非均匀横流作用下冲击射流冷却的数值研究

谭蕾; 张靖周; 谭晓茗

非均匀横流作用下冲击射流冷却的数值研究

南京航空航天大学能源与动力学院, 江苏南京 210016

计量
- 文章访问数: 1577
- HTML浏览量: 2
- PDF量: 487
- 被引次数: 0
出版历程
- 收稿日期: 2005-06-04
- 修回日期: 2005-09-26
- 刊出日期: 2006-06-28

Numerical Investigation of Jet Impingement Cooling with Non-Uniform Crossflow

College of Energy and Power Engineering, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 运用数值计算的方法对非均匀横流作用下冲击射流冷却的流动和传热过程进行了三维数值研究,揭示出射流冲击孔和横流孔相对排列方式、射流雷诺数和横流雷诺数相对大小、射流孔中心至横流孔出口截面距离等因素对冲击射流冷却流动传热特性的影响。结果表明:若保持总的冷却流量不变,当横流雷诺数与射流雷诺数之比等于或大于0.5后,有横流时的冲击射流冷却局部努塞尔数比无横流时有较为显著的下降;在非均匀的横流作用下,对于叉排和顺排方式,由于射流和横流的相互作用,壁面温度分布呈现出复杂的特征;射流孔和横流孔呈顺排布置时,峰值努塞尔数所对应的射流驻点区向下游偏移。
- 航空、航天推进系统 /
- 冲击冷却 /
- 非均匀横流 /
- 强化传热 /
- 数值计算
Abstract: Three-dimensional numerical computation of the flow and heat transfer for the jet impingement cooling with non-uniform initial crossflow was conducted to investigate the effects of the jet-to-surface spacing,the impinging holes and crossflow holes arrangement,as well as the crossflow to jet Reynolds number ratio on the heat transfer characteristics.When the crossflow to jet Reynolds number ratios are equal or greater than 0.5,the jet impingement Nusselt numbers are obviously lower than that without crossflow under the same total cooling massflow rate.Under the action of non-uniform crossflow,the temperature distributions take complicated feature for both staggered and inline arrangements owing to the interaction of jet and crossflow.Compared to the case of staggered arrangement between jet holes and crossflow holes,the stations corresponding to peak Nusselt numbers for inline arrangement move downstream.
- aerospace propulsion system /
- jet impingement /
- non-uniform crossflow /
- enhanced heat transfer /
- numerical calculation

HTML

参考文献(10)

[1]	顾维藻,神家锐,马重芳.强化传热[M].北京:科学出版社,1992.
[2]	Jambunathan K,Lai E,Moss M A,Button B L.Review of Heat Transfer Data for Single Circular Jet Impingement[J].International Journal of Heat and Fluid Flow,1992,13(2):106～115.
[3]	Florschuetz L W,Isoda Y.Flow Distributions and Discharge Coefficient Effects for Jet Array Impingement with Initial Crossflow[J].Journal of Engineering for Power,1983,105(3):296～303.
[4]	Florschuetz L W,Metzger D E,Su C C.Heat Transfer Characteristics for Jet Array Impingement with Initial Crossflow[R].ASME Paper 83-GT-28,1983.
[5]	Chen Wanbing,Chang Haiping.3-D Numerical Simulation of Impinging Jet Cooling with Initial Crossflow[R].ASME Paper 99-GT-256,1999.
[6]	Ashforth-Frost S,Jambunathan K.Numerical Prediction of Semi-Confined Jet Imoingement and Comparison with Experimental Data[J].International Journal of Meth.Fluids,1996,23(3):295～396.
[7]	Zhang Jingzhou,Li Liguo.High Resolution Heat Transfer Coefficient Measurement for Jet Impingement Using Thermochromic Liquid Crystals[J].Chinese Journal of Aeronatics,2001,14(4):205～ 209.
[8]	张靖周,李永康,谭晓茗,李立国.阵列射流冲击冷却局部对流换热特性的数值计算与试验验证[J].航空学报,2004,25(4):339～342.Zhang Jingzhou,Li Yongkang,Tan Xiaoming,Li Liguo.Numerical Computation and Experimental Investigation on Convective Heat Transfer Characteristics for Jet Array Impingement[J].Acta Aeronautica Et Astronautica Sinica,2004,25(4):339-～342.
[9]	陶文铨.数值传热学[M].西安:西安交通大学出版社,1992.
[10]	Launder B E,Sharma B I.Application of the Energy-Dissipation Model of Turbulence to the Calculation of Flow Near a Spinning Disc[J].Letters in Heat and Mass Transfer,1974,1:131～134.
