含行星架裂纹故障的行星齿轮箱振动仿真

王丹凤; 郭瑜

doi:10.13224/j.cnki.jasp.20210267

含行星架裂纹故障的行星齿轮箱振动仿真

doi: 10.13224/j.cnki.jasp.20210267

王丹凤,
郭瑜^,

昆明理工大学机电工程学院，昆明 650500

基金项目:

国家自然科学基金 51675251

云南省重点领域科技计划项目 202002AC080001

详细信息

作者简介:
王丹凤（1993-），女，博士生，主要从事行星齿轮箱故障诊断、建模研究。

通讯作者:
郭瑜（1971-），男，教授，博士，主要从事旋转机械故障诊断研究。E⁃mail：kmgary@163.com

中图分类号: V232.3
计量
- 文章访问数: 241
- HTML浏览量: 290
- PDF量: 44
- 被引次数: 0
出版历程
- 收稿日期: 2021-05-27

Vibration simulation of planetary gearbox with planet⁃carrier crack

WANG Danfeng,
GUO Yu^,

Faculty of Mechanical and Electrical Engineering，Kunming University of Science and Technology，Kunming 650500，China

摘要

摘要:
为深入了解行星架裂纹故障振动频谱结构，提出一种考虑时变传递路径和行星轮系载荷非均匀分配的振动仿真模型。根据裂纹导致的行星轮角位移函数，分析了行星轮角位移对行星轮系载荷分配特性的影响，仿真分析了行星架裂纹导致的行星轮角位移和行星轮系载荷非均匀分配下的频谱边带结构。仿真结果表明：行星轮个数为3时，边频带仅受行星轮角位移影响，随行星轮个数增加到4、5时，频谱边带受行星轮角位移和载荷分配共同影响，阶比谱出现以行星架旋转阶次为间隔的调制边带成分。通过对比行星轮个数为3的齿轮箱仿真与实测信号的阶比谱边带结构，验证了模型的有效性。
- 行星架裂纹 /
- 时变传递路径 /
- 载荷分配系数 /
- 频谱边带 /
- 振动仿真
Abstract:
To deeply understand the vibration spectrum structure，a vibration simulation model considering the time⁃varying transfer paths and the uneven load sharing of the planetary gearbox was proposed.According to angular shift function of planet gears caused by the crack，the effect of the angular shift of planet gears on load sharing was analyzed.The spectrum sideband structure under the planet gear angular shift caused by the planet⁃carrier crack and the non⁃uniform load distribution was simulated and analyzed.The simulation results showed that when the number of planet gears was 3，the sideband was only affected by the additional angular displacement of planet gears.When the number increased to 4 and 5，the spectral sideband was jointly affected by the angular displacement and load distribution among planets，and the modulation sideband components with the rotation order of carrier appeared in the order spectrum.By comparing the order spectrum structure of the simulated signal and measured signal of the planetary gearbox with 3 planets，the effectiveness of the proposed model was verified.
- planet⁃carrier crack /
- time⁃varying transfer path /
- load sharing factor /
- spectral sideband /
- vibration simulation
注释:

1) 王碧珺

HTML

图 1 5个行星轮均布的行星齿轮箱

Figure 1. Planetary gearbox with 5 equally spaced planets

下载: 全尺寸图片幻灯片

图 2 行星轮系载荷分配曲线

Figure 2. Load sharing curves among all planet gears

下载: 全尺寸图片幻灯片

图 3 故障行星齿轮振动传递路径

Figure 3. Vibration transfer paths of the fault planet gear

下载: 全尺寸图片幻灯片

图 4 3个行星轮行星架裂纹故障振动信号阶比谱

Figure 4. Order spectrum of planet⁃carrier crack fault vibration signal with 3 planets

下载: 全尺寸图片幻灯片

图 5 4个行星轮行星架裂纹故障振动信号阶比谱

Figure 5. Order spectrum of planet⁃carrier crack fault vibration signal with 4 planets

下载: 全尺寸图片幻灯片

图 6 5个行星轮行星架裂纹故障振动信号阶比谱

Figure 6. Order spectrum of planet⁃carrier crack fault vibration signal with 5 planets

下载: 全尺寸图片幻灯片

图 7 行星齿轮传动实验台

Figure 7. Planetary gear transmission test rig

下载: 全尺寸图片幻灯片

图 8 行星架裂纹故障

Figure 8. Planet⁃carrier crack fault

下载: 全尺寸图片幻灯片

图 9 振动信号处理流程图

Figure 9. Flow chart of vibration signal processing

下载: 全尺寸图片幻灯片

图 10 行星架转速曲线

Figure 10. Speed profile of planet⁃carrier

下载: 全尺寸图片幻灯片

图 11 正常和行星架裂纹振动信号对比

Figure 11. Comparison of vibration signal between normal and planet⁃carrier crack

下载: 全尺寸图片幻灯片

图 12 正常和行星架裂纹故障振动信号阶比谱放大图

Figure 12. Partial magnification of vibration signal order spectrum of the normal and planet⁃carrier crack

下载: 全尺寸图片幻灯片

表 1 行星架裂纹导致的各行星轮角位移^[15]

Table 1. Angular shift of planets caused by carrier⁃plate crack^[15]

裂纹长度/mm	行星轮编号
裂纹长度/mm	1	2	3	4	5
0	0.17	0.17	0.17	0.17	0.17
11.15	0.18	0.17	0.18	0.17	0.16
22.30	0.19	0.17	0.18	0.17	0.16
$⋮$	$⋮$	$⋮$	$⋮$	$⋮$	$⋮$
78.05	0.32	0.18	0.19	0.16	0.12
$⋮$	$⋮$	$⋮$	$⋮$	$⋮$	$⋮$
133.80	1.07	0.16	0.29	0.06	0.01
$⋮$	$⋮$	$⋮$	$⋮$	$⋮$	$⋮$

下载: 导出CSV

表 2 行星轮角位移函数的拟合系数

Table 2. Fitting parameters of the angular shift function of each planet gear

行星轮编号	a₁_i/10^-8	a₂_i/10^-5	a₃_i/10^-4	θ₀/（°）
1	50.0	-4.12	22.8	0.17
2	13.8	-2.04	7.59	0.17
3	5.11	-3.14	3.22	0.17
4	-7.86	0.757	-2.48	0.17
5	4.66	-1.50	3.00	0.17

下载: 导出CSV

表 3 行星齿轮箱参数

Table 3. Parameters of the planetary gearbox

参数	齿轮
参数	太阳轮	行星轮（3个）	齿圈
齿数	Z_s=28	Z_p=20	Z_r=71
模数/mm	2.25	2.25	2.25
齿形角/（°）	20	20	20

下载: 导出CSV

参考文献(19)

[1]	SINGH A.Application of a system level model to study the planetary load sharing behavior[J].Journal of Mechanical Design,2005，127（3）：469⁃476.
[2]	SINGH A.Load sharing behavior in epicyclic gears:physical explanation and generalized formulation[J].Mechanism and Machine Theory,2010,45（3）:511⁃530.
[3]	SINGH A.Epicyclic load sharing map—development and validation[J].Mechanism and Machine Theory,2011,46（5）:632⁃646.
[4]	LIGATA H,KAHRAMAN A,SINGH A.A closed⁃form planet load sharing formulation for planetary gear sets using a translational analogy[J].Journal of Mechanical Design,2009,131（2）:021007.1⁃021007.7.
[5]	肖铁英,陆卫杰.行星齿轮机构均载系数的计算方法[J].燕山大学学报,1992,16（4）:290⁃295. XIAO Teiying,LUO Weijie.Calculative method of load balance coefficient in planetary gear[J].Journal of Yanshan University,1992,16（4）:290⁃295.（in Chinese）
[6]	李阳,刘光磊,刘更,等.基于间隙浮动的行星齿轮传动系统静力学均载分析[J].机械科学与技术,2009,31（8）:1115⁃1120. LI Yang,LIU Guanglei,LIU Geng,et al.Analysis of static load sharing in a planetary gear set with gap for gear floating[J].Mechanical Science and Technology for Aerospace Engineering,2009,31（8）:1115⁃1120.（in Chinese）
[7]	MCFADDEN P D,SMITH J D.An explanation for the asymmetry of the modulation sidebands about the tooth meshing frequency in epicyclic gear vibration[J].Journal of Mechanical Engineering Science,1985,199（1）:65⁃70.
[8]	MCNAMES J.Fourier series analysis of epicyclic gearbox vibration[J].Journal of Vibration and Acoustics Transactions of the ASME.,2002,124（1）:150⁃153.
[9]	INALPOLAT M,KAHRAMAN A.A theoretical and experimental investigation of modulation sidebands of planetary gear sets[J].Journal of Sound and Vibration,2009,323（3/4/5）:677⁃696.
[10]	FENG Zhipeng,ZUO Mingjian.Vibration signal models for fault diagnosis of planetary gearboxes[J].Journal of Sound and Vibration,2012,331（22）:4919⁃4939.
[11]	LIU Zongyao,LEI Yaguo,LIU Huan,et al.A phenomenological model for investigating unequal planet load sharing in epicyclic gearboxes[J].Mechanical Systems and Signal Processing,2019,135（1）：1064141⁃10641416.
[12]	KELLER J A,GRABILL P.Vibration monitoring of UH⁃60 A main transmission planetary carrier fault[R].Phoenix，AZ，US:the 59th American Helicopter Society Annual Forum,2003.
[13]	BLUNT D M,KELLER J A.Detection of a fatigue crack in a UH⁃60A planet gear carrier using vibration analysis[J].Mechanical Systems and Signal Processing,2006,20（8）:2095⁃2111.
[14]	PATRICK R,FERRI A,VACHTSEVANOS G.Effect of planetary gear carrier⁃plate cracks on vibration spectrum[J].Journal of Vibration and Acoustics,2012,134（6）：061001⁃0610012.
[15]	FAN Lei,WANG Shaoping,WANG Xingjian,et al.Nonlinear dynamic modeling of a helicopter planetary gear train for carrier plate crack fault diagnosis[J].Chinese Journal of Aeronautics,2016,29（3）:675⁃687.
[16]	KAHRAMAN A.Load sharing characteristics of planetary transmissions[J].Mechanism and Machine Theory,1994,29（8）:1151⁃1165.
[17]	LIANG Xihui,ZUO Mingjian,Pandey M.Analytically evaluating the influence of crack on the mesh stiffness of a planetary gear set[J].Mechanism and Machine Theory,2014,76（1）:20⁃38.
[18]	LEI Yaguo,LIU Zongyao,LIN Jing,et al.Phenomenological models of vibration signals for condition monitoring and fault diagnosis of epicyclic gearboxes[J].Journal of Sound and Vibration,2016,369（1）:266⁃281.
[19]	SAINSOT P,VELEX P,DUVERGER O.Contribution of gear body to tooth deflections:a new bidimensional analytical formula[J].Journal of Mechanical.Design,2004,126（4）:748⁃752.
