Infrared radiation signature of three bearing swivel nozzle
-
摘要: 针对涡扇发动机用三轴承矢量喷管（3BSN），通过数值模拟的方法研究了在巡航和垂直起降（VTOL）状态即非矢量和90°矢量状态下三轴承矢量喷管的红外辐射空间分布特征，并分析了其影响机理。结果表明，在非矢量状态下由于特殊的几何型面使得喷管下壁面出现了局部高温区，喷流形状也变成椭圆锥形，造成垂直探测面上正探测角壁面红外辐射较负探测角最大增加44.6%，水平探测面上的燃气红外辐射大于垂直探测面；90°矢量状态下，由于偏转的喷管结构对前端高温部件的遮挡，总辐射峰值仅为非矢量状态的43.3%；喷管90°矢量偏转使得远离曲率中心一侧的气流速度降低温度升高，喷管外侧出现了大范围的局部高温区，导致垂直探测面负探测角范围的壁面辐射大于正探测角范围，最大相对差值达到71.9%。喷管偏转也遮挡了部分喷管内部的高温燃气，垂直探测面负探测角的仅能覆盖喷管出口处的高温燃气区域，明显小于正探测角，造成燃气辐射出现了20%的最大相对差值。Abstract: In view of the three bearing swivel nozzle （3BSN） for turbofan engines，numerical simulation method was used to study the spatial distribution of infrared radiation signature of three bearing swivel nozzle under the working conditions of vertical take-off and landing （VTOL） and cruise（non-vectorial and 90° vectorial conditions），and the influence mechanism was also analyzed.The results showed that under non-vector state，the local high temperature area appeared on the lower wall of 3BSN due to the special geometry surface，and the jet shape became an elliptical cone，resulting in a maximum increase of 44.6% in wall infrared radiation from positive detection angle over negative detection angle at vertical plane，and the gas radiation on horizontal detection plane was greater than that on vertical detection plane.Under 90° vector state，the total radiation peak was only 43.3% of the non-vector state due to the shielding effect of deflected 3BSN structure on the front high-temperature components.The vector deflection of 3BSN reduced the gas velocity on the side far from curvature center and increased the temperature.A large local high temperature area appeared on the outside of the nozzle，which caused the wall radiation in negative detection angle range larger than that in positive detection angle on vertical detection plane，and the maximum relative difference was up to 71.9%.The deflection also obstructed the high temperature gas inside the nozzle.The negative detection angle of vertical detection plane can only cover the high temperature gas area at the nozzle exit，which was significantly smaller than the positive detection angle，resulting in the maximum relative difference of 20% in gas radiation.
-
[1] 索德军，梁春华，张世福,等.S/VTOL战斗机及其推进系统的技术研究[J].航空发动机，2014，40（4）:7-13. [2] SARIPALLI K，FARRELL D.Simulated flow visualization studies of the near field exhaust flow patterns for the Russian Yak-141 supersonic V/STOL aircraft[R].Santa Clara，US：International Powered Lift Conference，1993. [3] WIEGAND C.F-35 air vehicle technology overview[R].Atlanta，US：Aviation Technology，Integration and Operations Conference，2018. [4] KENTFIELD J A C.Nozzles for jet-lift V/STOL aircraft[J].Journal of Aircraft，1967，4（4）:283-291. [5] WYNOSKY T，SZYSZKO C.V/STOL deflector aerodynamic design criteria[R].Las Vegas，US：the 9th Propulsion Conference，1973. [6] EAMES D.A review of lift nozzle model testing at Rolls-Royce[R].Santa Clara，US：International Powered Lift Conference,1993. [7] TERRIER D，LU F.Aerodynamically controlled expansion nozzle for STOVL aircraft[R].Reno，US：the 41st Aerospace Sciences Meeting and Exhibit，2003. [8] LU F，TERRIER D.Performance analysis of stovl aircraft nozzle in hover[R].Reno，US:the 41st Aerospace Sciences Meeting and Exhibit，2003. [9] HOGGARTH R，MANGE R.Highlights of the Lockheed Martin F-35 STOVL jet effects program[R].London,UK:International Powered Lift Conference，2008. [10] BIRCKELBAW L，NELSON E.Infrared flow visualization of V/STOL aircraft[R].Hilton Head Island，US：Guidance，Navigation and Control Conference，1992. [11] 王向阳，朱纪洪，刘凯,等.三轴承推力矢量喷管运动学建模及试验[J].航空学报，2014，35（4）:911-920. [12] 刘帅，王占学，周莉,等.三轴承旋转喷管矢量偏转规律及流场特性研究[J].推进技术，2015，36（5）:656-663. [13] 张义军.三轴承推力矢量喷管结构设计与研究[D].兰州：兰州交通大学，2014. [14] 罗明东，吉洪湖，黄伟，等.涡扇发动机二元喷管的红外光谱辐射特性实验[J].推进技术，2007，28（4）:394-398. [15] 程稳，周莉，王占学，等.几何参数对S弯喷管红外辐射特性的影响[J].推进技术，2018，39（9）:1974-1985. [16] 杨承宇，张靖周，单勇.单边膨胀喷管红外辐射特性的数值模拟[J].航空学报，2010，31（10）：1919-1926. [17] 刘帅.短/垂起降飞机用推进系统性能模拟及三轴承偏转喷管设计技术研究[D].西安：西北工业大学，2016. [18] 刘帅，王占学，周莉,等.三轴承偏转喷管驱动力矩计算及动态特性分析[J].航空动力学报，2016,31（12）:2851-2858. [19] 罗明东.无人机排气系统红外隐身技术研究[D].南京：南京航空航天大学，2006. -
