Status and prospect of Hall thruster of different thrust stages
-
摘要:
介绍了霍尔推力器原理的基础上,推导分析了霍尔推力器推力的影响因素,总结了改变其推力的主要方法。概述了微牛级、毫牛级和牛级等不同推力级适用的航天任务类型,按照3个级别对国内外霍尔推力器型号进行了分类,分别对3个推力级各系列型号的发展及趋势进行了梳理与分析。对各推力级霍尔推力器发展的关键技术进行了展望。针对其中的技术瓶颈与发展趋势进行了总结分析。全面、系统地针对各推力级霍尔推力器进行了综述。结果表明:毫牛级发展最为成熟的推力级,而随着航天任务类型逐渐丰富,微牛级和牛级霍尔推力器发展潜力愈发突出;研究结果提出了霍尔推进器应提升整体性能、扩展推力覆盖范围,强化多模式工作能力,发展空心阴极以及探究不同推进剂等建议。该研究结果对于霍尔电推进的进一步发展具有参考价值。
Abstract:Based on the introduction of the principle of Hall thruster, the influencing factors of Hall thruster thrust were deduced and analyzed, summarizing how to change Hall thruster thrust. The types of space missions applicable to different thrust levels, such as μN-level level, mN-level and N-level were summarized. The models of Hall thrusters at home and abroad were classified according to three levels, and the development and trend of each series of models of the three thrust levels were sorted out and analyzed respectively. The technical bottleneck and development trend were summarized and analyzed. Hall thrusters of various thrust stages were comprehensively and systematically reviewed. The results indicated that the mN-level was the most mature. With more abundant types of space missions, the μN-level level and N-level Hall thrusters had considerable development potential. The key technologies for the development of Hall Thrusters in each thrust stage were prospected. The results suggested that Hall Thrusters should improve the overall performance, expand the thrust coverage, strengthen the multi-mode working ability, develop hollow cathode and explore different propellants, thus providing a reference for the further development of Hall electric propulsion.
-
Key words:
- Hall electric propulsion technology /
- Hall thruster /
- thrust stage /
- thrust /
- space thruster
-
表 1 3种不同推力水平的电推力器特征及应用
Table 1. Characteristics and application of three kinds of electric thrusters with different thrust levels
推力量级 应用场景 寿命要求/年 工作特征 微牛级 姿态控制
飞轮卸载
空间引力波探测15~20 数十瓦功率
精确最小冲量为2×10−5 N·s毫牛级 南北位置保持
东西位置保持
深空探测
轨道修正
气动补偿
矢量定位20 数十瓦至数千瓦功率
对南北位置保持,最小冲量为2×10−3 N·s
100 kg航天器质量每年能够产生46000 N·s的总冲量牛级 轨道提升
星际旅行
太阳系考察3 数千瓦以上功率
间断或连续工作表 2 毫牛级SPT系列霍尔推力器性能参数[3]
Table 2. Performance parameters of milli-Newton SPT series Hall thruster[3]
参数 SPT-50/60 SPT-70 SPT-100 SPT-140 SPT-200 加速通道外径/mm 50~60 70 100 140 200 推力/mN 10~500 20~100 40~200 80~400 150~600 比冲/s 1570 1600 1810 1950 喷气速度/(km/s) 12 16 20 25 30 额定功率/W 0.7 1.5 3.0 6.0 12.0 效率/% 40 50 50 60 60~70 发展状态 工程产品 工程产品 工程产品 工程产品 试验样机 表 3 BHT系列霍尔推力器性能参数
Table 3. Performance parameters of BHT series Hall thruster
参数 BHT-100 BHT-200 BHT-350 BHT-600 BHT-1500 BHT-6000 输入功率/W 100 200 300 600 1500 6000 推力/mN 7 13 17 39 101 201-325 比冲/s 1000 1390 1244 1500 1710 1 900~2100 总冲量/(kN·s) >250 >140 >250 >1000 >6500 >8500 适用工质 Xe或I Xe或I Xe或Kr或I Xe或Kr或I Xe或Kr或I Xe或Kr或I -
[1] 康小录,张岩. 空间电推进技术应用现状与发展趋势[J]. 上海航天,2019,36(6): 24-34. KANG Xiaolu,ZHANG Yan. Application status and development trend of space electric propulsion technology[J]. Aerospace Shanghai,2019,36(6): 24-34. (in Chinese [2] 康小录,杭观荣,朱智春. 霍尔电推进技术的发展与应用[J]. 火箭推进,2017,43(1): 8-17. KANG Xiaolu,HANG Guanrong,ZHU Zhichun. Development and application of Hall electric propulsion technology[J]. Journal of Rocket Propulsion,2017,43(1): 8-17. (in Chinese [3] 于达仁. 空间电推进原理[M]. 哈尔滨: 哈尔滨工业大学出版社, 2014. [4] 张雪儿,李得天,张天平. 电推进三种比冲的定义及其工程应用[J]. 真空与低温,2020,26(6): 486-493. ZHANG Xueer,LI Detian,ZHANG Tianping. Three types of specific impulses for electric propulsions: their definitions and engineering applications[J]. Vacuum and Cryogenics,2020,26(6): 486-493. (in Chinese [5] HOFER R, JANKOVSKY R. A hall thruster performance model incorporating the effects of a multiply-charged plasma[R]. Salt Lake City, US: the 37th Joint Propulsion Conference and Exhibit, 2001. [6] GOEBEL D M, KATZ I. Fundamentals of electric propulsion: ion and hall thrusters[M]. Hoboken, US: John Wiley and Sons Incorporation, 2008. [7] 陈杰, 康小录, 赵震, 等. 高比冲霍尔推力器研究现状[R]. 南京: 中国航天第三专业信息网第40届技术交流会暨第4届空天动力联合会议, 2019. [8] HOFER R R,JOHNSON L K,GOEBEL D M,et al. Effects of internally mounted cathodes on Hall thruster plume properties[J]. IEEE Transactions on Plasma Science,2008,36(5): 2004-2014. doi: 10.1109/TPS.2008.2000962 [9] CONVERSANO R W,LOBBIA R B,KERBER T V,et al. Performance characterization of a low-power magnetically shielded Hall thruster with an internally-mounted hollow cathode[J]. Plasma Sources Science and Technology,2019,28(10): 105011.1-105011.14. [10] SOMMERVILLE J, KING L. Effect of cathode position on Hall-effect thruster performance and cathode coupling voltage[R] Cincinnati, US: the 43rd AIAA/ASME/SAE/ASEE Joint Propulsion Conference and Exhibit, 2007. [11] PATTERSON M J, THOMAS R, CROFTON M W, et al. High thrust-to-power annular engine technology[R] Orlando, US: the 51st AIAA/SAE/ASEE Joint Propulsion Conference, 2015. [12] ITO T,GASCON N,CRAWFORD W S,et al. Experimental characterization of a micro-Hall thruster[J]. Journal of Propulsion and Power,2007,23(5): 1068-1074. doi: 10.2514/1.27140 [13] 于达仁,牛翔,王泰卜,等. 面向空间引力波探测任务的微推进技术研究进展[J]. 中山大学学报 (自然科学版),2021,60(1/2): 194-212. YU Daren,NIU Xiang,WANG Taibu,et al. The developments of micro propulsion technology based on space gravitational wave detection task[J]. Acta Scientiarum Naturalium Universitatis Sunyatseni,2021,60(1/2): 194-212. (in Chinese [14] HEY F G. Micro Newton thruster development: direct thrust measurements and thruster downscaling[M]. Berlin, German: Springer, 2018. [15] IKEDA T, TOGAWA K, TAHARA H, et al. Performance characteristics of very low power cylindrical Hall thrusters for the Nano-satellite “PROITERES-3” [R]. Hakone, Japan: the 8th International Symposium on Applied Plasma Science (ISAPS), 2011. [16] ZAKIROV V,PAVSHOOK V. Feasibility of the recent Russian nuclear electric propulsion concept: 2010[J]. Nuclear Engineering and Design,2011,241(5): 1529-1537. doi: 10.1016/j.nucengdes.2011.02.010 [17] GORBUNOV A V, KHODNENKO V P, KHROMOV A V, et al. Vernier propulsion system for small earth remote sensing satellite “Canopus-V”[R]. Wiesbaden, Germany: the 32nd International Electric Propulsion Conference, 2011. [18] BOBER A, KOZULOSKY K, KOMARROW G, et al. Development and qualification test of a SPT electric propulsion system for “Gals” spacecraft[R]. Seattle, US: the 23rd International Electric Propulsion Conference, 1993. [19] MITROFANOVA O A, GNIZDOR R Y, MURASHKO V M, et al. New generation of SPT-100[R] Wiesbaden, Germany: the 32nd International Electric Propulsion Conference, 2011. [20] COREY R L, PIDGEON D J. Electric propulsion at space systems/Loral[R]. International Electric Propulsion Conference, IEPC-2009-270, 2009. [21] SNYDER J S, HOFER R R. Throttled performance of the SPT-140 Hall thruster[R] Cleveland, US: the 50th AIAA/ASME/SAE/ASEE Joint Propulsion Conference, 2014. [22] JAMESON-SILVA K, DELGADO J J, LIANG R, et al. Adaptability of the SSL electric propulsion-140 subsystem for use on a NASA discovery class missions: psyche[R]. Atlanta, US: the 35th International Electric Propulsion Conference, 2017. [23] DELGADO J J. QUALIFICATION of the SPT-140 for use on Western Spacecraft[R]. Cleveland, US: the 50th AIAA/ASME/SAE/ASEE Joint Propulsion Conference, 2014. [24] MURASHKO V, KORYAKIN A, NYATIN A, et al. State of the art and prospects of electric propulsion in Russia[R]. International Electric Propulsion Conference, IEPC-2003-340, 2003. [25] GORSHKOV O A,BELIKOV M B,MURAVLEV V A,et al. The GEOSAT electrical propulsion subsystem based on the KM-45 HET[J]. Acta Astronautica,2008,63(1/2/3/4): 367-378. [26] VASIN A I,KOROTEEV A S,LOVTSOV A S,et al. Review of works on electric propulsion at Keldysh Research Center[J]. Trudy MAI,2012,13(60): 70-79. [27] BELIKOV M B, BLINOV N V, GORSHKOV O A, et al. Operation peculiarities of Hall thruster with power 1.5—2.0 kW at high discharge voltages[R]. Toulouse, France: the 28th International Electric Propulsion Conference, 2003. [28] LOVTSOV A S, TOMILIN D A, MURAVLEV V A. Development of high-voltage hall effect thrusters at Keldysh Research Centre[R]. Adelaide, Australia: the International Astronautical Congress, 2017 [29] GORSHKOV D O, SHAGAYDA D A, MURAVLEV M V. The experience of hall thruster research and development[R]. Valencia, Spain: the 57th International Astronautical Congress, 2006. [30] KIM V, POPOV G, ARKHIPOV B, et al. Electric propulsion activity in Russia[R]Pasadena, US: the 27 International Electric Propulsion Conference, 2001. [31] LYNN P, OSBORN M, SANKOVIC J, et al. Electric propulsion demonstration module (EPDM) flight Hall thruster system[R]. Cleveland, US: the International Electric Propulsion Conference Proceedings, 1997. [32] OSBORN M F, LYNN P, SUTTON R. RHETT/EPDM flight xenon flow system development[R]. Cleveland, US: the 25th International Electric Propulsion Conference, 1997. [33] VALENTIAN D, MASLENNIKOV N. The PPS 1350 program[R]. Cleveland, US: the 25th International Electric Propulsion Conference, 1997. [34] GARNERO P. ASTRA 1K and STENTOR plasma propulsion subsystem experience[R]. Huntsville, US: the 39th AIAA/ASME/SAE/ASEE Joint Propulsion Conference and Exhibit, 2003. [35] KOPPEL C, LYSZYK M, VALENTIAN D, et al. PPS 1350 with variable power features for SMART 1[R]. Huntsville, US: the 6th AIAA/ASME/SAE/ASEE Joint Propulsion Conference and Exhibit, 2000. [36] DUCHEMIN O, DUMAZERT P, ESTUBLIER D, et al. Stretching the operational envelope of the PPS® X000 plasma thruster[R]. Fort Lauderdale, US: the 40th AIAA/ASME/SAE/ASEE Joint Propulsion Conference and Exhibit, 2004. [37] VIAL V, DUCHEMIN O. Optimization of the PPS® X000-technological demonstrator for high ISP operation[R]. Denver, US: the 45th AIAA/ASME/SAE/ASEE Joint Propulsion Conference and Exhibit, 2009. [38] DUCHEMIN O, DUMAZERT P, ESTUBLIER D, et al. Testing the PPS X000 plasma thruster at high discharge voltage[R]. International Spacecraft Propulsion Conference, ISPC-2004-555, 2004. [39] MONHEISER J,HRUBY V,FREEMAN C,et al. Development and testing of a low-power Hall thruster system[J]. Micropropulsion for Small Spacecraft,2000,187: 255-270. [40] SZABO J J, POTE B, TEDRAKE R, et al. High throughput 600-watt Hall effect thruster for space exploration[R]. Salt Lake City, US: the 52nd AIAA/SAE/ASEE Joint Propulsion Conference, 2016 [41] Busek Company Incorporation. Hall effect thrusters[EB/OL]. [2021-11-13]. https://www.busek.com/hall-thrusters [42] KAMHAWI H, HAAG T, BENAVIDES G, et al. Overview of iodine propellant Hall thruster development activities at NASA Glenn Research Center[R]. Salt Lake City, US: the 52nd AIAA/SAE/ASEE Joint Propulsion Conference, 2016. [43] FISHER J, WILSON A, KING D, et al. The development and qualification of a 4.5 kW Hall thruster propulsion system for GEO satellite applications[R] Pasadena, US: the 27th International Electric Propulsion Conference, 2001. [44] DE GRYS K, MATHERS A, WELANDER B, et al. Demonstration of 10, 400 hours of operation on 4.5 kw qualification model hall thruster[R]. Nashville, US: the 46th AIAA/ASME/SAE/ASEE Joint Propulsion Conference and Exhibit, 2010. [45] KING D, TILLEY D, AADLAND R, et al. Development of the BPT family of US-designed hall current thrusters for commercial LEO and GEO applications[R]. Cleveland, US: the 34th AIAA/ASME/SAE/ASEE Joint Propulsion Conference and Exhibit, 1998. [46] MATHERS A, DE GRYS K, PAISLEY J. Performance variation in BPT-4000 Hall thrusters[R]. International Electric Propulsion Conference, IEPC-2009-144, 2009. [47] 杭观荣,康小录. 美国AEHF军事通信卫星推进系统及其在首发星上的应用[J]. 火箭推进,2011,37(6): 1-8. HANG Guanrong,KANG Xiaolu. Propulsion system of USA AEHF military communication satellite and its application on AEHF-1 satellite[J]. Journal of Rocket Propulsion,2011,37(6): 1-8. (in Chinese [48] WELANDER B, MONHEISER J, MECKEL N, et al. Demonstration of the XR-12 Hall Current Thruster[R]. Washington D C: the 33rd International Electric Propulsion Conference, 2013. [49] HOFER R R,JANKOVSKY R S,GALLIMORE A D. High-specific impulse Hall thrusters: Part 1 influence of current density and magnetic field[J]. Journal of Propulsion and Power,2006,22(4): 721-731. doi: 10.2514/1.15952 [50] PETERSON P, KAMHAWI H, MANZELLA D, et al. Hall thruster technology for NASA science missions: HiVHAC status update[R]. Cincinnati, US: the 43rd AIAA/ASME/SAE/ASEE Joint Propulsion Conference and Exhibit, 2007. [51] MISURI T, DUCCI C, GREGUCCI S, et al. SITAEL HT100 thruster unit, full ground qualification[C]//Proceedings of the 36th International Electric Propulsion Conference. Vienna, Austria: University of Vienna Press, 2019: 15-20. [52] RAFAEL I. VEN μS–A novel technological mission using electric propulsion[R]. Atlanta, US: the 35th International Electric Propulsion Conference, 2017. [53] KIM E H,KIM Y H,PARK J S,et al. Orbit evolution analysis of DubaiSat-2 using hall-effect thruster[J]. Journal of the Korean Society for Aeronautical and Space Sciences,2015,43(4): 377-386. [54] PIRAGINO A, LEPORINI A, GIANNETTI V, et al. Characterization of a 20 kW-class hall effect thruster[R]. Atlanta, US: the 35th International Electric Propulsion Conference, 2017. [55] SOULAS G, HAAG T, HERMAN D, et al. Performance test results of the NASA-457M v2 Hall thruster[R]. Atlanta, US: the 48th AIAA/ASME/SAE/ASEE Joint Propulsion Conference and Exhibit, 2012. [56] PETERSON P, JACOBSON D, MANZELLA D, et al. The performance and wear characterization of a high-power high-ISP NASA Hall thruster[R]. Tucson, US: the 41st AIAA/ASME/SAE/ASEE Joint Propulsion Conference and Exhibit, 2005. [57] KAMHAWI H, HAAG T, JACOBSON D, et al. Performance evaluation of the NASA-300M 20 kW Hall thruster[R]. San Diego, US: the 47th AIAA/ASME/SAE/ASEE Joint Propulsion Conference and Exhibit, 2011. [58] HALL S J, JORNS B J, GALLIMORE A D, et al. High-power performance of a 100-kW class nested Hall thruster[R]. International Electric Propulsion Conference, IEPC-2017-228, 2017. [59] ZURBACH S, CORNU N, LASGORCEIX P. Performance evaluation of a 20 kW hall effect thruster[R]. International Electric Propulsion Conference, IEPC-2011-33, 2011. [60] 于达仁, 崔凯, 刘辉, 等. 用于引力波探测的微牛级霍尔电推进技术[J]. 哈尔滨工业大学学报, 2020, 52(6): 171-181.YU Daren, CUI Kai, LIU Hui, et al. Micro-newton hall electric propulsion technology for gravitational wave detection[J]. Journal of Harbin Institute of Technology, 2020, 52(6): 171-181. (in Chinese) [61] YANLIN H U,DAWEI H U,PENGAN W U,et al. Development of HEP-XXMF series hall thrusters in BICE[J]. Aerospace China,2019,17(2): 9-16. [62] 于达仁,乔磊,蒋文嘉,等. 中国电推进技术发展及展望[J]. 推进技术,2020,41(1): 1-11. YU Daren,QIAO Lei,JIANG Wenjia,et al. Development and prospect of electric propulsion technology in China[J]. Journal of Propulsion Technology,2020,41(1): 1-11. (in Chinese [63] 田立成,赵成仁,张天平,等. SJ-17卫星LHT-100霍尔电推进系统飞行试验工作性能评价[J]. 推进技术,2017,38(11): 2411-2421. TIAN Licheng,ZHAO Chengren,ZHANG Tianping,et al. Flight test performance evaluation of LHT-100 Hall electric propulsion system on SJ-17 satellite[J]. Journal of Propulsion Technology,2017,38(11): 2411-2421. (in Chinese [64] 张天平. 兰州空间技术物理研究所电推进新进展[J]. 火箭推进,2015,41(2): 7-12. ZHANG Tianping. New progress of electric propulsion technology in LIP[J]. Journal of Rocket Propulsion,2015,41(2): 7-12. (in Chinese [65] RAITSES Y, FISCH N J, BURLINGAME C A, et al. Parametric studies of the cylindrical hall thruster[R]. Williamsburg, US: the APS Division of Plasma Physics Meeting, 2000. [66] POLZIN K, RAITSES Y, GAYOSO J C, et al. Comparisons in performance of electromagnet and permanent-magnet cylindrical hall-effect thrusters[R]. Nashville, US: the 46th AIAA/ASME/SAE/ASEE Joint Propulsion Conference and Exhibit, 2010. [67] 康小录,张岩,刘佳,等. 大功率霍尔电推进研究现状与关键技术[J]. 推进技术,2019,40(1): 1-11. KANG Xiaolu,ZHANG Yan,LIU Jia,et al. Research status and key technologies of high-power Hall electric propulsion[J]. Journal of Propulsion Technology,2019,40(1): 1-11. (in Chinese [68] MATHERS A. Development of a high power cathode heater[R]. Hartford, US: the 44th AIAA/ASME/SAE/ASEE Joint Propulsion Conference and Exhibit, 2008. [69] 贾艳辉,张天平. 空间用六硼化镧空心阴极最新研究进展及发展趋势[J]. 真空科学与技术学报,2016,36(6): 690-698. JIA Yanhui,ZHANG Tianping. Latest development of space-borne lab6 hollow cathode[J]. Chinese Journal of Vacuum Science and Technology,2016,36(6): 690-698. (in Chinese [70] WARNER D, BRANAM R, HARGUS W, et al. Low current cerium hexaboride and lanthanum hexaboride hollow cathodes[R]. Reno, US: the 46th AIAA Aerospace Sciences Meeting and Exhibit, 2008. [71] GRUBISIC A, GABRIEL S. Preliminary thrust characterization of a T5 hollow cathode[R]. Cincinnati, US: the 43rd AIAA/ASME/SAE/ASEE Joint Propulsion Conference and Exhibit, 2007. [72] PEDRINI D, TORRINI F, GRASSI J, et al. Development of hollow cathodes for 5 to 20 kW Hall thrusters[R]. Atlanta, US: the 35th International Electric Propulsion Conference, 2017. [73] SENGUPTA A,ANDERSON J A,GARNER C,et al. Deep space 1 flight spare ion thruster 30 000-hour life test[J]. Journal of Propulsion and Power,2009,25(1): 105-117. doi: 10.2514/1.36549 [74] 郭宁,唐福俊,李文峰. 空间用空心阴极研究进展[J]. 推进技术,2012,33(1): 155-160. GUO Ning,TANG Fujun,LI Wenfeng. Advances in spaceborne hollow cathode[J]. Journal of Propulsion Technology,2012,33(1): 155-160. (in Chinese [75] 扈延林,毛威,李栋,等. 面向全电推进卫星的霍尔推进技术[J]. 空间控制技术与应用,2017,43(1): 73-78. HU Yanlin,MAO Wei,LI Dong,et al. The Hall propulsion technology oriented all-electric-propulsion satellites[J]. Journal of Propulsion Technology,2017,43(1): 73-78. (in Chinese [76] LINNELL J A. An evaluation of krypton propellant in hall thrusters[D]. Ann Arbor, Michigan: University of Michigan, 2007. [77] 张乾鹏,康小录. 用Xe 和Kr 作为霍尔电推进工质的比较[J]. 推进技术,2011,32(6): 828-834. ZHANG Qianpeng,KANG Xiaolu. Comparison for the hall thruster using Xe and Kr propellent[J]. Journal of Propulsion Technology,2011,32(6): 828-834. (in Chinese [78] SZELECKA A,KURZYNA J,BOURDAIN L. Thermal stability of the krypton Hall effect thruster[J]. Nukleonika,2017,62(1): 9-15. doi: 10.1515/nuka-2017-0002 [79] 刘辉,牛翔,李鑫,等. 碘工质电推进技术研究综述[J]. 推进技术,2019,40(1): 12-25. LIU Hui,NIU Xiang,LI Xin,et al. Reviews on electrical propulsion technology using iodinealternatives[J]. Journal of Propulsion Technology,2019,40(1): 12-25. (in Chinese [80] MASON L, JANKOVSKY R, MANZELLA D. 1000 hours of testing on a 10 kilowatt Hall effect thruster[R]. Salt Lake City, US: the 37th Joint Propulsion Conference and Exhibit, 2001.
