弹性支承下的双半内圈角接触球轴承振动分析
Vibration analysis of two-piece inner ring angular contact ball bearing with elastic support
-
摘要: 针对弹性支承下的双半内圈角接触球轴承,考虑弹性支承体与轴承外圈、轴承座之间的刚柔耦合特性,建立了弹性支承下的双半内圈角接触球轴承非线性动力学微分方程.采用精细积分法和预估-校正Adams-Bashforth-Moulton多步法相结合的算法,对非线性动力学微分方程进行求解,并对弹性体支承的双半内圈角接触球轴承振动特性进行了理论分析.分析结果表明:①通过增加支承体过渡沟槽个数可大幅度降低内圈振幅;套筒环厚度对轴承振幅影响相对较小,随着套筒环厚度的增加,内圈振幅先减小后增大;②轴向力较小时,采用过渡沟槽个数多的支承体能够降低振动幅值;轴向力较大时,适当减少过渡沟槽个数,有利于系统稳定;③存在一个最佳的过渡沟槽个数和套筒环厚度,使得轴承径向振动幅值达到最小.Abstract: Taking the bearing with elastic support as the object of study,nonlinear dynamics differential equation for the two-piece inner ring of angular contact ball bearing with elastic support,which coupled the outer ring and housing,was established.Fine integral method and predict-correct Adams-Bashforth-Moulton multi-step method were used to solve the nonlinear dynamic equations,and the vibration characteristics of two-piece inner ring of angular contact ball bearing with elastic support were analyzed and discussed.The analysis results show: (1) Magnitude of inner vibration can be significantly decreased from increasing the number of the groove joint.The thickness of the sleeve has small effect on inner vibration,and with the increase of the thickness,the amplitude value of the inner decreases first and then increases. (2) When the axial load has a small value,it is more helpful for decreasing the magnitude of bearing vibration when increasing the number of the groove joint.On the contrary,under the heavy axial load,it is beneficial for the stabilization of bearing when reducing the number of the groove joint. (3) There is a reasonable number of groove joints and thickness of sleeve for elastic support to obtain the minimum radial vibration amplitude of the bearing.
-
[1] Tiwari M,Gupta K,Prakash O.Dynamic response of an unbalanced rotor supported on ball bearings[J].Journal of Sound and Vibration,2000,238(5):757-779. [2] Harsha S P.Nonlinear dynamic analysis of rolling element bearings due to cage run-out and number of balls[J].Journal of Sound and Vibration,2006,289(1/2/3):360-381. [3] Harsha S P.Nonlinear dynamic response of a balanced rotor supported by rolling element bearings due to radial internal clearance effect[J].Mechanism and Machine Theory,2006,41(6):688-706. [4] 陈果,李成刚,王德友.航空发动机转子-滚动轴承-支承-机匣耦合系统的碰摩故障分析与验证[J].航空动力学报,2008,23(7):1304-1311. CHEN Guo,LI Chenggang,WANG Deyou.Nonlinear dynamic analysis and experiment verification of rubbing faults of rotor-ball bearing-support-stator coupling system for aero-engine[J].Journal of Aerospace Power,2008,23(7):1304-1311.(in Chinese) [5] Berman A, Flannelly W G.Theory of incomplete model of dynamic structures[J].AIAA Journal,1971,9(8):1481-1487. [6] Ecsedi I.Bounds for the torsional rigidity of elastic ring[J].Mechanics Research Communications,1999,26(4):445-450. [7] 陈果.滚动轴承支承下的不平衡转子系统非线性动力响应分析[J].中国机械工程,2007,23(18):2773-2778. CHEN Guo.Nonlinear dynamic response analysis of an unbalanced rotor supported on ball bearing[J].China Mechanical Engineering,2007,23(18):2773-2778.(in Chinese) [8] 李贵林.组合弹性支承结构的设计与试验研究[J].燃气涡轮试验与研究,2006,19(3):53-57. LI Guilin.Study on the design and experiment of combined elastic support[J].Gas Turbine Experiment and Research,2006,19(3):53-57.(in Chinese) [9] 邓四二,郝建军,滕弘飞.角接触球轴承保持架动力学分析[J].轴承,2007(10):1-5. DENG Sier,HAO Jianjun,TENG Hongfei.Dynamics analysis on cage of angular contact ball bearings[J].Bearing,2007(10):1-5.(in Chinese) [10] 陈立平,张云清,任卫群.机械系统动力学分析及ADAMS应用[M].北京:清华大学出版社,2005:259-272. [11] Harris T A,Kotzalas M N.Advanced concepts of bearing technology:rolling bearing analysis[M].5th ed.Boca Raon:CRC Press,2006. [12] Krkkinen A,Helfert M,Aeschlimann B,et al.Dynamic analysis of rotor system with misaligned retainer bearings [J].Journal of Tribology,2008,130(2):021102.1-021102.10. [13] 王燕霜,邓四二,杨伯原.润滑油五参数流变模型的研究[J].摩擦学报,2007,127(5):461-465. WANG Yanshuang,DENG Sier,YANG Boyuan.Investigation on a new five-parameter rheological model of lubricating oil[J].Journal of Tribology,2007,127(5):461-465.(in Chinese) [14] Zakhariev E.Dynamics of rigid multibody systems with clearances in the joints[J].Mechanics of Structure & Machines,1999,27(1):63-87. [15] Raje N,Sadeghi F,Rateick R G,et al.A numerical model for life scatter in rolling element bearings[J].Journal of Tribology,2008,130(1):011011.1-011011.10.
