Research on transient load for transonic compressor based on dynamic boundaries
-
摘要: 针对航空涡轮发动机压气机部件的过渡态,基于动态边界并结合双向流固耦合(FSI)方法模拟了跨声速压气机NASA Rotor 67的过渡态过程,获得了考虑叶片弹性变形的压气机过渡过程特性曲线,研究了叶片气动弹性变形对跨声速压气机加速过程中气动参数、流场激波结构演变过程的影响,分析了加速过程中非定常气动载荷与离心载荷共同作用下的叶片变形特征。结果表明:随转速升高,叶片变形对上半叶高区域的总压比和总温比的影响较显著;加速过程中,叶片变形对通道内激波结构特征及其演变有一定的影响;叶片变形主要集中在上半叶高,以弯曲变形为主导,主要由离心载荷造成,加速过程中叶尖区域的叶型出现反扭现象,从而引起压气机气动性能参数的变化。
-
关键词:
- 动态边界 /
- 跨声速压气机 /
- 过渡态性能 /
- 叶片变形 /
- 流固耦合 (FSI)
Abstract: Focusing on the transient state of aviation turbine engines components, a method based on dynamic boundaries and a two-way fluid-structure interaction(FSI) method were used to calculate the acceleration process of the transonic compressor NASA Rotor 67.The curve of the compressor transient process considering the blade deformation was calculated, and the influences of the aeroelastic deformation of the blade on the aerodynamic parameters during the acceleration process and the shock wave structure and evolution process in the flow field were studied.And the deformation distribution of the blade in acceleration process under unsteady aerodynamic load and centrifugal load was also studied.The results showed that: with the increase of the rotational speed, the influence of the blade deformation on the total pressure ratio parameter and the total temperature ratio parameter was more obvious.The structure and evolution of the shock wave in the flow path when considering blade deformation were slightly different with those without blade deformation in the acceleration process of the transonic compressor.The transient load caused the gradual increase of blade deformation during the acceleration process.The blade deformation was mainly concentrated in the upper half of the blade, and mainly caused by centrifugal load, which was dominated by bending deformation, and caused the torsion phenomenon at the leading edge of the tip to cause change of aerodynamic performance. -
[1] 陈懋章,刘宝杰.风扇/压气机气动设计技术发展趋势-用于大型客机的大涵道比涡扇发动机[J].航空动力学报,2008,23(6):961-975. CHEN Maozhang,LIU Baojie.Fan/compressor aero design trend and chal lenge on the development of high bypass ratio turbofan[J].Journal of Aerospace Power,2008,23(6):961-975.(in Chinese) [2] GANJI A R,KHADEM M,KHANDANI S M H.Transient dynamics of gas turbine engines[R].Cincinnati,Ohio, US:ASME International Gas Turbine and Aeroengine Congress and Exposition,1993. [3] 周盛.叶轮机气动弹性力学引论[M].北京:国防工业出版社,1989. [4] LANE F.System mode shapes in the flutter of compressor blade rows[J].Journal of the Aeronautical Sciences,1956,23(1):54-66. [5] VERDON J.Linearized unsteady aerodynamics for turbomachinery aeroelastic applications[J].Journal De Physique:Ⅲ,2013,2(4):481-506. [6] LI P.Double linearization theory for a rotating supersonic annular cascade of oscillating blades[J].Memoirs of the Faculty of Engineering,1990,50:161-185. [7] DOI H,ALONSO J J.Fluid/structure coupled aeroelastic computations for transonic flows in turbomachinery[R].Amsterdam,Netherlands:ASME Turbo Expo:Power for Land,Sea,and Air,2002. [8] DOWELL E H,HALL K C.Modeling of fluid-structure interaction[M].Amsterdam,Netherlands:Springer Netherlands,2005:445-490. [9] RZADKOWSKI R,GNESIN V.3-D inviscid self-excited vibrations of a blade row in the last stage turbine[J].Journal of Fluids and Structures,2007,23(6):858-873. [10] RZADKOWSKI R,GNESIN V,KOLODYAZHNAYA L.Unsteady forces acting on rotor blades in five and half compressor stage[J].Advances in Vibration Engineering and Technologies,2013,12(3):287-301. [11] KUBITZ L,RZADKOWSKI R,GNESIN V,et al.Direct integration method in aeroelastic analysis of compressor and turbine rotor blades[J].Journal of Vibrational Engineering and Technologies,2016,4(1):37-42. [12] ANSYS CFX.User's guide-14[M].New York:ANSYS Incorporation,2012. [13] 张章.风扇/压气机气动弹性动力响应的机理与应用研究[D].北京:北京航空航天大学,2013. ZHANG Zhang.Mechanism and application of aeroelastic dynamical response of fan/compressor[D].Beijing:Beijing University of Aeronautics and Astronautics,2013.(in Chinese) [14] YANG X,HOU A,ZHANG M,et al.Flow field and vibration behavior of the rotor due to mistuning IGV in a transonic compressor[R].Houston,Texas,US:ASME International Mechanical Engineering Congress and Exposition(IMECE),2012:267-274. [15] LI M,HOU A,YANG X,et al.Flow field and vibration behavior of straight transonic compressor cascade due to external acoustic excitation[R].ASME Paper GT2013-94770,2013. [16] 王洪伟.我所理解的流体力学[M].北京:国防工业出版社,2014. [17] 郭倩楠.基于动态边界的跨声速压气机过渡态载荷研究[D].北京:北京航空航天大学,2018. GUO Qiannan.Research on transient load for transonic compressor based on dynamic boundaries[D].Beijing:Beijing University of Aeronautics and Astronautics,2018.(in Chinese) [18] STRAZISAR A J,WOOD J R,HATHAWAY M D,et al.Laser anemometer measurements in a transonic axial flow fan rotor[R].NASA-TP-2879,1989. [19] 廉筱纯.航空发动机原理[M].西安:西北工业大学出版社,2005. [20] 郭倩楠,李绍斌,宋西镇,等.基于动态边界的跨声速压气机过渡态三维模拟方法[J].推进技术,2019,40(6):1231-1238. GUO Qiannan,LI Shaobin,SONG Xizhen,et al.Three-dimensional transient simulation method for transonic compressor based on dynamic boundaries[J].Journal of Propulsion Technology,2019,40(6):1231-1238.(in Chinese) [21] 赵赫楠.跨声速压气机过渡态气动匹配研究[D].北京:北京航空航天大学,2020. ZHAO Henan.Research on aerodynamic matching of transonic compressor in transient process[D].Beijing:Beijing University of Aeronautics and Astronautics,2020.(in Chinese) [22] WANG Songbai,LI Shaobin,SONG Xizhen.Investigations on static aeroelastic problems of transonic fans based on fluid-structure interaction method[J].Journal of Power and Energy,2016,230(7):685-695. [23] 汪松柏,李绍斌,宋西镇.基于流固耦合方法的跨声速叶片气动和强度性能研究[J].振动与冲击,2016,35(20):104-110. WANG Songbai,LI Shaobin,SONG Xizhen.Investigations on aerodynamic and mechanical performance of a transonic blade based on a fluid-structure interaction method[J].Journal of Vibration and Shock,2016,35(20):104-110.(in Chinese)
