Improved design of pressure reduction ratio characteristics of a nozzle afterburner regulator
-
摘要: 为解决某型喷口加力调节器在配装发动机使用过程中存在的涡轮落压比偏离设计值问题，对一维定常可压缩拉瓦尔喷管的气体流动状态进行了理论分析计算，从涡轮落压比的连续性工作要求分析了拉瓦尔喷管正常工作的使用条件，提出了空气减压器二级减压拉瓦尔喷管扩张段流道形状的改进设计方法，并通过了发动机试验验证，结果表明：空气减压器只有在超临界状态工作，并且激波位置在测压点位置后面时，才能保证减压比仅与针塞位置有关，与进气压力大小无关；进气压力较低时，激波位置离测压点较近，会造成减压比相对稳定状态存在偏差；增大喉道面积，可使得相同进气条件下，激波位置后移，远离测压点，有利于提高减压比的稳定性，增大后端角度会导致激波位置前移，不利于减压比的稳定。Abstract: In order to solve the problem that the turbine drop pressure ratio deviates from the design value in the use of a nozzle afterburner regulator with an engine，the gas flow state of one-dimensional steady compressible Laval nozzle was theoretically analyzed and calculated，and the service conditions for the normal operation of Laval nozzle were analyzed according to the continuous working requirements of turbine drop pressure ratio；an improved design method for the secondary decompression Laval nozzle air pressure reducer expansion groove shape was proposed，and the engine test was conducted.The results showed that when the air pressure reducer only worked in supercritical state，and the shock wave was positioned behind the pressure measuring point location，it could ensure that relief was only associated with the position of pin plug，but had nothing to do with the inlet pressure.When the inlet pressure was low，the shock wave position was close to the pressure measuring point，which caused the deviation of the decompression ratio in the relative stable state.Increasing the throat area can make the shock position move backward and away from the pressure measuring point under the same inlet condition，which is conducive to improving the stability of the decompression ratio.Increasing the angle of the back end can make the shock position move forward，which is not conducive to the stability of the decompression ratio.
-
[1] 吴琪华，贺慧珠，张加桢.航空发动机调节[M].北京：空军工程大学工程学院，2002. [2] 李海，祁磊，薛锋.某型发动机喷口收放故障分析与排除[J].航空维修与工程，2014（4）:78-80. [3] 谢寿生.АЛ-31Ф加力涡扇发动机[M].陕西：空军工程大学工程学院，2002. [4] 周宗才，郑铁军.АЛ-31Ф发动机结构特性控制[M].陕西：中国人民解放军空军装备部外场部，2013. [5] 陈晓涛，骆润，南斌斌.浅析某型发动机喷口加力调节器故障原因[J].航空维修与工程，2017（4）:86-87. [6] 航空发动机设计手册总编委会.航空发动机设计手册[M].北京：航空工业出版社，2001. [7] 航空发动机设计手册总编委会.航空喷气发动机自动控制设计手册[M].北京：国防工业出版社，1982. [8] 潘锦珊，单鹏.气体动力学基础[M].北京：国防工业出版社,2012. [9] CENGEL Y A，BOLES M A.Thermodynamics:an engineering approach，5th ed[M].New York:McGraw-Hill College，2006. [10] CENGEL Y A.Heat transfer:a practical approach， 2nd ed [M].New York:McGraw-Hill College,2002.[11] CENGEL Y A.Fluid mechanics fundamentals and applications[M]. 2nd ed .New York:McGraw-Hill College,2010.[12] 王新月.气体动力学基础[M].西安：西北工业大学出版社,2006. [13] 王新月，杨青青.热力学与气体动力学基础[M].西安：西北工业大学出版社,2004. [14] 邢宗文.流体力学基础[M].西安：西北工业大学出版社,1990. [15] Anderson J D,Jr.Modern compressible flow[M].New York:McGraw-Hill Book Company,1982. -
