小尺寸双级跨音轴流压气机试验研究
EXPERIMEATAL INVESTIGATION OF A SMALL TWO-STAGE TRANSONIC AXIAL COMPRESSOR
-
摘要: 本文叙述了一台叶尖速度436m/s的小尺寸双级跨音速轴流式压气机性能。在机械调试达到设计转速45000r/min后,进行了性能试验,主要性能指标都达到或超过了设计值。本文讨论了径向轴向间隙,探针堵塞,级间配合和一些测试技术对压气机性能的影响。Abstract: A small dimension two stage transonic axial compressor has been designed with blade tip veloicty 436m/s and design revolution 45000r/min.Its tests has been carried out to investigate the performance of this compressor.It is shown that its performance attains or exceeds its design specifications.This paper also considers the effects of radial and axial clearances,probe blockage,step matching and measuring techniques on the performance of the compressor.
