基于深度学习光流法的荧光油膜全局速度测量

王超 董秀成 古世甫 张征宇 钱泓江

王超,董秀成,古世甫,等.基于深度学习光流法的荧光油膜全局速度测量[J].航空动力学报,2022,37(7):1539‑1549. doi: 10.13224/j.cnki.jasp.20220049
引用本文: 王超,董秀成,古世甫,等.基于深度学习光流法的荧光油膜全局速度测量[J].航空动力学报,2022,37(7):1539‑1549. doi: 10.13224/j.cnki.jasp.20220049
WANG Chao,DONG Xiucheng,GU Shifu,et al.Global velocity measurement of fluorescent oil film based on deep learning optical flow method[J].Journal of Aerospace Power,2022,37(7):1539‑1549. doi: 10.13224/j.cnki.jasp.20220049
Citation: WANG Chao,DONG Xiucheng,GU Shifu,et al.Global velocity measurement of fluorescent oil film based on deep learning optical flow method[J].Journal of Aerospace Power,2022,37(7):1539‑1549. doi: 10.13224/j.cnki.jasp.20220049

基于深度学习光流法的荧光油膜全局速度测量

doi: 10.13224/j.cnki.jasp.20220049
基金项目:

国家自然科学基金 11872069

四川省中央引导地方科技发展专项 2021ZYD0034

详细信息
    作者简介:

    王超(1998-),男,硕士生,主要从事空气动力学、计算机视觉研究。

    通讯作者:

    董秀成(1963-),男,教授,硕士,主要从事机器视觉研究。E⁃mail:dxc136@163.com

  • 中图分类号: V19

Global velocity measurement of fluorescent oil film based on deep learning optical flow method

  • 摘要:

    针对基于先验的传统光流法存在前提条件苛刻的问题,提出使用基于深度学习的光流法进行荧光油膜全局速度测量。采用数值仿真试验对基于先验的改进HS光流法和基于深度学习的FlowNet2光流法进行对比,结果显示:在不外加干扰时,改进HS光流法和FlowNet2光流法的平均端点误差分别为0.458 7像素/s和0.381 7像素/s;在亮度变化、噪声干扰或不同的演化时间下,FlowNet2光流法的平均端点误差均明显低于改进HS光流法,平均端点误差差值最大可达5.19像素/s;风洞试验进一步证明,FlowNet2光流法能够获得正确、清晰、定量的荧光油膜全局速度场,较改进HS光流法鲁棒性更高,对风洞工程应用具有一定的参考价值。



  • 图 1  三层金字塔优化示意图

    Figure 1.  Schematic diagram of three⁃layer pyramid optimization

    图 2  FlowNet原理示意图

    Figure 2.  Schematic diagram of FlowNet priciple

    图 3  FlowNet2网络结构图

    Figure 3.  Network architecture diagram of FlowNet2

    图 4  荧光油膜模拟图像

    Figure 4.  Simulation images of fluorescent oil film

    图 5  不同亮度变化下的平均端点误差曲线

    Figure 5.  Average endpoint error curve with different brightness changes

    图 9  不同演化时间下的平均端点误差曲线

    Figure 9.  Average endpoint error curve with different evolution times

    图 10  试验平台

    Figure 10.  Experimental platform

    图 11  亮度变化下的流线图

    Figure 11.  Streamlines with brightness variation

    图 12  噪声下的流线图

    Figure 12.  Streamlines with noise

    图 13  大位移下的流线图

    Figure 13.  Streamlines with large displacement

    图 14  荧光油膜展翼图像

    Figure 14.  Fluorescent oil film images of airfoil

    表  1  两种数据集特征

    Table  1.   Features of two datasets

    特征数据集名称
    ChairsThings3D
    训练集帧数22 23221 818
    测试集帧数6404 248
    场景数9642 247
    下载: 导出CSV

    表  2  不同亮度变化下的平均端点误差

    Table  2.   Average endpoint error with different brightness changes

    亮度变化/%平均端点误差/(像素/s)
    改进HS光流法FlowNet2光流法
    -10-8-6-4-20+2+4+6+8+100.557 00.555 90.557 40.556 30.559 40.458 70.579 30.620 90.670 90.752 80.840 00.495 60.477 50.459 50.452 70.447 90.381 70.450 30.452 30.458 40.461 90.464 0
    下载: 导出CSV

    表  3  不同噪声下的平均端点误差

    Table  3.   Average endpoint error with different noises

    噪声类型平均端点误差(像素/s)
    改进HS光流法FlowNet2光流法
    无噪声0.458 70.381 7
    高斯噪声0.775 40.457 9
    椒盐噪声0.859 80.460 4
    混合噪声0.855 50.456 6
    下载: 导出CSV

    表  4  不同演化时间下的平均端点误差

    Table  4.   Average endpoint error with different evolution times

    演化时间/s平均端点误差/(像素/s)
    改进HS光流法FlowNet2光流法
    0.020.040.060.080.100.120.140.160.180.200.458 60.564 40.718 61.426 12.495 63.709 54.882 76.091 17.419 08.632 70.381 70.436 00.527 70.650 50.858 41.203 31.674 12.197 92.760 33.442 7
    下载: 导出CSV
  • [1] 邢宇,罗东明,余雄庆.超临界层流翼型优化设计策略[J].北京航空航天大学学报,2017,43(8):1616⁃1624.

    XING Yu,LUO Dongming,YU Xiongqing.Optimization strategy of supercritical laminar flow airfoil design[J].Journal of Beijing University of Aeronautics and Astronautics,2017,43(8):1616⁃1624.(in Chinese)
    [2] 朱自强,吴宗成,丁举春.层流流动控制技术及应用[J].航空学报,2011,32(5):765⁃784.

    ZHU Ziqiang,WU Zongcheng,DING Juchun.Laminar flow control technology and application[J].Acta Aeronautica et Astronautica Sinica,2011,32(5):765⁃784.(in Chinese)
    [3] 王帅,何国强,秦飞,等.超声速内流道摩擦阻力分析及减阻技术研究[J].航空动力学报,2019,34(4):908⁃919.

    WANG Shuai,HE Guoqiang,QIN Fei,et al.Research on skin⁃friction drag and drag reduction technics in a supersonic inner flow path[J].Journal of Aerospace Power,2019,34(4):908⁃919.(in Chinese)
    [4] 黄湛,王宏伟,魏连风,等.基于荧光油膜的全局表面摩阻测量技术研究[J].空气动力学学报,2016,34(3):373⁃378.

    HUANG Zhan,WANG Hongwei,WEI Lianfeng,et al.Research of global skin friction measurement based on fluorescent oil film[J].Acta Aerodynamica Sinica,2016,34(3):373⁃378.(in Chinese)
    [5] NAUGHTON J W,SHEPLAK M.Modern developments in shear⁃stress measurement[J].Progress in Aerospace Sciences,2002,38(6/7):515⁃570.
    [6] 林其勋,郭捷,李亚平,等.用热线风速仪研究轴流压气机的非定常流场及端壁附面层[J].航空动力学报,1989,4(2):141⁃144.

    LIN Qixun,GUO Jie,LI Yaping,et al.Investigation on unsteady flow field and endwall boundary layer in axial flow compressor with hot wire anemometer[J].Journal of Aerospace Power,1989,4(2):141⁃144.(in Chinese)
    [7] 徐大川,龙彦志,李玉栋.基于激光多普勒原理的极低风速测量实验[J].航空动力学报,2020,35(6):1228⁃1237.

    XU Dachuan,LONG Yanzhi,LI Yudong.Experiment of extremely low wind velocity measurement based on laser Doppler[J].Journal of Aerospace Power,2020,35(6):1228⁃1237.(in Chinese)
    [8] LIU T,SULLIVAN J P.Luminescent oil⁃film skin⁃friction meter[J].AIAA Journal,2015,36(8):1460⁃1465.
    [9] 钱泓江董秀成张征宇基于Hankel阵的荧光油膜灰度与厚度预测模型改进航空动力学报2021361020612071

    Improved prediction model of gray and thickness of fluorescent oil film based on Hankel matrixJournal of Aerospace Power2021361012281237(in Chinese)
    [10] QIAN H,DONG X C,ZHANG Z Y.Research on stability of gray value of excited⁃state fluorescent oil film based on variable light vector angle[J].Mathematical Problems in Engineering,2021:8632992.1⁃8632992.12.
    [11] 钱泓江,董秀成,徐椰烃,等.基于神经网络的荧光油膜厚度与灰度研究[J].南京航空航天大学学报,2021,53(3):470⁃476.

    QIAN Hongjiang,DONG Xiucheng,XU Yeting,et al.Fluorescence oil film thickness and gray level identification based on neural network[J].Journal of Nanjing University of Aeronautics and Astronautics,2021,53(3):470⁃476.(in Chinese)
    [12] ZHAI M,XIANG X,LV N,et al.Optical flow and scene flow estimation:a survey[J].Pattern Recognition,2021,114(3):107861.1⁃107861.15.
    [13] TU Z,XIE W,ZHANG D,et al.A survey of variational and CNN⁃based optical flow techniques[J].Signal Processing Image Communication,2019,72:9⁃24.
    [14] HORN B,SCHUNCK B G.Determining optical flow[J].Artificial Intelligence,1981,17(1):185⁃203.
    [15] SUN D,ROTH S,Black M J.Secrets of optical flow estimation and their principles[C]∥Proceeding of IEEE Conference on Computer Vision and Pattern Recognition.San Francisco,US:IEEE,2010:2432⁃2439.
    [16] 邵绪强,杨艳,刘艺林.流体运动估计光流算法研究综述[J].中国图象图形学报,2021,26(2):355⁃367.

    SHAO Xuqiang,YANG Yan,LIU Yilin.Review of optical flow algorithm in fluid motion estimation[J].Journal of Image and Graphic,2021,26(2):355⁃367.(in Chinese)
    [17] FISCHER P,DOSOVITSKIY A,ILG E,et al.FlowNet:learning optical flow with convolutional networks[C]∥Proceeding of IEEE International Conference on Computer Vision.Santiago,Chile:IEEE,2015:2758⁃2766.
    [18] ILG E,MAYER N,SAIKIA T,et al.FlowNet 2.0:evolution of optical flow estimation with deep networks[C]∥Proceeding of 2017 IEEE Conference on Computer Vision and Pattern Recognition.Honolulu,US:IEEE,2017:1647⁃1655.
    [19] HEITZ D,MÉMIN E,SCHNÖRR C.Variational fluid flow measurements from image sequences:synopsis and perspectives[J].Experiments in Fluids,2010,48(3):369⁃393.
    [20] BROX T,BRUHN A,PAPENBERG N,et al.High accuracy optical flow estimation based on a theory for warping[C]∥Proceeding of European Conference on Computer Vision.Berlin,German:Springer,2004:25⁃36.
    [21] 李鹏.全局表面摩擦应力直接测量技术研究[D].南京:南京航空航天大学,2012.

    LI Peng.Studies of direct measurement techniques about global skin friction[D].Nanjing:Nanjing University of Aeronautics and Astronautics,2012.(in Chinese)
    [22] 邹易峰,张征宇,王学渊,等.风洞试验模型表面的荧光油膜路径运动速度测量[J].航空学报,2019,40(6):92⁃105.

    ZOU Yifeng,ZHANG Zhengyu,WANG Xueyuan,et al.Velocity measurement of fluorescent oil film path movement on wind tunnel testing model surface[J].Acta Aeronautica et Astronautica Sinica,2019,40(6):92⁃105.(in Chinese)
    [23] WANG Bo,CAI Zemin,SHEN Lixin,et al.An analysis of physics⁃based optical flow[J].Journal of Computational and Applied Mathematics,2015,276:62⁃80.
    [24] 陈吉明,吕金磊,廖达雄,等.连续式跨声速风洞试验段降噪技术[J].航空动力学报,2021,36(8):1712⁃1719.

    CHEN Jiming,Jinlei LÜ,LIAO Daxiong,et al.Noise reduction technology in test section of continuous transonic wind tunnel[J].Journal of Aerospace Power,2021,36(8):1712⁃1719.(in Chinese)
    [25] HU Y,RUI S,LI Y.Efficient coarse⁃to⁃fine patch match for large displacement optical flow[C]∥Proceeding of IEEE Conference on Computer Vision and Pattern Recognition.Las Vegas,US:IEEE,2016:5704⁃5712.
    [26] WEINZAEPFEL P,REVAUD J,HARCHAOUI Z,et al.DeepFlow:large displacement optical flow with deep matching[C]∥Proceeding of IEEE International Conference on Computer Vision.Sydney,Australia:IEEE,2013:2523⁃2541.
    [27] COSTANTINI M,LEE T,NONOMURA T,et al.Feasibility of skin⁃friction field measurements in a transonic wind tunnel using a global luminescent oil film[J].Experiments in Fluids,2021,62(1):1⁃34.
