轮盘端面齿连接的周向拉杆转子刚度研究

李浦 袁奇 高进 谈芦益 李一峰 刘华峰

李浦, 袁奇, 高进, 谈芦益, 李一峰, 刘华峰. 轮盘端面齿连接的周向拉杆转子刚度研究[J]. 航空动力学报, 2013, 28(7): 1618-1623.
引用本文: 李浦, 袁奇, 高进, 谈芦益, 李一峰, 刘华峰. 轮盘端面齿连接的周向拉杆转子刚度研究[J]. 航空动力学报, 2013, 28(7): 1618-1623.
LI Pu, YUAN Qi, GAO Jin, TAN Lu-yi, LI Yi-feng, LIU Hua-feng. Investigation on stiffness of circumferential distributed tie-rod rotor with curvic couplings of trochal disk[J]. Journal of Aerospace Power, 2013, 28(7): 1618-1623.
Citation: LI Pu, YUAN Qi, GAO Jin, TAN Lu-yi, LI Yi-feng, LIU Hua-feng. Investigation on stiffness of circumferential distributed tie-rod rotor with curvic couplings of trochal disk[J]. Journal of Aerospace Power, 2013, 28(7): 1618-1623.

轮盘端面齿连接的周向拉杆转子刚度研究

Investigation on stiffness of circumferential distributed tie-rod rotor with curvic couplings of trochal disk

  • 摘要: 针对轮盘端面齿连接的周向拉杆转子模型,理论分析得到转子各组成部分刚度计算方法.应用商业有限元软件ANSYS,基于三维有限元非线性接触算法计算预紧力下轮盘端面齿连接段的弯曲刚度和扭转刚度,得到刚度修正系数和刚度无量纲系数.分析周向拉杆刚度和轮盘刚度的关系,提出拉杆刚度比例系数.计算结果表明:刚度系数无量纲系数小于1时,刚度修正系数保持不变;刚度无量纲系数大于1时,此时预紧力不足,齿面发生滑移,刚度修正系数会突然降低,拉杆弯曲刚度比例系数会增加.刚度无量纲系数具有明确的物理意义,可为带端面齿的燃气轮机转子设计和故障诊断提供参考.



  • [1] 陈崇.大功率交流传动货运机车整体驱动系统研究 [D].成都:西南交通大学,2008. CHEN Chong.Study on the integrality drive system of superpower AC electrical locomotive for wagon [D].Chengdu:Southwest Jiaotong University,2008.(in Chinese)
    [2] 林公舒,杨道刚.现代大功率发电用燃气轮机[M].北京:机械工业出版社,2007.
    [3] 金令诚.端齿盘分度装置[M].北京:国防工业出版社,1995.
    [4] Bannister R H.Method for modelling flanged and curvic couplings for dynamic analysis of complex rotor constructions[J].Journal of Mechanical Design,1980,102(1):130-139.
    [5] Pisani S R,Rencis J J.Investigating CURVIC coupling behavior by utilizing two and three-dimensional boudary and finite element methods[J].Engineering Analysis with Boundary Elements,2000,24(3):271-275.
    [6] Richardson I J,Hyde T H,Becher A A,et al.A validation of the three-dimensional finite element contact method for use with curvic couplings[J].Journal of Aerospace Engineering,2002,216(2):63-75.
    [7] Yuan S X,Zhang Y Y,Zhang Y C,el al.Stress distribution and contact status analysis of a bolted rotor with curvic couplings[J].Journal of Mechanical Engineering Science.2009,224(9):1815-1829.
    [8] Richardson I J,Hyde T H,Becher A A,et al.A three-dimensional finite element investigation of the bolt stresses in an aero-engine curvic coupling under a blade release condition[J].Journal of Aerospace Engineering,2000,214(4):231-245.
    [9] 尹泽勇,欧圆霞,李彦,等.端齿轴段刚度及其对转子动力特性的影响[J].振动工程学报,1993,6(1):63-67. YIN Zeyong,OU Yuanxia,LI Yan,et al.Stiffness of a shaft section with curvic couplings and its effect on dynamic characteristic of a rotor[J].Journal of Vibration Engineering,1993,6(1):63-67.(in Chinese)
    [10] 尹泽勇,胡柏安,吴建国,等.端齿连接转子轴向预紧力的确定[J].航空动力学报,1996,9(2):355-357. YIN Zeyong,HU Baian,WU Jianguo,et al.Determination of axial preloads of rotors with curvic couplings[J].Journal of Aerospace Power,1996,9(2):355-357.(in Chinese)
    [11] 胡柏安,尹泽勇,徐友良.两段预紧的端齿连接转子轴向预紧力的确定[J].机械强度,1999,21(4):274-276. HU Baian,YIN Zeyong,XU Youliang.Determination of axial preloads of rotor with curvic couplings pretightened into two segments[J].Journal of Mechanical Strength,1999,21(4):274-276.(in Chinese)
    [12] Tsai Y C,Hsu W Y.A study on the CAD/CAM of curvic couplings [C]//Proceedings of ASME Turbo Expo.Netherlands:ASME,2002:1-6.
    [13] 刘洛莹.曲齿联轴器齿形最优化之研究[D].台湾:国立中山大学,2002. LIU Luoying.A study on the optimization of tooth profiles for curvic couplings.Taiwan:National Sun Yat-Sen University,2002.(in Chinese)
    [14] LIU Heng,CHEN Li,WANG Weimin,et al.Nonlinear dynamic analysis of a flexible rod fastening rotor bearing system [D]//Proceedings of ASME Turbo Expo.Glasgow,UK:ASME,2010:1-10.
    [15] GAO Jin,YUAN Qi,LI Pu,et al.Effects of bending moments and pre-tighting forces on the flexural stiffness of contact interfaces in rod-fastened rotors[C]//Proceedings of ASME Turbo Expo.Denmark:ASME,2012:1-9.
    [16] 李会勋,胡迎春,张建中.利用ANSYS模拟螺栓预紧力的研究[J].山东科技大学学报,2006,25(1):57-59. LI Huixun,HU Yingchun,ZHANG Jianzhong.Study on simulating bolt pretension by using ANSYS[J].Journal of Shandong University of Science and Technology,2006,25(1):57-59.(in Chinese)
