Chimera grid technology with IPDG method
-
摘要: 在内罚间断伽辽金(IPDG)方法框架内应用嵌套网格技术求解了二维可压缩Navier-Stokes方程。通过把黏性通量作为辅助变量实现了Navier-Stokes方程的降阶,继而用间断有限元方法进行离散得到空间半离散方程。时间推进采用Newton-Krylov隐式方法。利用库埃特流动精确解验证了该方法的精度。在此基础上,对包括有黏NACA0012翼型绕流、定常和非定常的圆柱绕流在内的若干典型测试算例开展数值模拟,进一步验证了该方法的鲁棒性和可靠性。在嵌套网格中应用了h型网格自适应技术用于提高激波分辨率,对NACA0012翼型无黏跨声速绕流开展数值模拟,结果表明:自适应之后的单元数相比无自适应时只增加了8.4%,但是激波分辨率得到了显著提高,激波附近的计算结果也与实验值符合得更好,从而验证了该方法的有效性。
-
关键词:
- 二维可压缩Navier-Stokes方程 /
- 嵌套网格 /
- 间断伽辽金方法 /
- 内罚方法 /
- h型网格自适应技术
Abstract: An internal penalty discontinuous Galerkin (IPDG) method was developed to solve the 2-D (two-dimensional)compressible Navier-Stokes equations together with chimera grid technique.The viscous flux was introduced as an auxiliary variable to reduce the equation order.The semi-discrete equation was solved with the discontinuous Galerkin method,and time marching was carried out with the implicit Newton-Krylov method.The accuracy of above methods was validated with the Couette flow in comparison of the exact solution.In addition,several test cases including viscous NACA0012 airfoil,steady and unsteady flow around a circular cylinder were simulated to verify the robustness and feasibility of the present methods.Eventually,the h-grid adaptive technique was also adopted in chimera grid to improve the resolution of shock wave.The inviscid transonic flow case over NACA0012 airfoil was also simulated.Result showed that,the number of cells after adaptation only increased by 8.4% compared with that without adaptation,but the shock resolution was significantly improved,and the calculated results near the shock were in better agreement with the experimental values,thereby verifying the effectiveness of the method. -
[1] BENEK J,STEGER J,DOUGHERTY F.A flexible embedding technique with application to the Euler equations[R].AIAA-1983-1944,1983. [2] CHAN W M.Overset grid technology development at NASA ames research center[J].Computers and Fluids,2009,38(3):496-503. [3] POMIN H,WAGNER S.Aeroelastic analysis of helicopter rotor blades on deformable chimera grids[J].Journal of Aircraft,2004,41(3):577-584. [4] SITARAMAN J,POTSDAM M,WISSINK A,et al.Rotor loads prediction using helios: a multisolver framework for rotorcraft aeromechanics analysis[J].Journal of Aircraft,2013,50(2):478-492. [5] SHI Lei,WANG Zhijian,FU Song,et al.A PNPM-CPR method for Navier-Stokes equations[R].AIAA-2012-460,2012. [6] SHERER S E,SCOTT J N.High-order compact finite-difference methods on general overset grids[J].Journal of Computational Physics,2005,210(2):459-496. [7] SHERER S,VISBAL M,GALBRAITH M.Automated preprocessing tools for use with a high-order overset-grid algorithm[R].AIAA-2006-1147,2006. [8] REED W H,HILL T R.Triangular mesh methods for the neutron transport equation[R].LA-UR-73-479,1973. [9] COCKBURN B,SHU Chiwang.TVB Runge-Kutta local projection discontinuous Galerkin finite element method for conservation laws:Ⅱ general framework[J].Mathematics of Computation,1989,52(186):411-435. [10] COCKBURN B,LIN S Y,SHU Chiwang.TVB Runge-Kutta local projection discontinuous Galerkin finite element method for conservation laws:Ⅲ one-dimensional systems[J].Journal of Computational Physics,1989,84(1):90-113. [11] COCKBURN B,HOU S,SHU Chiwang.The Runge-Kutta local projection discontinuous Galerkin finite element method for conservation laws:Ⅳ the multidimensional case[J].Mathematics of Computation,1990,54(190):545-581. [12] COCKBURN B,KARNIADAKIS G E,SHU Chiwang.Discontinuous Galerkin methods:theory,computation and applications[M].Berlin Heidelberg:Springer-Verlag,2000. [13] GALBRAITH M C,ORKWIS P D,BENEK J A.Extending the discontinuous Galerkin scheme to the chimera overset method[R].AIAA-2011-3409,2011. [14] GALBRAITH M C,BENEK J A,ORKWIS P D,et al.A discontinuous Galerkin chimera scheme[J].Computers and Fluids,2014,98:27-53. [15] GALBRAITH M C,ORKWIS P D,BENEK J A.A 3-D discontinuous Galerkin chimera overset method[R].AIAA-2014-0776,2014. [16] GALBRAITH M C,BENEK J A,ORKWIS P D,et al.A discontinuous Galerkin scheme for chimera overset viscous meshes on curved geometries[J].Computers and Fluids,2015,119:176-196. [17] NASTASE C,MAVRIPLIS D,SITARAMAN J.An overset unstructured mesh discontinuous Galerkin approach for aerodynamic problems[R].AIAA-2011-195,2011. [18] BRAZELL M J,KIRBY A C,MAVRIPLIS D.A high-order discontinuous-Galerkin octree-based AMR solver for overset simulations[R].AIAA-2017-3944,2017. [19] BASSI F,REBAY S.A high-order accurate discontinuous finite element method for the numerical solution of the compressible Navier-Stokes equations[J].Journal of Computational Physics,1997,131(2):267-279. [20] ARNOLD D N,BREZZI F,MARINI D.Unified analysis of discontinuous Galerkin methods for elliptic problems[J].Siam Journal on Numerical Analysis,2002,39(5):1749-1779. [21] BASSI F,CRIVELLINI A,REBAY S,et al.Discontinuous Galerkin solution of the Reynolds-averaged Navier-Stokes and k-ω turbulence model equations[J].Computers and Fluids,2005,34(4/5):507-540. [22] COCKBURN B,SHU Chiwang.The local discontinuous Galerkin method for time-dependent convection-diffusion systems[J].Siam Journal on Numerical Analysis,1998,35(6):2440-2463. [23] HARTMANN R,HOUSTON P.Symmetric interior penalty DG methods for the compressible Navier-Stokes equations:Ⅰ method formulation[J].International Journal of Numerical Analysis and Modeling,2006,3(1):1-20. [24] HARTMANN R,HOUSTON P.Symmetric interior penalty DG methods for the compressible Navier-Stokes equations:Ⅱ goal-oriented a posteriori error estimation[J].International Journal of Numerical Analysis and Modeling,2006,3(2):141-162. [25] DE WIART C C,HILLEWAERT K,BRICTEUX L,et al.Implicit LES of free and wall-bounded turbulent flows based on the discontinuous Galerkin/symmetric interior penalty method[J].International Journal for Numerical Methods in Fluids,2015,78(6):335-354. [26] TORO E F.Riemann solvers and numerical methods for fluid dynamics:a practical introduction[M].Berlin Heidelberg:Springer-Verlag,2009. [27] HARTMANN R.Adaptive discontinuous Galerkin methods with shock-capturing for the compressible Navier-Stokes equations[J].International Journal for Numerical Methods in Fluids,2006,51(9/10):1131-1156. [28] CAO Yihua,ZHAO Ming.Numerical simulation of rotor flowfields based on several spatial discretization schemes[J].Journal of Aircraft,2012,49(5):1535-1539. [29] ZHAO Ming,XIAO Zhixiang,FU Song.Predictions of transition on a hovering tilt-rotor blade[J].Journal of Aircraft,2014,51(6):1904-1913. [30] CRAIN T,GRAMOLI V,RAYNAL M.A contention-friendly binary search tree[R].Berlin Heidelberg:European Conference on Parallel Processing,2013. [31] WANG Zhijian,HARIHARAN N,CHEN Rangfu.Recent development on the conservation property of chimera[J].International Journal of Computational Fluid Dynamics,2001,15(4):265-278. [32] SUN Yuzhi,WANG Zhijian,LIU Yen.High-order multidomain spectral difference method for the Navier-Stokes equations[R].AIAA-2006-301,2006. [33] ZHANG Laiping,LIU Wei,LI Ming,et al.A class of DG/FV hybrid schemes for conservation law:Ⅳ 2D viscous flows and implicit algorithm for steady cases[J].Computers and Fluids,2014,97:110-125. [34] MüLLER B.High order numerical simulation of aeolian tones[J].Computers and Fluids,2008,37(4):450-462. [35] 孙强,吕宏强,伍贻兆.基于高阶物面近似的自适应间断有限元法欧拉方程数值模拟[J].空气动力学学报,2015,33(4):446-453.
