进口畸变条件下轴流压气机转子内流的PIV研究

李茂义; 陆亚钧; 弓志强; 袁巍

进口畸变条件下轴流压气机转子内流的PIV研究

北京航空航天大学航空航天大学能源与动力工程学院航空发动机气动热力重点实验室, 北京 100083

基金项目: 国家自然科学基金资助(50476003)

计量
- 文章访问数: 1508
- HTML浏览量: 1
- PDF量: 485
- 被引次数: 0
出版历程
- 收稿日期: 2005-06-11
- 修回日期: 2005-10-20
- 刊出日期: 2006-06-28

PIV Investigation of the Internal Flow in an Axial Flow Compressor Rotor under Inlet Distortion

National Key Laboratory on Aero-Engines, School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100083, China

摘要

摘要: 用50%堵塞比的插板畸变屏模拟低速轴流压气机进口流场畸变,用PIV(粒子图像速度场仪,ParticleImageVelocimetry)技术测量均匀和畸变进气条件下压气机转子叶片通道内的流场结构。实验表明,进气畸变条件下压气机流场在转子叶片通道内不同的周向位置会产生四种不同的流动结构状态,同时,进气畸变大大增加了漩涡扰动、流动亏损和转子叶排气流分离的强度,这样必然会对压气机的性能产生很大的影响。实验也验证了经典平行压气机理论的缺陷。
- 航空、航天推进系统 /
- 进气畸变 /
- 轴流压气机 /
- 转子叶片通道 /
- PIV技术 /
- 流场结构
Abstract: Flow field structure in the rotor blade passage of a low speed axial flow compressor both under uniform inlet flow and distorted flow simulated by adding baffles with 50% blocking ratio was investigated using PIV(Particle Image Velocimetry) technique.Experimental results indicate that there are four different flow field structure types in the compressor rotor passage at different circumferential positions under inlet distortion.Inlet distortion makes the intensity of vortex disturbance,velocity decrement and separation in the rotor passage rise greatly.This will affect the performance of compressor heavily.The experiment also testifies the limitation of the classical parallel compressor theory.
- aerospace propulsion system /
- inlet distortion /
- axial flow compressor /
- rotor blade passage /
- PIV technique /
- flow field structure

HTML

参考文献(5)

[1]	Braithwaite W M,Graber F J Jr,Mehalic C M.The Effects of Inlet Temperature and Pressure Distortion on Turbojet Performance[R].AIAA 73-1316.
[2]	Jouber H.Flowfield Calculation in Compressor Operating with Distorted Inlet Flow[R].ASME 90-GT-212.
[3]	Davis M W Jr.Parametric Investigation into the Combined Effects of Pressure and Temperature Distortion on Compression System Stability[R].AIAA 91-1895.
[4]	李传鹏,胡骏.旋转进气畸变对轴流压气机气动稳定性影响实验研究[J].航空动力学报,2004,19(4):433～437.Li Chuanpeng,Hu Jun.Effects of Rotating Inlet Distortion on a 5-Stage Compressor Stability[J].Journal of Aerospace Power,2004,19 (4):433～ 437.
[5]	赵全春.压气机实验用的三种压力畸变发生器及实验结果[J].航空发动机,1995,3:28～38.
