DR image enhancement of aero⁃engine guide vane based on improved CLAHE
-
摘要:
为了解决航空发动机导向叶片数字射线（DR）检测图像信息动态范围大、对比度低、细节信息不明显，缺陷区域难以识别的问题，提出一种改进型限制对比度自适应直方图均衡化（CLAHE）算法。采用CLAHE增强导向叶片DR图像对比度，同时引入基于空间均值滤波器的Gaussian掩模处理，进行DR图像降噪，提取DR图像的低频信息；采用CLAHE增强的图像与提取的DR图像低频信息线性做差，突出DR图像的高频细节信息；与CLAHE增强的图像线性叠加，进一步提高了DR图像的对比度，实现导向叶片DR图像增强。依据图像基本空间分辨率（SRB）、信噪比（SNR）、灰度平均值对DR图像增强效果进行评价。结果表明: 改进的CLAHE算法，可以同时将表征SRB的D13双丝线对应的调制深度值从49.17%提高到了56.08%,整体灰度平均值从32 400.66增加到了38 684.43，02号微小裂纹缺陷的SNR从14.10提升到了15.16。结果显示优化的CLAHE算法，相比自适应直方图均衡化（AHE）等4种经典的航空发动机导向叶片DR图像增强算法，不仅提高了平坦区域对比度，突显了边缘细节信息，而且有效提升了微小缺陷的视觉效果。
-
关键词:
- 数字射线（DR）图像 /
- 微小缺陷 /
- 导向叶片 /
- 限制对比度自适应直方图均衡化（CLAHE） /
- 图像增强
Abstract:In order to solve the problems of large dynamic range，low contrast，inconspicuous detail information，and difficulty in identifying defect areas in the image information detected by digital radiography （DR） of aero⁃engine guide blades，an improved adaptive histogram equalization algorithm with limited contrast was proposed.Contrast limited adaptive histogram equalization （CLAHE） was used to enhance the contrast of the DR image of the guide vane.Meanwhile，the Gaussian mask processing based on the spatial mean filter was introduced to reduce the image noise and extract the low⁃frequency information of the DR image.The high⁃frequency information of DR image was highlighted by difference of CLAHE enhanced image and the low⁃frequency information of DR image.Furthermore，a linear superimposing of CLAHE enhanced image and highlighted image high frequency information was employed to further improve the contrast of DR image and realize the enhancement of the DR image of the guide vane.In addition，the DR image enhancement effect was evaluated based on the basic spatial resolution of the image （SRB），signal⁃to⁃noise ratio （SNR） and gray average.Experimental results showed that the improved CLAHE algorithm can simultaneously increase the modulation depth value characterizing SRB correspondingly to the D13 double⁃filament wire from 49.17% to 56.08%，and the overall grayscale average value from 32 400.66 to 38 684.43，and the SNR of the No.02 micro crack defect was improved from 14.10 to 15.16.The result showed that the improved CLAHE algorithm not only improved the flat area contrast and highlighted the edge detail information，but also effectively improved visual effect of small defects in comparison with four classic aero⁃engine guide vane DR image enhancement algorithms such as adaptive histogram equalization （AHE）.
-
图 4 航空发动机导向叶片原图和局部DR图像
Figure 4. Original image and partial DR image of aero engine guide vane
图 6 导向叶片DR缺陷图像子块及灰度直方图
Figure 6. Sub⁃block and gray histogram of the DR defect image of the guide vane
图 7 自适应直方图均衡化处理结果及灰度直方图
Figure 7. Adaptive histogram equalization processing results and gray histogram
图 8 裁剪分配插值运算结果及灰度直方图
Figure 8. Interpolation operation results and gray histogram of crop distribution
图 10 Gaussian处理导向叶片DR图像子块及灰度直方图
Figure 10. Gaussian processing guide blade DR image sub⁃block and gray histogram
图 11 导向叶片DR图像低频信息及灰度直方图
Figure 11. Low⁃frequency information and gray histogram of the DR image of the guide vane
图 12 导向叶片DR图像高频信息及灰度直方图
Figure 12. High⁃frequency information and gray histogram of the DR image of the guide vane
图 13 改进CLAHE处理结果和灰度直方图
Figure 13. Improved CLAHE processing results and gray histogram
图 16 Gaussian滤波处理的导向叶片DR缺陷图像
Figure 16. DR defect image of guide vane processed by Gaussian filter
图 17 Unsharp锐化处理的导向叶片DR缺陷图像
Figure 17. DR defect image of guide vane processed byUnsharp sharpening
图 19 改进CLAHE处理的导向叶片DR缺陷图像
Figure 19. DR defect image of guide vane processed by improved CLAHE
图 22 AHE处理的导向叶片DR图像的测试结果
Figure 22. Test results of DR images of guide blades processed by AHE
图 23 Gaussian滤波处理的导向叶片DR图像的测试结果
Figure 23. Test results of DR images of guide blades processed by Gaussian filtering
图 24 Unsharp锐化处理的导向叶片DR图像的测试结果
Figure 24. Test results of DR images of guide blades processed by Unsharp sharpening
图 25 CLAHE算法处理的导向叶片DR图像的测试结果
Figure 25. Test results of DR images of guide blades processed by CLAHE algorithm
图 26 改进CLAHE算法处理的导向叶片DR图像的测试结果
Figure 26. Test results of DR images of guide blades processed by improved CLAHE algorithm
图 27 不同处理方式导向叶片DR整体图像和02号缺陷信噪比对比结果
Figure 27. Comparison results of the overall image of the guide blade DR with different processing methods and the signal⁃to⁃noise ratio of No.02 defect
表 1 不同处理方式导向叶片DR图像整体信噪比SNR
Table 1. Overall signal⁃to⁃noise ratio SNR of the DR image of guide blade with different processing methods
图像种类 灰度平均值 灰度均方差 信噪比/dB DR原始图像 32 400.66 9 634.52 3.36 AHE处理 32 578.79 10 724.24 3.04 Gaussian滤波 32 400.66 9 633.61 3.36 Unsharp锐化 32 412.68 9 645.22 3.37 CLAHE处理 33 522.93 9 926.95 3.38 改进CLAHE处理 38 684.43 9 998.56 3.87
下载: 导出CSV
表 2 不同处理方式02号缺陷的信噪比SNR
Table 2. Signal⁃to⁃noise ratio SNR of No.02 defect in different processing methods
图像种类 灰度平均值 灰度均方差 信噪比/dB DR原始图像 28 232.77 2 002.11 14.10 AHE处理 25 628.03 5 973.01 4.29 Gaussian滤波 28 232.81 2 001.42 14.10 Unsharp锐化 28 232.47 2 009.34 14.05 CLAHE处理 34 085.50 4 130.98 8.25 改进CLAHE处理 31 159.31 2 055.01 15.16
下载: 导出CSV
-
