考虑几何偏心的斜齿轮耦合转子系统振动响应分析

马辉 王奇斌 黄婧 张义民

马辉, 王奇斌, 黄婧, 张义民. 考虑几何偏心的斜齿轮耦合转子系统振动响应分析[J]. 航空动力学报, 2013, 28(1): 16-24.
引用本文: 马辉, 王奇斌, 黄婧, 张义民. 考虑几何偏心的斜齿轮耦合转子系统振动响应分析[J]. 航空动力学报, 2013, 28(1): 16-24.
MA Hui, WANG Qi-bin, HUANG Jing, ZHANG Yi-min. Vibration response analysis of gear coupled rotor system considering geometric eccentric effect of helical gears[J]. Journal of Aerospace Power, 2013, 28(1): 16-24.
Citation: MA Hui, WANG Qi-bin, HUANG Jing, ZHANG Yi-min. Vibration response analysis of gear coupled rotor system considering geometric eccentric effect of helical gears[J]. Journal of Aerospace Power, 2013, 28(1): 16-24.

考虑几何偏心的斜齿轮耦合转子系统振动响应分析

基金项目: 机械传动国家重点实验室开放基金(SKLMT-KFKT-200903); 国家自然科学基金(51105065); 中央高校基本科研业务费专项资金(N100403008)

Vibration response analysis of gear coupled rotor system considering geometric eccentric effect of helical gears

  • 摘要: 以一个2对斜齿轮耦合的三平行轴转子系统为研究对象,考虑静态传递误差、齿轮几何偏心等因素的影响,建立了全自由度通用齿轮啮合动力学模型,并将其与转子系统有限元模型进行耦合,建立了平行轴系齿轮转子系统的有限元模型,其中转子系统采用梁单元来模拟,齿轮之间的啮合通过啮合刚度矩阵和阻尼矩阵来模拟,最后分析了静态传递误差、转子质量不平衡、齿轮几何偏心以及三者耦合对系统动力学特性的影响.研究结果表明:齿轮几何偏心对啮合力有很大影响,其作用相当于一个扭矩作用于齿轮.



  • [1] 李润方,王建军.齿轮系统动力学:振动、冲击、噪声[M].北京:科学出版社,1997:1-3.
    [2] 庞辉,方宗德,欧卫林.多平行齿轮耦合转子系统的振动特性分析[J].振动与冲击,2007,26(6):21-25. PANG Hui,FANG Zongde,OU Weilin.Analysis on lateral torsional coupling vibration characteristics of multi-parallel gear-rotor system[J].Journal of Vibration and Shock,2007,26(6):21-25.(in Chinese)
    [3] 张建云,丘大谋.齿轮刚度及制造误差对多平行轴转子系统动力学特性的影响[J].机械科学与技术,1996,15(5):749-753. ZHANG Jianyun,QIU Damou.Effects of gear stiffness and manufacturing errors on the dynamical characteristics of parallel multi-stage gear-bearing-rotor system[J].Mechanical Science and Technology,1996,15(5):749-753.(in Chinese)
    [4] 夏伯乾,虞烈,谢友柏.DH型压缩机齿轮-轴承-转子系统动力学分析[J].振动工程学报,2003,16(2):251-255. XIA Boqian,YU Lie,XIE Youbai.Dynamics analysis of geared rotor-bearing system of DH type turbine compressor[J].Journal of Vibration Engineering,2003,16(2):251-255.(in Chinese)
    [5] 李明,胡海岩.完整约束下齿轮啮合转子系统的弯扭耦合振动稳态响应[J].振动工程学报,2003,16(1):75-80. LI Ming,HU Haiyan.Steady state response of the coupled lateral-torsional vibrations of geared rotor system under a holonomic constraint[J].Journal of Vibration Engineering,2003,16(1):75-80.(in Chinese)
    [6] 欧卫林,王三民,袁茹.齿轮耦合复杂转子系统弯扭耦合振动分析的轴单元法[J].航空动力学报,2005,20(3):434-439. OU Weilin,WANG Sanmin,YUAN Ru.Shaft element method for the analysis of lateral-torsional coupling vibration of a complex gear-rotor system[J].Journal of Aerospace Power,2005,20(3):434-439.(in Chinese)
    [7] 林江,楼建勇.斜齿轮圆柱齿轮传动系统动力学模型及动特性试验研究[J].机械工程学报,2003,39(7):29-33. LIN Jiang,LOU Jiangyong.Study on dynamic models and behavior of power transmission helical gear[J].Chinese Journal of Mechanical Engineering,2003,39(7):29-33.(in Chinese)
    [8] 窦唯,张楠,刘占生.高速齿轮转子系统弯扭耦合振动研究[J].振动工程学报,2011,24(4):386-393. DOU Wei,ZHANG Nan,LIU Zhansheng.The coupled bending and torsional vibrations of the high-speed geared rotor-bearing system[J].Journal of Vibration Engineering,2011,24(4):385-393.(in Chinese)
    [9] Lee A S,Ha J W,Choi D H.A coupled lateral and torsional vibration characteristics of a speed increasing geared rotor-bearing system[J].Journal of Sound and Vibration,2003,263(4):725-742.
    [10] Kahraman A,Ozguven H N,Houser D R,et al.Dynamic analysis of geared rotors by finite elements[J].ASME Journal of Mechanical Design,1992,114(3):507-514.
    [11] Rao J S,Shiau T N,Chang J R.Theoretical analysis of lateral response due to torsional excitation of geared rotors[J].Mechanism and Machine Theory,1998,33(6):761-783.
    [12] 蒋庆磊,吴大转,谭善光,等.齿轮传动多转子耦合系统振动特性研究[J].振动工程学报,2010,23(3):254-259. JIANG Qinglei,WU Dazhuan,TAN Shanguang,et al.Development and application of a model for coupling geared rotors system[J].Journal of Vibration Engineering,2010,23(3):254-259.(in Chinese)
    [13] 宋雪萍,刘树英,闻邦椿.齿轮-转子系统的振动特性分析[J].机械科学与技术,2006,25(2):153-157. SONG Xueping,LIU Shuying,WEN Bangchun.Vibration characteristics analysis of a gear rotor system[J].Mechanical Science and Technology,2006,25(2):153-157.(in Chinese)
    [14] 刘辉,项昌乐,孙恬恬.车辆动力传动系统弯扭耦合振动模型的建立及复模态分析[J].机械工程学报,2010,46(24):67-74. LIU Hui,XIANG Changle,SUN Tiantian. Construction of bending-torsional coupled vibration model and complex modal analysis of the vehicle powertrain[J]. Chinese Journal of Mechanical Engineering,2010,46(24):67-74.(in Chinese)
    [15] Kubur M,Kahraman A,Zini D M,et al.Dynamic analysis of a multi-shaft helical gear transmission by finite elements:model and experiment[J].ASME Journal of Vibration and Acoustics,2004,126(3):398-406.
    [16] 陈宏,王丽雅,郝伟,等.三轴斜齿轮传动转子系统的动力学特性分析[J].矿山机械,2010,38(2):29-33. CHEN Hong,WANG Liya,HAO Wei,et al.Dynamic analysis of a three-shaft helical gear transmission rotor system[J].Mining & Processing Equipment,2010,38(2):29-33.(in Chinese)
    [17] 邵忍平,沈允文,刘更,等.齿轮旋翼传动系统动态固有特性识别[J].航空动力学报,1997,12(2):206-209. SHAO Renping,SHEN Yunwen,LIU Geng,et al.Identification of gear transmission system with a rotor on dynamic natural characteristic[J].Journal of Aerospace Power,1997,12(2):206-209.(in Chinese)
    [18] 魏永祥,陈建军,王敏娟.随机参数齿轮-转子系统的扭转振动分析[J].航空动力学报,2010,25(11):2637-2642. WEI Yongxiang,CHEN Jianjun,WANG Minjuan.Dynamic response of torsional vibration of gear-rotor with random parameters[J].Journal of Aerospace Power,2010,25(11):2637-2642.(in Chinese)
    [19] 刘占生,崔亚辉,叶建槐,等.非线性油膜力和啮合力作用下齿轮系统的振动特性研究[J].中国电机工程学报,2009,29(23):84-91. LIU Zhansheng,CUI Yahui,YE Jianhuai,et al.Reseach on vibration characteristics of gear system with nonlinear oil film force and mesh force[J].Proceedings of the CSEE,2009,29(23):84-91.(in Chinese)
    [20] 崔亚辉,刘占生,叶建槐,等.复杂多级齿轮-转子-轴承系统的动力学建模和数值仿真[J].机械传动,2009,33(6):44-48. CUI Yahui,LIU Zhansheng,YE Jianhuai,et al.Dynamic model and numerical simulation of multi-stage gear-rotor- bearing system[J].Mechanical Power Transmission,2009,33(6):44-49.(in Chinese)
    [21] 朱增宝,朱如鹏,鲍和云,等.偏心与齿频误差对封闭差动人字齿轮传动系统动态均载特性的影响分析[J].航空动力学报,2011,26(11):2601-2609. ZHU Zengbao,ZHU Rupeng,BAO Heyun,et al.Impact of run-out and meshing-frequency errors on dynamic load sharing for encased differential herringbone train[J].Journal of Aerospace Power,2011,26(11):2601-2609.(in Chinese)
    [22] American Petroleum Institute.API standard 617-2002 axial and centrifugal compressors and expander-compressors for the petroleum chemical and gas industry[S].Washington:API Publishing Services, 2002:19-24.
