变流向梯形通道内短扰流柱排的流量分配实验
Experimental Investigation on Flow in Pin-Fin Trapezoidal Duct
-
摘要: 为了深入了解涡轮叶片尾缘扰流柱区域的流动情况,对叶片内流工程计算程序进行验证,针对气流90°转弯全部从弦向流出的情况,通过实验测量了梯形通道短扰流柱排的端壁静压分布,以及各段弦向出流量沿叶片径向的变化。实验结果表明:(1)静压变化主要发生在弦向,尤其是在弦向出口附近静压变化剧烈,而沿径向静压变化不大。(2)在所研究的Re数范围内,靠近叶片根部和尖部的流量较大,而叶片中部的流量较小。(3)弦向出流量沿叶片径向的变化不超过30%。实验结果对涡轮叶片内部冷却计算具有重要的参考价值。Abstract: Experiments were conducted to determine the distribution of static pressure and lateral mass flow rate in a pin-fin trapezoidal duct that modeled the cooling passages in the gas turbine blades.The ratio of lateral-to-total flow rate was 1.The flow Reynolds numbers were varied from 1.5×104through 9×104.The results show that the pressure drops along chordwise passages are much larger than that along radials.The lateral flow rates near the root and the tip of the blade are larger than that in the middle part by 5%~30%.
-
Key words:
- aerospace propulsion system /
- pin-fin /
- flow /
- mass flow rate /
- pressure
-
[1] Kumaran T K,Han J C.Augmented Heat Transfer in a Pin Fin Channel with Short or Long Ejection Holes[J].Int.Journal Heat Mass transfer,1991,34(10):2617~2628. [2] Lau S C,Mcmillin R D,Kukreja R T.Segmental Heat Transfer in a Pin Fin Channel with Ejection Holes[J].Int.Journal Heat Mass Transfer,1992,35 (6):1407~1417. [3] Jenn-Jiang Hwang,Chau-Chin Lui.Detailed Heat Transfer Characteristic Comparison in Straight and 90-Deg Turned Trapezoidal Ducts with Pin-Fin Arrays[J].Int.Journal Heat Mass Trans f er,1999,42:4005~ 4016. [4] Jenn-Jiang Hwang,Chau-Chin Lui.Measurement of Endwall Heat Transfer and Pressure Drop in a Pin-Fin Wedge Duct[J].Int.Journal Heat Mass Transfer,2002,45:877~889. [5] 张丽,刘松龄.有弦向出流的短扰流柱排流动与换热数值计算[J].推进技术,2004(4):307~310.Zhang Li,Liu Songling.Numerical Study on Heat Transfer and Pressure Drop in Pin-Fin Channels with Lateral Flow Ejection[J].Journal of Propulsion Technology,2004 (4):307~310.
