直升机变距拉杆杆端自润滑关节轴承的力学分析和损伤特性

周长春; 杨永生; 谭德强; 杨晓强; 贺强; 胡月

doi:10.13224/j.cnki.jasp.20210674

直升机变距拉杆杆端自润滑关节轴承的力学分析和损伤特性

doi: 10.13224/j.cnki.jasp.20210674

中国民用航空飞行学院航空工程学院，四川广汉 618307

基金项目: 国家自然科学基金（52105132）；四川省应用基础研究项目（2020YJ0192、2021YJ0537）；四川省科技成果转移转化平台项目（2019ZHCG0139）；中国民用航空飞行学院面上项目（J2021-044）

详细信息

作者简介:
周长春（1972-），男，教授，硕士，主要从事通用航空器零部件适航与安全研究。

通讯作者:
谭德强（1989-），男，副教授，博士，主要从事航空器关键零部件服役行为和损伤机理研究。E-mail：tdqtx2@163.com

中图分类号: V258.5;TH117.1
计量
- 文章访问数: 469
- HTML浏览量: 119
- PDF量: 118
- 被引次数: 0
出版历程
- 收稿日期: 2021-11-28
- 刊出日期: 2022-05-28

Mechanical analysis and damage characteristics of self-lubricating joint bearings of helicopter variable-pitch tie rod ends

Aviation Engineering College，Civil Aviation Flight University of China，Guanghan Sichuan 618307，China

摘要

摘要: 以R44直升机主旋翼变距拉杆杆端自润滑关节轴承为研究对象，用三维建模软件Solidworks建立其旋转摆动的有限元模型并导入到有限元分析软件Ansys Workbench中，分析计算其在径向正弦载荷下衬垫的等效应力、位移、接触应力和等效剪切应力的变化特性；并结合实际服役工况下R44直升机失效的自润滑关节轴承衬垫进行分析。结果表明：在整个周期内，衬垫的边缘因为被挤压而发生变形，衬垫的等效应力和等效变形最大值均出现在外圈的边缘上，接触应力最大值所在的区域始终出现在衬垫的顶部和底部，并且接触应力分布区域的移动与内圈的转动方向一致，切应力最集中的地方在径向载荷施加点的左上方、左下方、右上方、右下方以及左右两侧；由于实际服役工况中载荷的变化，导致衬垫的损伤上半部分是以接触应力引起的疲劳损伤为主，下半部分是以切应力导致的转移膜形成为主。
- 关节轴承 /
- 有限元分析 /
- 径向载荷 /
- 自润滑衬垫 /
- 摩擦磨损
Abstract: The self-lubricating joint bearings of the R44 helicopter main rotor variable-pitch tie rod ends were taken as the research objects.The rotating and swinging finite element model was established with three-dimensional modeling software Solidworks and applied to the finite element analysis software Ansys Workbench.The change characteristics of equivalent stress，displacement，contact stress and shear stress of the liner under radial sinusoidal load were analyzed and calculated，and the failure of the self-lubricating joint bearing liner of the R44 helicopter under actual service conditions was analyzed.The results showed that during the whole period，the edge of the liner was deformed due to being squeezed，and the equivalent stress and the equivalent maximum deformation of the liner appeared on the edge of the outer ring；the area with the maximum contact stress always appeared at the top and bottom of the liner，and the movement of the contact stress distribution area was consistent with the rotation direction of the inner ring； the most concentrated shear stress was in the upper left，lower left，upper right，lower right，left and right areas of the radial load application point.Due to the change of load in actual service conditions，the damage of liner was mainly caused by fatigue damage arising from contact stress in the upper part and transfer film was caused by shear stress in the lower part.
- joint bearing /
- finite element analysis /
- radial load /
- self-lubricating liner /
- fraction and wear

HTML

参考文献(22)

[1]	魏立保,陈有光.自润滑关节轴承的研制与应用[J].轴承,2008（5）:8-10.
[2]	ZHANG Zhaozhu,SU Fenghua,WANG Kun,et al.Study on the friction and wear properties of carbon fabric composites reinforced with micro- and nano-particles[J].Materials Science and Engineering:A,2005,404（1-2）:251-258.
[3]	GUO Fang,ZHANG Zhaozhu,LIU Weimin,et al.Influence of solid lubricant reinforcement on wear behavior of Kevlar fabric composites[J].Journal of Applied Polymer Science,2008,110（3）:1771-1777.
[4]	应盛盛,杨晓翔.自润滑关节轴承固化工艺的有限元模拟研究[J].机电工程,2015,32（6）:773-777.
[5]	GUO Qiang,SONG Yunfeng,QIAO Hongbin,et al.Friction and wear properties of the spherical plain bearing with self-lubricating composite linear in oscillatory movement[J].Journal of Wuhan University of Technology,2004,19（4）:86-90.
[6]	胡宝根,王卫英,岳琳琳.基于有限元法的自润滑关节轴承静力学分析[J].轴承,2014（4）:10-13.
[7]	张瑞芬,吴连平,杨晓翔.自润滑关节轴承二次挤压装配的有限元仿真分析[J].轴承,2015（11）:20-22,56.
[8]	杨帆,孟国营,吴炳胜.多绳摩擦提升机天轮衬垫的有限元分析[J].煤炭工程,2011（3）:99-101.
[9]	李杨,司东宏,余永健,等.可变角度径向加载下的轴肩轴承有限元分析[J].机床与液压,2021,49（6）:124-128.
[10]	KIM B C,DONG C P,KIM H S,et al.Development of composite spherical bearing[J].Composite Structures，2006,75（1）:231-240.
[11]	KIM B C,LEE D G.Endurance and performance of a composite spherical bearing[J].Composite Structures,2009,87（1）:71-79.
[12]	李迎春,邱明,苗艳伟.PTFE/芳纶纤维编织衬垫自润滑关节轴承的黏接性能及摩擦学性能[J].中国机械工程,2016,27（2）:222-229.
[13]	邱明,张亚涛,卢团良,等.套圈材料对自润滑关节轴承热力学性能的影响[J].航空动力学报,2020,35（10）:2097-2103.
[14]	TAN Deqiang,LI Rui,YANG Xiaoqiang,et al.Tribological behavior of PTFE/Kevlar fabric under different contact stresses[J].AIP Advances,2021,11:035233.1-035233.10
[15]	戴雨静,汪久根,陈芳华,等.带挡边关节轴承静力学有限元分析[J].润滑与密封,2020,45（9）:7-11.
[16]	贾新哲.直升机不可逾越速度试飞方法的研究[C]∥中国航空学会第十七届全国直升机年会论文集.北京:中国航空学会,2001:302-305.
[17]	刘云帆,秦红玲,韩翠红,等.自润滑关节轴承寿命试验及损伤失效机理研究现状[J].材料导报,2021（1）:36-45.
[18]	李英,李宝福,李如琰.自润滑关节轴承接触应力分析[J].轴承,2016（5）:32-36.
[19]	TAN Deqiang,LI Rui,HE Qiang,et al.Failure analysis of the joint bearing of the main rotor of the Robinson R44 helicopter:A case study[J].Wear,2021,477:203862.1-203862.10.
[20]	邱明,周大威,庞晓旭.织物衬垫编织工艺对自润滑关节轴承摩擦学性能的影响[J].兵工学报,2017,38（9）:1867-1872.
[21]	邱明,周占生,周大威,等.聚四氟乙烯/聚苯硫醚织物自润滑关节轴承的摩擦学性能[J].摩擦学学报,2018,38（5）:547-553.
[22]	向定汉,潘青林,姚正军.聚四氟乙烯自润滑编织复合材料关节轴承的摆动摩擦磨损性能研究[J].摩擦学学报,2003,23（1）:72-75.
