Method of dynamic stress measurement calibration tests for compressor blades
-
摘要: 提出了一种提高压气机叶片动应力测量准确度的方法，即在发动机叶片装配前，对已完成应变计粘贴的测试叶片开展动应力测量标定试验，获取试验应变计输出值与叶片各阶振动最大模态应变区域的敏感度，试验结果可用于指导发动机试车时叶片动应力限制值的设置，从而更准确地监控叶片的振动安全状态。对比分析了直接应力法和af强度法（振幅a和振动频率f的乘积）两种试验方法的优缺点。基于直接应力法，针对某压气机叶片开展了动应力测量标定试验，结果显示：1#叶片试验应变计对第1阶、第3阶模态的敏感度实测值较理论值分别大17.4%和24%，而1#叶片试验应变计和2#叶片试验应变计对第1阶模态的敏感度差异达到14.8%。试验结果证明开展动应力测量标定试验，可综合提高叶片动应力测试数据利用的有效性。Abstract: A method to improve the dynamic stress measurement accuracy for compressor blades was introduced.Dynamic stress calibration tests of the instrumented blades were carried out before assembly of the rotor.Strain gauge sensitivity ratios of the measured strain to the maximum modal strain for each vibration mode of the instrumented blades were acquired.The ratios were helpful in defining strain monitoring limits for the blades during engine tests，which made blade vibration safety monitoring more accurate.Advantages and drawbacks of two calibration methods，direct stress and af strength method （the product of vibration amplitude a multiplies vibration frequency f），were comparatively analyzed.Based on the direct stress method，stress calibration tests for two compressor blades were carried out.Results showed that the measured gauge sensitivity ratios of the 1# blade for the 1st mode and the 3rd mode were larger than the theoretical ratios with values of 17.4% and 24% respectively.And the gauge sensitivity ratio differences of the two blades （1# blade and 2# blade） for the 1st vibration mode reached 14.8%.It proved that calibration tests could improve measured data validation for blade dynamic stress comprehensively.
-
[1] 170厂,驻170厂军代表室.航空发动机叶片失效分析及预防措施研究[C]∥ 航空发动机叶片故障及预防研讨会论文集 .北京:航空工业出版社，2005:74-95.[2] COWLES B A.High cycle fatigue in aircraft gas turbines-an industry perspective[J].International Journal of Fracture，1996，80（2）:147-163. [3] NICHOLAS T.High cycle fatigue A mechanics of materials perspective[M].London，UK:Elsevier，2006. [4] Federal Aviation Administration. Airworthiness standards:aircraft engines：14 CFR Part 33 Subpart F [S].Washington,US：Federal Aviation Administration，2003:45.[5] 吴大观.不容忽视发动机叶片动应力测量的作用[J].燃气涡轮试验与研究，1996，9（1）:58-62. [6] 彭建，刘兵.压气机转子叶片动频动应力测试技术和应用研究[J].燃气涡轮试验与研究，2003，16（1）:10-13. [7] 曹昆华，黄家经.某型发动机低压涡轮转子叶片动测技术及应用研究[J].燃气涡轮试验与研究，2008，21（1）：22-25. [8] 卢艳辉，梅庆，雷沫枝，等.高转速压气机转子叶片的动应力测试与动力学设计评估[J].推进技术，2014，35（10）：1398-1403. [9] 王奉明，贺进，朱俊强.高转速小尺寸涡轮叶片动应力测量方法与应用[J].推进技术，2018，39（6）:1406-1411. [10] 张再德，文华.涡轴发动机燃气涡轮叶片动应力测试技术研究及验证[J].燃气涡轮试验与研究，2019，32（3）:8-12. [11] WILLIAMS R J，JOHAL K L，BARTON H A，et al.Prediction and measurement of rotor blade/stator vane dynamic characteristics of a modern aero-engine axial compressor[C]∥ Proceedings of the Conference Held at the University of Liverpool ，Oxford，UK:Pergamon Press，1989:163-169.[12] DANFORTH C E.Blade vibration:some key elements in design verification[J].Journal of Aircraft，1975，12（4）:333-342. [13] SARAVANAMUTTOO H I H，ROGERS G F C，COHEN H，et al.Gas turbine theory[M]. 7th ed .Harlow，UK:Pearson Education Limited，2017.[14] ARMSTRONG E K.Recent blade vibration techniques[J].Journal of Engineering for Power，1967,89（3）:437-444. [15] ARMSTRONG E K.Fatigue and assessment methods of blade vibration[M]∥AGARD（Advisory Group for Aerospace Reaearch and Development）.AGARD Manual on Aeroelasticity in Axial-Flow Turbomachines:Volume 2 Structural Dynamics and Aeroelasticity，Essex，UK:Specialised Printing Services Limited，1988:33-34. [16] 宋兆泓.航空燃气涡轮发动机强度设计[M].北京：北京航空学院出版社，1988. [17] BLACKWELL B D.Some investigations in the field of blade engineering[J].Journal of the Royal Aeronautical Society，1958，62（573）:633-646. [18] ARMSTRONG E K，CROWCROFT R S，HUNT T M.Fatigue life of compressor blading[C]∥ Proceedings of the Institution of Mechanical Engineers ，London:SAGE Publications，1966,180（39）:61-70.[19] PASSEY R D C.Reliability of compressor aero foils[J].Progress in Aerospace Sciences，1976，17（3）:67-92. [20] 中国民用航空局. 航空发动机适航规定:CCAR-33-R2 [S].北京：中国民用航空局，2016:37. -
