,et al.An ultrathin nanoporous membrane evaporator[J].Nano Letters,2017,17（10）:6217-6220.
[10]	PLAWSKY J L,FEDOROV A G,GARIMELLA S V,et al.Nano- and microstructures for thin-film evaporation：a review[J].Nanoscale and Microscale Thermophysical Engineering,2014,18（3）:251-269.
[11]	KANDLIKAR S G.Controlling bubble motion over heated surface through evaporation momentum force to enhance pool boiling heat transfer[J].Applied Physics Letters,2013,102（5）:051611.1-051611.5.
[12]	TANJUNG E F,JO D.Surface orientation effects on bubble behaviors and critical heat flux mechanism in saturated water pool[J].International Journal of Heat and Mass Transfer,2019,133:179-191.
[13]	ZHAO X,ZHANG B,YANG Z,et al.Surface orientation effects on heat transfer performance of spray cooling[J].International Journal of Heat and Mass Transfer,2020,147:118960.1-118960.14.
[14]	XIA G,WANG J,ZHOU W,et al.Orientation effects on liquid-vapor phase change heat transfer on nanoporous membranes[J].International Communications in Heat and Mass Transfer,2020,119:104934.1-104934.11.
[15]	WILKE K L,BARABADI B,LU Z,et al.Parametric study of thin film evaporation from nanoporous membranes[J].Applied Physics Letters,2017,111（17）:171603.1-171603.5.
[16]	WANG Q,SHI Y,CHEN R.Transition between thin film boiling and evaporation on nanoporous membranes near the kinetic limit[J].International Journal of Heat and Mass Transfer,2020,154:119673.1-119673.9.
[17]	NARAYANAN S,FEDOROV A G,JOSHI Y K.Interfacial transport of evaporating water confined in nanopores[J].Langmuir,2011,27（17）:10666-10676.
[18]	AURSAND E,YTREHUS T.Comparison of kinetic theory evaporation models for liquid thin-films[J].International Journal of Multiphase Flow,2019,116:67-79.
[19]	POLIKARPOV A P,GRAUR I A,GATAPOVA E Y,et al.Kinetic simulation of the non-equilibrium effects at the liquid-vapor interface[J].International Journal of Heat and Mass Transfer,2019,136:449-456.
[20]	LI R,WANG J,XIA G.New model for liquid evaporation and vapor transport in nanopores covering the entire Knudsen regime and arbitrary pore length[J].Langmuir,2021,37（6）:2227-2235.
[21]	BUSUIOC S,GIBELLI L.Mean-field kinetic theory approach to Langmuir evaporation of polyatomic liquids[J].Physics of Fluids,2020,32（9）:093314.1-093314.11.
[22]	MA K T,PAN C.The effect of heated wall thickness and materials on nucleate boiling at high heat flux[J].International Communications in Heat and Mass Transfer,1999,26（8）:1103-1114.
