涡轮叶片尾缘复合通道中隔板结构对换热特性的影响

丁水汀; 刘丽艳; 李莉; 陶智; 徐国强

涡轮叶片尾缘复合通道中隔板结构对换热特性的影响

北京航空航天大学能源与动力工程学院航空发动机气动热力重点实验室, 北京 100083

计量
- 文章访问数: 1371
- HTML浏览量: 8
- PDF量: 472
- 被引次数: 0
出版历程
- 收稿日期: 2005-04-22
- 修回日期: 2005-09-22
- 刊出日期: 2006-06-28

The Effect of Different Clapboards Structure in Turbine Blade Trailing Edge Complex Passages on Heat Transfer Characteristics

National Key Laboratory on Aero-Engines, School of Jet Propulsion, Beijing University of Aeronautics and Astronautics, Beijing 100083, China

摘要

摘要: 采用热色液晶测温法,测量了涡轮叶片尾缘带隔板的复合通道的温度场。主要讨论了在通道其它结构均相同的条件下分别采用4种不同结构的隔板(2种孔径的矩形隔板与2种孔径的波形隔板),研究隔板中孔径大小对通道换热和流阻的影响。结果表明:矩形隔板中将矩形隔板上的孔由原来的1.8mm放大到2.5mm(即出流孔的总面积放大一倍)后提高了通道的换热,降低了流阻;波形隔板中将隔板由波谷孔径1.5mm、波峰孔径2.1mm分别放大到波谷孔径2.1mm、波峰孔径3.0mm后对换热没有提高;矩形隔板与波形隔板比较的情况下,波形隔板的换热均高于矩形隔板,而且流阻较低。
- 航空、航天推进系统 /
- 叶片尾缘 /
- 热色液晶 /
- 矩形隔板 /
- 波形隔板 /
- 换热
Abstract: The experiment mainly aimed at to investigate the effect of different aperture in different clapboard structure in the turbine blade trailing edge complex passages on heat transfer and pressure drop characteristics.A thermochromic liquid crystal method was used to measure the detailed heat transfer coefficients on the end wall surfaces.Comparison of end wall heat transfer and pressure drop characteristics was made between two kinds of rectangular clapboards and two kinds of waved clapboard in the turbine blade trailing edge complex passages.It was found that the rectangular clapboard with aperture of 2.5 millimeter produces higher heat transfer with relatively less pressure drop than that of the rectangular clapboard with aperture of 1.8 millimeter;the heat transfer of the waved clapboard with aperture 1.5 millimeter in trough and aperture 2.1 millimeter on ridge was higher than that of the waved clapboard with aperture 2.1 millimeter in trough and aperture 3.0 millimeter on ridge.Comparing the four structures,the two waved clapboards performed the higher endwall-averaged heat transfer and in the meanwhile pay the lower pressure drop penalty than the two rectangular clapboards.
- aerospace propulsion system /
- turbine blade trailing edge /
- thermochromic liquid crystal /
- rectangular clapboard /
- waved clapboard /
- heat transfer

HTML

参考文献(3)

[1]	Jenn-Jiang Hwang,Chau-Chin Lui.Detailed Heat Transfer Characteristic Comparison Inrectangular and 90-Deg Turned Trapezoidal Ducts with Pin-Fin Arrays[J].International Journal of Heat and Mass Transfer,1999,42:4005 ～ 4016.
[2]	吉洪湖,玉宝官.涡轮叶片尾缘出流对带叉排扰流柱阵列的内冷通道传热特性的影响[J].航空动力学报,1999,14(3):Ji Honghu,Wang Baoguan,Wang Daijun,Deng Huayu.Effect of Trailing and Edge Ejection of Turbine Blades on Heat Transfer of Cooling Passage with Staggered Pin Fins[J].Journal of Aerospace Power,1999,14(3):237～241.
[3]	李莉,丁水汀,陶智,徐国强,赵世红.涡沦叶片尾缘复合通道的换热[J].北京航空航天大学学报,2005,31(2):202～205.Li Li,Ding Shuiting,Tao Zhi,Xu GuoQiang,Zhao Shihong.Heart Transfer in Complex Passages of Turbine Blade Trailiing Edge[J].Journal of Beijing University of Aeronautics and Astronautic,2005,31 (2):202～205.
