TiAl合金低循环疲劳行为与寿命预测模型

李维; 蒋康河; 马莉; 曾武; 杨俊杰

doi:10.13224/j.cnki.jasp.20210440

TiAl合金低循环疲劳行为与寿命预测模型

doi: 10.13224/j.cnki.jasp.20210440

李维¹,
蒋康河^1, ,,
马莉¹,
曾武²,
杨俊杰³

1.
中国航空发动机集团有限公司湖南动力机械研究所，湖南株洲 412002
2.
中国科学院工程热物理研究所，北京 100190
3.
清华大学航空发动机研究院，北京 100085

基金项目: 航空动力基金（6141B090544）；湖南省自然科学基金（2019JJ50702）

详细信息

作者简介:
李维（1973-），男，研究员，博士，主要从事航空发动机设计工作。

通讯作者:
蒋康河（1989-），男，高级工程师，博士，主要从事航空发动机结构设计工作。E-mail：peamy@126.com

中图分类号: V232.4;O346.2
计量
- 文章访问数: 685
- HTML浏览量: 134
- PDF量: 186
- 被引次数: 0
出版历程
- 收稿日期: 2021-08-11
- 刊出日期: 2021-12-28

Low cycle fatigue behavior and life prediction model of TiAl superalloy

LI Wei¹,
JIANG Kanghe^{1
, ,},
MA Li¹,
ZENG Wu²,
YANG Junjie³

1.
Hunan Aviation Powerplant Research Institute，Aero Engine Corporation of China，Zhuzhou Hunan 412002，China
2.
Institute of Engineering Thermophysics， Chinese Academy of Sciences，Beijing 100190，China
3.
Institute of Aero Engine，Tsinghua University，Beijing 100085，China

摘要

摘要: 通过400 ℃和750 ℃下的单轴应变控制低循环疲劳（LCF）试验获取了一种TiAl合金循环变形行为和低循环疲劳寿命。合金在应变循环载荷下具有较稳定的循环特性，未出现明显的循环软化或循环硬化现象。Ramberg-Osgood方程能够较好地描述合金的循环应力-应变关系，疲劳寿命与总应变幅值近似呈对数线性关系。材料在750 ℃条件下呈现韧性断裂特征，在400 ℃条件下材料脆性特征较为明显。试件失效以层状组织跨层断裂为主，且层间断裂现象都随应变幅的增加而大幅减少，值得注意的是材料在750 ℃时氧化速度明显加快。与Manson-Coffin模型相比较，Cruse-Meyer模型尽管数学形式更简单，材料常数更少，但对具有低温度高应力的叶片榫头部位的寿命预测精度不高，不宜直接用于钛铝合金叶片寿命预测。
- TiAl合金 /
- 低循环疲劳（LCF） /
- 循环应力-应变关系 /
- 寿命预测 /
- 断口形貌
Abstract: Axial strain-controlled low cycle fatigue （LCF） tests were carried out on the TiAl superalloy at 400 ℃ and 750 ℃ to obtain the cyclic behavior and LCF lifetime.The superalloy exhibited stable cyclic characteristics，i.e.no obvious cyclic softening or cyclic hardening during test.The cyclic stress-strain relationship was well described by the Ramberg-Osgood equation.LCF lives at different temperatures had a log-linear relationship with the total strain ranges.Fracture morphology revealed that the TiAl superalloy presented pronounced ductile fracture and significant oxidation at 750 ℃，while the brittle fracture of the material was obvious at 400 ℃.Meanwhile，translamellar fracture was dominant for the lamellar microstructure at both temperature，and the percentage of the interlamellar fracture decreased with the strain amplitude.It was noteworthy that oxidation was significantly accelerated at 750 ℃.Compared to the Manson-Coffin model，although the Cruse-Meyer model had simpler mathematical form and fewer material constants，it was not accurate enough to predict the life of the tenon part of turbine blades with lower temperature but heavy centrifugal load.Hence，the model was not suitable to be applied to TiAl turbine blade directly.
- TiAl superalloy /
- low cycle fatigue（LCF） /
- cyclic stress-strain relationship /
- life prediction /
- fracture morphology

HTML

参考文献(22)

[1]	HODGE A M,HSIUNG L M,NIEH T G.Creep of nearly lamellar TiAl alloy containing W[J].Scripta Materialia,2004,51（5）:411-415.
[2]	ZHANG S Z,ZHANG C J,DU Z X,et al.Microstructure and tensile properties of hot fogred high Nb containing TiAl based alloy with initial near lamellar microstructure[J].Materials Science and Engineering:A,2015,642:16-21.
[3]	WEN Y F,SUN J.Generalized planar fault energies and mechanical twinning in gamma TiAl alloys[J].Scripta Materialia,2013,68（9）:759-762.
[4]	KITASHIMA T,KAWAMURA T.Prediction of oxidation behavior of near:α titanium alloys[J].Scripta Materialia,2016,124:56-58.
[5]	DONG C,YU H,JIAO Z,et al.Low cycle fatigue,creep and creep-fatigue interaction behavior of a TiAl alloy at high temperatures[J].Scripta Materialia,2018,144：60-63.
[6]	杨益,党明珠,李伟,等.激光选区熔化钛铝合金裂纹形成机理及抑制研究[J].机械工程学报,2020,56（3）:181-188.
[7]	王茂松,杜宇雷.增材制造钛铝合金研究进展[J].航空学报,2021,42（7）:625263.1-625263.24.
[8]	于慧臣,董成利,焦泽辉,等.一种TiAl合金的高温蠕变和疲劳行为及其寿命预测方法[J].金属学报,2013,49（11）:1311-1317.
[9]	BARTOLOTTA P,BARRETT J,KELLY T,et al.The use of cast Ti-48Al-2Cr-2Nb in jet engines[J].The Journal of The Minerals,Metals and Materials Society,1997,49（5）:48-50.
[10]	HUANG S C,LATHAM N Y.Titanium aluminum alloys modified by chromium and niobium and method of preparation：US4879092[P].1989-11-07.
[11]	杨锐.钛铝金属间化合物的进展与挑战[J].金属学报,2015,51（2）:129-147.
[12]	CHEN G,PENG Y B,ZHENG G,et al.Polysynthetic twinned TiAl single crystals for high-temperature applications[J].Nature Materials,2016,15（8）:876-881.
[13]	BEWLAY B,NAG S,SUZUKI A,et al.TiAl alloys in co mmercial aircraft engines[J].Materials at High Temperatures,2016,33（4/5）:549-559.
[14]	董成利,胡晓安.一种TiAl合金的高温疲劳-蠕变交互力学行为与寿命预测方法[J].航空材料学报,2020,40（4）:36-44.
[15]	张部声,祝济之,史剑,等.某型钛铝合金航空发动机叶片高温高周振动疲劳实验[J].航空动力学报,2020,35（6）:1169-1175.
[16]	ZHANG B,WANG R,HU D,et al.Stress-controlled LCF experiments and ratcheting behaviour simulation of a nickel-based single crystal superalloy with[001] orientation[J].Chinese Journal of Aeronautics,2020,34（8）:112-121.
[17]	RECINA V,LUNDSTRM D,KARLSSON B.Tensile creep,and low-cycle fatigue behavior of a cast $γ$ -TiAl-based alloy for gas turbine applications[J].Metallurgical and Materials Transactions:A,2002,33（9）:2869-2881.
[18]	梁泽芬,张俊喜,易湘斌,等. $β / γ$ 三相钛铝合金Ti-43Al-8.5V-Y的应变疲劳性能[J].化工机械,2020,47（1）:28-32.
[19]	CRUSE T A,MEYER T G.A cumulative fatigue damage model for gas turbine engine disks subjected to complex mission loading[J].Journal of Engineering for Gas Turbines and Power,1979,101（4）:563-571.
[20]	MANSON S S.Fatigue:a complex subject-some simple approximations[J].Experimental Mechanics,1965,5（4）:193-226.
[21]	王延荣,杨顺,李宏新,等.总应变寿命方程中疲劳参数的确定和寿命预测[J].航空动力学报,2018,33（1）:1-14.
[22]	姚卫星.结构疲劳寿命分析[M].北京:国防工业出版社,2003.
