叶栅相似变换准则的实验研究
EXPERIMENTAL STUDY ON CASCADE SIMILARITY TRANSFORMATION RULES
-
摘要: 本文叙述为验证叶栅相似变换准则所进行的低速风洞实验研究,对应NACA6 5 (12)10和DCA叶栅的高速试验,分别测量了其低速相似叶栅的叶片表面压力分布。由于实验条件的不同,本文从相对差别这一角度验证了文献 [1]中所推得的相似变换准则的正确性。实验结果表明:实际的低速叶栅和高速叶栅具有同无粘设计所得到的同一量级的相似精度,因而只需提高设计相似精度便可提高实际模型的相似精度。Abstract: In order to verify the similarity transformation rules in real flow situation,two sets of low speed cascades similar to the high speed NACA65 (12)10 and DCA cascades,are designed according to the similarity rules developed by the authors and tested in a two dimensional low speed cascade tunnel.The distributions of pressure coefficient on blade surfaces are measured.The results show that the measured similarity precision is of the same order of magnitude as the design simitarity precision.Therefore further improvement of the similarity precision of blade profiles can be achieved by the improvement of the design similarity precision.
